Area Repeater Map & Approximate Coverage



Scroll down to view repeater frequencies & locations.

Check out the new Yaesu repeaters!

Image of rainbowbullet.gifCircles indicate approximate coverage using a 50 watt mobile with 5/8 mobile antenna. Again, this is only approximate.

Best viewed at 1024 x 768

Legend
Blue  -Pinetree Intertie UHF Backbone Red - Controlled through backbone control

Brown - Remote Base (2m link) Coloured Rings - Indicate approximate coverage.



Download the Pinetree Intertie Manual



Repeater Directory

The frequencies in RED are the ones shown on the map.P T I - Pine Tree Intertie, Linking

Pine Tree Intertie, Linking - UHF Backbone


Dryden, ON- VE3DRY 147.255+  linked to PTI

Camp Robinson, ON- VE3VBY 145.310- remote base to VE3DRY

Atikokan, ON- VE3RIB 147.120+  IRLP link to VE3DRY, Link#3

Sioux Lookout, ON- VE3YXL 146.850- linked to PTI    Being Rebuilt

Sioux Narrows, ON- VE3RSN 145.170- linked to PTI

Kenora, ON- VE3LWR 147.030- linked to PTI

BlackHawk, ON- VE3RBK 147.045+ linked to PTI

Falcon Lake, MB- VE4FAL 146.640- linked to PTI        CTCSS  (127.3Hz)

Milner Ridge, MB- VE4MIL 145.210- linked to PTI        CTCSS  (127.3Hz)

Starbuck, MB- VE4MAN 146.610- linked to PTI        CTCSS  (127.3Hz)

Winnipeg, MB- VE4WPG 147.390+ linked to PTI        CTCSS  (127.3Hz)

Winnipeg, MB- VE4VJ 443.500+ linked to PTI        CTCSS  (127.3Hz)

Portage La Prairie, MB- VE4PLP 147.165+ linked to PTI



 IRLP Nodes

Status

Dryden, ON- VA3DIS 147.375+      IRLP  #2739

Ignace, ON- VA3IGN 147.180+      IRLP  #2414    CTCSS  (123.0Hz)

Atikokan, ON- VE3RIB 147.120+      IRLP  #2768

Sioux Narrows, ON- VE3JJA 146.580s      IRLP  #2015    CTCSS  (123.0Hz)

Kenora, ON- VE3YQK 146.560s      IRLP   #2949   CTCSS  (123.0Hz)

Fort Frances, ON- VE3BIK 146.570s      IRLP   #2509   CTCSS  (123.0Hz)

Thunder Bay, ON- VA3LU      146.820-      IRLP   #2000   CTCSS  (107.2Hz)

Winnipeg, MB- VE4WSC 147.570s      IRLP   #1809   CTCSS  (127.3Hz)

Winnipeg, MB- VA4FIL 443.600+      IRLP   #1205

Pinawa, MB- VA4GD 146.490s      IRLP   #1981   CTCSS  (127.3Hz)

St. Andrews, MB- VE4COR 146.580s      IRLP   #1121   CTCSS  (127.3Hz)

Winnipeg, MB- VA4GL 432.400s      IRLP   #1018   CTCSS  (127.3Hz)


Utilizing Reflector 9021




Other Repeaters




Sioux Narrows, ON- VA3EMC 147.330+ Yaesu System Fusion  DIGITAL

Kenora, ON- VE3YQK 146.910- Yaesu System Fusion  AMS (123.0Hz)

Dryden, ON- VA3EOD 145.425- Yaesu System Fusion DIGITAL

BlackHawk, ON- VE3RBK 145.110- Yaesu System Fusion DIGITAL

Nestor Falls, ON- VA3EMN 146.715- Yaesu System Fusion DIGITAL

Sioux Lookout, ON- VA3SLT 147.195+ Yaesu System Fusion DIGITAL

St. Andrews, MB- VE4INT 146.820- Yaesu System Fusion DIGITAL

Falcon Lake, MB- VE4ZIM 147.525s Yaesu System Fusion DIGITAL

Winnipeg, MB- VA4ART 444.100+ Yaesu System Fusion DIGITAL

Marathon, ON- VE3JTD 146.550s Yaesu System Fusion DIGITAL


VA3ADI's Logging Script Page for VA3SLT


Utilizing Room 21578



Local

Dryden, ON- VA3YHD 53.150- Linked to 2Meter VA3YHD

Dryden, ON- VA3YHD 147.150+ PL tone

Sioux Narrows, ON- VA3SXN 146.940- Local (Usually runs in summer)

Fort Frances, ON- VE3RLC 146.820- Local

Red Lake, ON- VE3RLD 147.000+ Local

Upsala, ON- VE3UPP 145.470- Local



APRS Digis & IGATES


Dryden- VE3DRY 144.390 WIDE

Dryden- VA3EOD 144.390  IGATE, WIDE, WX

Dryden- VA3EXT 144.390  IGATE

Sioux Lookout- VE3SLT 144.390  IGATE

Bear Paw- VA3BPL 144.390 WIDE 1   Being Rebuilt

Red Lake- VE3YQK-1 144.390 IGATE

Red Lake- VE3YQK-2 144.390 WIDE

Atikokan- VE3RIB-1 144.390 WIDE

Atikokan- VE3FYN 144.390 IGATE

Flanders- VE3RIB-2 144.390 WIDE

Sioux Narrows VE3RMU 144.390 WIDE

Sioux Narrows VE3JJA 144.390 IGATE, WIDE, WX

Fort Frances- VE3RLC 144.390 WIDE

Fort Frances- VA3FNP 144.390 IGATE

Fort Frances- VE3BVC 144.390 IGATE

Black Hawk- VE3RBK 144.390 WIDE

Kenora- VE3YQK 144.390 WIDE

Falcon Lake- VE4FAL-3 144.390 WIDE
