Ultra-compact HF/VHF/UHF Transceiver


Breaking new ground in the field of micro-miniature transceiver design, the FT-100 is the only miniature mobile transceiver providing coverage of the 160~6 meter bands plus the 144 MHz and 430 MHz bands, Combining a unique, user-friendly front panel with high-tech features like Digital Signal Processing, the FT-100 provides performance capability well above that of many base station transceivers, ideal as a compact mobile, vacation, or expedition transceiver, the FT-100 provides wide frequency coverage and operating versatility for every operator's requirements.

Features (info courtesy Yaesu)

  • Frequency coverage: RX :100 kHz - 970 MHZ (Cellular/digital telephone freqencies are blocked)
  • TX :160~6 Meters, 2-Meters, 70 CM
  • Power output: HF/50 MHz 100W , 2-Meters 50W , 70 CM 20W
  • All Mode Operation: SSB, CW, AM, FM, AFSK, Packet (1200/9600 bps)
  • Detachable and Remoteable Front Panel
  • DSP Bandpass Filter, Notch Filter and Noise Reduction
  • IF Noise Blanker
  • IF Shift
  • Optional 6 kHz, 500 Hz, 300 Hz IF Filters
  • Two Antenna Jacks (HF/50 and 144/430)
  • VOX
  • DuaI VFOs
  • Built-in Electronic Memory Keyer
  • Speech Processor
  • Built-in CTCSS Encode/ DCS (Digital Coded Squelch)
  • Automatic Repeater Shift (ARS)
  • 300 Memory Channels
  • Quick Memory Bank (QMB)
  • Smart SearchTM Automatic Memory Channel Loading System
  • Auto-Range Transpond System (ARTS )
  • Bright LCD with Multi-Function Display Menu
  • Compatible with optional ATAS-100 Active-Tuning Antenna System
