Heathkit SB-200 Linear Amplifier

This is a classic linear amplifier by the Heathkit Company. The amplifier is capable of putting out 1200 watts PEP SSB and 1000 watts CW with a power input of 100 watts. It operates on the 80, 40, 20, 15 and 10 meter bands. The unit uses forced air cooling. At present, the amplifier is wired for 240V.

Physical characteristics: 14 7/8 inches wide x 6 5/8 inches high x 13 3/8 inches deep. 35 lbs.

This unit was owned by Ernie Brown, W5FYX-SK, and was donated to QCWA Chapter 85 and sold at auction to raise scholarship money.
