PS-1V4 Power Supply

Home

This is the second half of the power supply project that originally started life embedded in the PS-25 power unit. It has now been built into a separate SB-600 case and as a result is much easier to maintain.

The following regulated DC lines are provided via an octal socket on the rear panel:

+1.4v @ 1A

+12v @ 1A

-0V common low voltage return line

-32v at 20mA

+67.5v @ 20mA

+90v at 100mA

and one unregulated line of +150v @100mA

-0v common high voltage return line

Top view of the completed power supply:
