1	Übersicht Overview

---

1.1	Trioden Triodes

---

0 1 2 3 4 5 6 7 8 9   10-99 100-999 1000-9999 10 000   A B C D E F G H I J K L M N O P Q R S T U V W X Y Z

1DY4 ... 1DY4A   EQUIV. Uf If µ Base w Art - Type = Anwendungen - Applications Ref *? Heater V A   Outline g 1D3  AC/DC 1.25 0.3 8.7 8DN U32   UHF triode 4 Syl50 1DY4  - 1.6 0.6 28 7DK M38   Frame grid triode = UHF oscillator 16 Syl63 1DY4A  - 1.6 0.6 28 7DK M28   Frame grid triode = UHF oscillator 16 Syl63 1E4G  - 1.4 0.05 14 5S K86   General purpose triode = Oscillator in battery operated receiver Syl39 - 1.4 0.05 14.5 G-5S K86   Syl40 1G4GT  DC 1.4 0.05 8.8 G-5S K70   General purpose triode = Battery operated receiver Rca42 Tse44 1H4G  (30) DC 2.0 0.06 9.3 G-5S ST12   General purpose triode = Detector, Class-A1, Class-B2 amplifier 460 Rca38 Tse38 1H4GT  DC 2.0 0.06 9.3 G-5S K70   Triode = Detector, Class-A1, Class-B2 amplifier 460 Syl47 1LE3  DC 1.4 0.05 14.5 4AA L57   Triode = Detector, oscillator, amplifier in battery operated receiver Rca47 Tse49 1LF3  1LE3 DC 1.4 0.05 14.5 4AA L57   Triode = Resistance coupled amplifier, low grid current Syl48   EQUIV. Uf If µ Base w Art - Type = Anwendungen - Applications 18519 Heater V A   Outline g

2A3 ... 2T4   EQUIV. Uf If µ Base w Art - Type = Anwendungen - Applications Ref *? Heater V A   Outline g 2A3  AC/DC 2.5 2.5 4.2 4D ST16   Power Amplifier Triode = Power-output stage of AC-operated receiver 124 Tse45 Rca47 2A3H  AC/DC 2.5 2.5 4.2 4Q   Power Triode = Audio Amplifier Rat64 2AF4  XC94 2.35 0.6 13.5 7DK M38   UHF Triode = TV Oscillator 16 Get56 2AF4A  (XC94) 2.35 0.6 13.5 7DK M28   UHF Triode = TV Oscillator, Ufk=50 V 16 Get56 2AF4B  (XC94) 2.35 0.6 15 7DK M28   UHF Triode = 950 MHz TV Local Oscillator, Ufk=180 V 16 Tse58 2BN4  - 2.3 0.6 43 7EG M38   VHF Triode = TV RF Amplifier, S=6.8 mA/V 16 Get56 2BN4A  - 2.35 0.6 43 7EG M38   VHF Triode = TV RF Amplifier, S=8.0 mA/V 16 Tse59 2C22  7193 6.3 0.3 20 4AM   Triode = RF Amplifier Rca43 2C36  - 6.3 0.4 25 Cx-4D5   SHF Triode = Pulsed Oscillator 224 Syl 2C37  5766 5767 6.3 0.4 25 Cx-4D5   SHF Triode = Oscillator 224 Syl 2C39A  5648 6.3 1.1 100 Cx-4D3A 75 SHF Triode = Amplifier - Oscillator Val69 2C39BA  - 6.0 1.05 100 Cx-4D3A 70 SHF Triode = Amplifier - Oscillator Val69 2C41  - 6.3 1.03 100 Cx-4D3   SHF Triode = Pulsed Oscillator 98 Ray 2C53  - 6.3 0.3 450 Oc-8C4   Power Triode = HV Shunt Regulator Mil98 2CW4  - 2.1 0.45 65 12AQ MT4   Nuvistor Triode = VHF Amplifier 298 Rca70 2DS4  - 2.1 0.45 63 12AQ MT4   Nuvistor Triode = Grounded-cathode neutralized VHF amplifier 298 Rca75 2DV4  - 2.1 0.45 35 12EA MT4   Nuvistor Triode = 1000 MHz TV UHF oscillator 298 Rca75 2DX4  - 2.4 0.6 30 7DK M28   UHF Triode = TV local oscillator 16 Wec63 2DY4  - 2.05 0.45 28 7DK M38   Frame grid triode = UHF oscillator 16 Syl63 2DY4A  - 2.05 0.45 28 7DK M28   Frame grid triode = UHF oscillator 16 Syl63 2DZ4  - 2.35 0.6 14 7DK M28   UHF triode = 1000 MHz oscillator 16 Tse63 2EG4  - 1.7 0.6 63 12AQ MT4   Nuvistor Triode = Grounded-cathode neutralized VHF amplifier 298 Rca75 2ER5  XC95 2.3 0.6 80 7FP M38   Semi-remote cutoff frame-grid triode = VHF RF amplifier 16 Syl60 2ES5  - 2.35 0.6 75 7FP M38   Semi-remote cutoff triode = Grounded-cathode VHF RF amplifier 16 Tse60 2FH5  - 2.35 0.6 50 7FP M38   VHF Neutrode Triode = Grounded-Cathode Tuner Amplifier 16 Tse61 2FQ5  - 2.3 0.6 60 7FP M38   Semi-remote cutoff triode = VHF and RF amplifier 16 Tse60 2FQ5A  - 2.3 0.6 74 7FP M38   Semi-remote cutoff triode = VHF and RF amplifier 16 Tse61 2FY5  XC97 2.4 0.6 70 7FP M38   Remote-cutoff frame-grid shielded triode = 200 MHz low-noise TV VHF tuner 16 Tse60 2GK5  - 2.3 0.6 78 7FP M38   Frame grid gain-controlled triode = Neutrode circuit VHF amplifier 16 Syl61 2GW5  - 2.45 0.6 70 7GK M38   Frame grid gain-controlled triode = Neutrode circuit VHF amplifier 16 Syl62 2HK5  - 2.3 0.6 75 7GM M38   Frame grid gain-controlled triode = VHF RF amplifier 16 Syl62 2HM5  - 2.4 0.6 78 7GM M38   Sharp-cutoff triode = VHF TV tuner grounded-cathode RF amplifier 16 Wec63 2HQ5  - 2.4 0.6 78 7GM M38   Triode = Grounded-Cathode VHF Amplifier 16 Syl 2T4  - 2.35 0.6 13 7DK M28   Triode = UHF Oscillator 16 Tse54   EQUIV. Uf If µ Base w Art - Type = Anwendungen - Applications 18518 Heater V A   Outline g

3-500Z ... 3HQ5   EQUIV. Uf If µ Base w Art - Type = Anwendungen - Applications Ref *? Heater V A   Outline g 3-500Z - 5.0 14.5 160 Gi-5D1   High-Mu Power Triode = Audio or RF Amplifier 32 Eim68 3A/107B CV1655 4.0 0.25 7.0 Eu-4C1   Triode = Output Amplifier 5 Mik60 3AF4  - 3.15 0.45 13.5 7DK M38   UHF Triode = 1000 MHz TV local oscillator 16 Tse64 3AF4A - 3.2 0.45 13.5 7DK M28   UHF Triode = TV Oscillator, Ufk=50 V 16 Get56 3AF4B  - 3.2 0.45 13.5 7DK M28   UHF Triode = TV Oscillator, Ufk=180 V 16 Get63 3BN4  - 3.0 0.45 43 7EG M38   VHF Triode = TV RF Amplifier 16 Get56 3BN4A  - 3.0 0.45 43 7EG M38   VHF triode = TV tuner RF amplifier 16 Tse62 3C24 - 6.3 3.0 23 2D   Medium-Mu Triode = Modulator - RF Power Amplifier 32 Eim46 3CX 100A5 - 6.0 1.05 100 Cx-4D3A 70 SHF Triode = Amplifier - Oscillator 106 Val69 3CX 300A1 - 6.3 2.65 9.0 Lo-8D1 200 Power Triode = Audio Amplifier 99 Sve96 3DX4  - 3.0 0.45 30 7DK M28   UHF Triode = TV local oscillator 16 Wec63 3DY4  - 2.9 0.3 28 7DK M38   Frame grid triode = UHF oscillator 16 Syl63 3DY4A  - 2.9 0.3 28 7DK M28   Frame grid triode = UHF oscillator 16 Syl63 3DZ4  - 3.2 0.45 14 7DK M28   UHF triode = 1000 MHz oscillator 16 Tse63 3ER5  - 2.8 0.45 80 7FP M38   Semi-remote cutoff frame-grid triode = VHF RF amplifier 16 Syl60 3ES5  - 3.0 0.45 75 7FP M38   Semi-remote cutoff triode = Grounded-cathode VHF RF amplifier 16 Tse60 3FH5 - 3.0 0.45 50 7FP   VHF Triode = Tuner Amplifier 16 Rca64 3FQ5  - 2.8 0.45 60 7FP M38   Semi-remote cutoff triode = VHF and RF amplifier, S=11 mA/V 16 Tse60 3FQ5A  - 2.8 0.45 74 7FP M38   Semi-remote cutoff triode = VHF and RF amplifier 16 Tse61 3FY5  - 3.1 0.45 70 7FP M38   Remote-cutoff frame-grid shielded triode = 200 MHz low-noise TV VHF tuner 16 Tse60 3GK5 - 2.8 0.45 78 7FP M38   Frame grid gain-gontrolled triode = VHF RF amplifier 16 Syl61 3GW5 - 3.0 0.45 70 7GK M38   Frame grid gain-gontrolled triode = VHF RF amplifier 16 Syl62 3HA5  - 2.7 0.45 80 7GM M28   VHF Triode = Grounded-cathode RF amplifier 16 Get64 3HK5  - 2.9 0.45 75 7GM M38   Frame grid gain-controlled triode = VHF RF amplifier 16 Syl62 3HM5  - 2.9 0.45 78 7GM M38   Sharp-cutoff triode = VHF TV tuner grounded-cathode RF amplifier 16 Wec63 3HQ5 - 3.0 0.45 78 7GM M38   Triode = VHF Amplifier 16 Syl   EQUIV. Uf If µ Base w Art - Type = Anwendungen - Applications 18518 Heater V A   Outline g

4BN4 ... 4HQ5   EQUIV. Uf If µ Base w Art - Type = Anwendungen - Applications Ref *? Heater V A   Outline g 4BN4  - 4.2 0.3 43 7EG M38   VHF Triode = TV RF Amplifier Bri58 4D1 CV1109 13 0.2 40 Br-7C1A   Triode = Amplifier Bab58 4GK5  - 4.0 0.3 78 7FP M38   Frame grid gain-gontrolled triode = VHF RF amplifier 16 Syl61 4GW5  - 4.2 0.3 70 7GK M38   Frame grid gain-gontrolled triode = VHF RF amplifier 16 Syl62 4HM5  - 4.0 0.3 78 7GM M38   Sharp-cutoff triode = VHF TV tuner grounded-cathode RF amplifier 16 Wec63 4HQ5  - 4.2 0.3 78 7GM M38   Triode = VHF Amplifier 16 Syl   EQUIV. Uf If µ Base w Art - Type = Anwendungen - Applications 18516 Heater V A   Outline g
