The images on this page were generated artificially with a 3D raytracing program, call POV-RAY. More details can be found at another page on this site, or at it's home page.

	View of the entire antenna.
		Orthographic view (no perspective) of the complete antenna.
	View from above.
		View from above - slightly tilted. Pay attention to the fact that the middle supports are not exactly at 90 degrees - barely noticeable (see also the next image).
	One of the middle supports for the cable. Again, check the small offset to the left, compensating the fact that it couldn't be located in the middle vertically.
		Another side view of the completed antenna.

---
