DTMF Functions
In Sysop mode, EchoLink can be configured to accept commands through the
local receiver using DTMF tones (TouchTones). These commands are used to
enable or disable the link, or to connect or disconnect a station on the
Internet.
Each command consists of a sequence of digits (or the special keys *, #, and
A through D). Although a set of default sequences is assigned to each
function, any sequence can be customized using the DTMF tab of the Sysop Settings page.
The table below lists each of the DTMF commands.
Note: If you have upgraded from an earlier version of EchoLink, you
may need to choose "Reset to Defaults" to make all of the
following commands available.
Command
|
Description
|
Default
|
Connect
|
Connects to a station on the Internet, based on its node
number.
|
num
|
Connect by Call
|
Connects to a station on the Internet, based on its
callsign.
|
C+call+#
|
Random Node
|
Selects an available node (of any type) at random, and
tries to connect to it.
|
00
|
Random Link
|
Selects an available link or repeater (-L or -R) at
random, and tries to connect to it.
|
01
|
Random Conf
|
Selects a conference server at random, and tries to
connect to it.
|
02
|
Random User
|
Selects an available single-user station at random, and tries
to connect to it.
|
03
|
RandomFavNode |
Selects an available node (of any type) at random from the Favorites
List, and tries to connect to it. |
001 |
RandomFavLink |
Selects an available link or repeater (-L or -R) at random from the
Favorites List, and tries to connect to it. |
011 |
RandomFavConf |
Selects a conference server at random from the Favorites List, and
tries to connect to it. |
021 |
RandomFavUser |
Selects an available single-user station at random, and tries to
connect to it. |
031 |
Disconnect
|
Disconnects the station that is currently connected.
If more than one station is connected, disconnects only the most-recently-connected station.
|
#
|
Disconnect All |
Disconnects all stations. |
## |
Reconnect
|
Re-connects to the station that most recently
disconnected.
|
09
|
Status
|
Announces the callsign of each station currently
connected.
|
08
|
Link Down
|
Disables EchoLink (no connections can be established).
|
(none)
|
Link Up
|
Enables EchoLink.
|
(none)
|
Play Info
|
Plays a brief ID message.
|
*
|
Query by Call
|
Looks up a station by its callsign, and reads
back its node number and status.
|
07+call+#
|
Query by Node
|
Looks up a station by its node number, and reads back its
callsign and status.
|
06+num
|
Profile Select |
Switches to a different stored set of configuration settings (0
through 9). |
B#+num |
Listen-Only On
|
Inhibits transmission from RF to the Internet.
|
0511
|
Listen-Only Off
|
Restores normal transmission from RF to the Internet.
|
0510
|
Connect
The default for the Connect command is to simply enter the 4- 5-, or 6-digit
node number to which you wish to connect. To prevent interference with
other DTMF functions, however, you may wish to configure a special prefix,
such as A or 99.
Link Up and Link Down
No defaults are provided for these functions. To enable these
functions, enter a DTMF sequence for each one, using the DTMF tab of the Sysop
Settings page.
Profile Select
Profiles are numbered from 0 to one less than the number of profiles shown
under File->Profiles. Profile 0 is always MAIN.
Station Shortcuts
Custom DTMF commands can be created to connect to specific stations. These
commands are called Station Shortcuts, and are not shown in the table above. To
manage your Station Shortcuts, click the Station Shortcuts button on the DTMF
tab of Sysop Settings.
Entering Node Numbers
To enter a node number (for the Connect or Query by Node commands), enter
the 4-, 5-, or 6-digit node number. If the specified node is not among
the stations currently logged on, EchoLink will say "NOT FOUND".
Entering Callsigns
To enter a callsign (for the Connect by Call or Query by Call commands),
press two digits for each letter and number in the callsign. The first
digit is the key on which the letter appears (using 1 for Q and Z), and the
second digit is 1, 2, or 3, to indicate which letter is being entered. To
enter a digit, press the digit followed by 0. When finished, end with the
pound key (#).
For example, the letter "K" is entered as "52", the
letter "Q" is entered as "11", and the digit "7"
is entered as "70".
Callsigns need not be entered in full. If a partial callsign is
entered, EchoLink will find the first match among the stations currently logged
on. If no match is found among the stations currently logged on, EchoLink
will say "NOT FOUND".
Examples
(These examples assume that the default DTMF codes are configured.)
- To connect to node number
9999:
Enter: 9 9 9 9
EchoLink responds with:
"CONNECTING TO CONFERENCE
E-C-H-O-T-E-S-T"
followed by
"CONNECTED"
because 9999 is the node number of conference
server "*ECHOTEST*".
- To get the status of K1RFD:
Enter: 0 7 5 2 1
0 7 2 3 3 3 1 #
EchoLink responds with:
"K-1-R-F-D 1-3-6-4-4 BUSY"
because 13644 is the node number of station K1RFD,
and K1RFD is currently busy.
- To connect to a random link
or repeater:
Enter: 0 1
EchoLink responds with:
"CONNECTING TO K-1-O-F REPEATER"
followed by
"CONNECTED"
because K1OF-R was selected at random.
