One day in
the late summer of 2018
Ed, KB8QEU, was walking
from his house in Lancer
toward the back side of
Bull Creek. Being an
avaid model railroader,
he was taking a lot of
pictures of the trackage
and the load-out for
later modeling in a HO
scale model rail road
diorama.
After looking at the
pictures, he saw a tower
and noticed it was in
line of site of his
residence. After
researching the path, it
was truly in LOS! See
the images below!
Here is the parent image thatshows the
tower.
Click on
this image to
see full size!
|
|
Here
is the close
up view of the
tower.
Resolution is
low.
|
|
At this time, Ed
is yet to recon the site, but
he will very soon!
So, here, below, is a plan for
that site.
It sees South Williamson site,
and a few other potential
sites, via 5.825 Gigacycle
microw-wave, easily!
|
Ed already have
the beginnings of a repeater
system at my residence and
this is the second of three
for now.
Maybre later, Joe's Knob -
Pike County - Kentucky,
Pilot Knob - Guyandotte
Mountain - Kopperston - West
Virginia, Skeleton Tank Hill
- Skeleton - Raleigh County
- West Virginia and Huff
Knob - Flat Top - (Raleigh/Mercer
County Line) Raleigh
County (By a few feet) - West
Virginia.
The plans for this site is
for it to be the hub for the
link points, and be a
repeater stack it's self.
Plans for later P25 and DMR,
as well maybe a 928 Mcs
repeater, listed below but
for planning at this time.
|
At this
time there are three
locations
planned/operational.
Mouse
over the Site ID Numbers
to be able to select that
site!
The below listing is
dynamic as more sites are
to be added or changed!
The below table will be
located on each of the
individual Site Pages!
In
Amateur Radio, being
dynamic and go with a
changing
environment is the key
to great communications!
|
|
|
Lancer
At Residence
Floyd County
Kentucky |
Sugarloaf Branch
Bull Creek
Floyd County
Kentucky
|
South Williamson
EKB Tower
Pike County
Kentucky
|
Site Secured
Opeational
- VLP
|
Site
Under
Negotiation
|
Site Under Negotiation
May
change to it's
planned
original
location at
054059-010
Williamson,
Mingo County
West Virginia.
|
|
x
|
|
LATITUDE
|
:
|
37°
40' 10.01" /
37.66944722°N |
LONGITUDE
|
:
|
82°
42' 21.80" /
82.70605556°W |
| MAP |
: |
|
AMSL
|
:
|
1386.000'
/ 0422.453m |
OHAGL
|
:
|
190.000'
/ 0057.912m |
OHAMSL
|
:
|
1576.000'
/ 0480.365m |
OHAAT
|
:
|
652.713' / 198.497m |
|
|
|
|
|
|
|
Listed by
Bands, Then OutPut±(Tone)
(If a
simplex radio is linked to a
particular repeater stack,
then the "$" is used in
place of ±. The "M" is used
to indicate Microwave.)
To see the
Co-Ordination Tables
individually, click the "-###"
in the "SUB #" Column.
To see the explanation of
the colors that is used in these
Co-Ordination Tables, Click
Here! |
| SUB # |
Out[±$](Tone ) |
Mode |
Type
|
Notes |
Plotted |
| -111 |
0029.62000-(127.3)
|
Analog
|
Repeater
|
(1)
|
No |
| -112 |
0053.11000-(127.3)
|
Alalog
|
Repeater |
(1) |
Yes |
| -113 |
0146.73000-(127.3)
|
Alalog
|
Repeater |
(1)(2)(4)(5)
|
Yes |
| -114 |
0224.90000-(127.3)
|
Alalog
|
Repeater |
(1) |
Yes |
| -115 |
0442.90000+(127.3)
|
Alalog
|
Repeater |
(1) |
Yes |
| -116 |
0927.60000+(127.3)
|
Alalog
|
Repeater |
(1) |
Yes |
| -117 |
- |
- |
- |
- |
No |
| -543 |
0144.39000$(None
) |
Digital
|
APRS |
(1)(2) |
Yes |
| -713 |
0145.24000+(None
)
|
Digital
|
Repeater - P-25
|
(1)(2)
|
No |
| -813 |
0145.02000-(
CC15) |
Digital
|
Repeater -
DMR
|
(1)(2) |
Yes |
| -815 |
0444.95000+(
CC15)
|
Digital |
Repeater -
DMR |
(1) |
Yes |
| -999 |
5825.00000M(None
) |
Digital |
Microwave Link to
021071-0010
|
(1)(3)(9) |
Yes |
| -999 |
5825.00000M(None
) |
Digital |
Microwave Link to
021071-0200
|
(1)(4)(9) |
Yes |
| -999 |
5825.00000M(None
) |
Digital |
Microwave Link to
021071-0300
|
(1)(4)(9) |
Yes |
| -999 |
5825.00000M(None
) |
Digital |
Microwave Link to
021071-0400
|
(1)(4)(9) |
Yes |
| -999 |
5825.00000M(None
) |
Digital |
Microwave Link to
021195-0100
|
(1)(3)(9) |
Yes |
| -999 |
5825.00000M(None
) |
Digital |
Microwave Link to
021195-0200
|
(1)(4)(9) |
Yes |
| -999 |
5825.00000M(None
) |
Digital |
Microwave Link to
021195-0600
|
(1)(4)(9) |
Yes |
| -999 |
5825.00000M(None
) |
Digital |
Microwave Link to
021115-0100
|
(1)(4)(9) |
Yes |
| -999 |
5825.00000M(None
) |
Digital |
Microwave Link to
054059-0200
|
(1)(4)(9) |
Yes |
| -999 |
5825.00000M(None
) |
Digital |
Microwave Link to
054109-0100
|
(1)(3)(9) |
Yes |
Notes
|
:
|
(1)
Planning Stage
|
|
|
|
(2)
These may need
additional equipment
for filtering the
others of the same
band. |
|
|
|
(3)
A definite
install and to calculated
for
wind loading.
|
|
|
|
(4)
Future planning and is
to be calculated for
wind loading.
|
|
|
|
(5) This
Frequency looks
available but two others
can be.
|
|
|
|
(9)
Ubiquiti
AF-5U
Wind loading of 863
N @ 200 km/hr (194
lbf @ 125 mph)
Wind Survivability
is 200 km/hr (125
mph).
|
|
|
|
|
|
|
|
|
021071-0100 ,Sugarloaf Branch, Bull Creek,
KY
Frequency Selection Tables for Co-Ordination |
In the next table, the first
column is the SUB # column. Some of these
numbers are clickable to take you to that
Co-Ordination data table series for that Sub
#.
When you do choose to look at the tables,
below the frequency table, note the colors in
the data rows, other than headers.
They are :
|
White
|
:
|
These
repater data rows are from the Repeayer
Book Data.
|
|
Pink
|
:
|
These
repeaters data rows are from SERA
Co-Ordination Frequency Search Data.
|
|
Red
|
:
|
Any
repeater row with this color is a
posible Co-Ordination but, it may have a
Co-Ordination issue and may not be
Co-Ordinated. Thus, this frequence may
change or not be.
|
|
The Greens
|
:
|
Lite Green Background, with Black fonts!
This
repeater is the target frequency and is
to be Co-Ordinated. |
Medium Green
Background, with Dark Green Fonts.
This repeater has been Co-Ordinated but
not operational. |
Dark Green
Background, with Light Green fonts.
This Repeater is Co-Ordinated and is yet
operational. |
|
The Light
Orange
|
:
|
Older
Co-Ordinated
Frequency from SERA
|
| 021071-0100's
Plans for Co-Ordination Tables |
021071-010-111
Since
there are no Adjacent Frequencies Co-Ordinated
Repeaters within 200 Miles,
This table is of that Notification. |
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0029.60000_(___._)
|
There are none within 200 Miles
Co-Ordinated
|
| Co-Frequency must be > 100
Miles. |
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0029.62000-(127.3) |
KB8QEU |
Sugarloaf
Branch |
Floyd |
KY |
0.00 |
0.00 |
Analog |
| 0029.62000_(___._) |
--- |
Summersville |
--- |
WV |
108.70 |
--- |
--- |
| 0029.62000_(___._) |
--- |
New
Market |
--- |
TN |
123.50 |
--- |
--- |
| 0029.62000_(___._) |
--- |
Wilkesboro |
--- |
NC |
131.50 |
--- |
--- |
| Adjacent Frequency at 20Kcs. must
be > 25
Miles. |
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0029.64000_(___._) |
--- |
Charleston |
--- |
WV |
73.60 |
--- |
--- |
| 0029.64000_(___._) |
--- |
Greeneville |
--- |
TN |
113.90 |
--- |
--- |
| 0029.64000-(118.8) |
K4MFD |
Greeneville
- Viking Mountain |
Greene |
TN |
114.03 |
180.22 |
Analog |
| 0029.64000-(162.2) |
WV8ZH |
Dry Fork |
Randolph |
WV |
186.14 |
63.85 |
Analog |
021071-010-112
| Adjacent Frequency
at 20Kcs. must be > 25 Miles. |
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0053.09000-(071.9) |
K8QIK |
Lancaster |
Fairfield |
OH |
141.51 |
2.30 |
Analog |
| 0053.09000_(___._) |
--- |
Roanoke
- Poor Mountain
|
Roanoke |
VA |
143.90 |
--- |
--- |
| 0053.09000-(123.0) |
WB8BON |
Roanoke |
Roanoke |
VA |
154.24 |
99.45 |
Analog |
| Co-Frequency must be
> 100 Miles. |
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0053.11000-(127.3) |
KB8QEU |
Sugarloaf
Branch |
Floyd |
KY |
0.00 |
0.00 |
Analog |
| 0053.11000-(103.5) |
N8ZAR |
Buckhannon |
Upshur |
WV |
162.50 |
54.92 |
Analog |
| 0053.11000-(082.5) |
W4GR |
Lawrenceville |
Gwinnett |
GA |
266.70 |
196.02 |
Analog |
| Adjacent Frequency at 20Kcs. must be
> 25 Miles. |
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0053.13000_(___._) |
--- |
Wharton |
--- |
WV |
65.20 |
--- |
--- |
| 0053.13000_(___._) |
--- |
Lawrenceburg |
--- |
KY |
120.30 |
--- |
--- |
| 0053.13000-(100.0) |
W4FOT |
Hendersonville |
Henderson |
NC |
163.16 |
175.14 |
Analog |
021071-010-113
| djacent Frequency at
15Kcs. must be > 50 Miles. |
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0146.71500-(103.5) |
W8SOE |
Chesapeake |
Lawrence |
OH |
54.18 |
14.42 |
Analog |
| 0146.71500_(___._) |
--- |
Mount
Vernon |
--- |
KY |
83.60 |
--- |
--- |
| 0146.71500-(100.0) |
KF4OFT |
Berea |
Madison |
KY |
87.40 |
265.91 |
Analog |
| 0146.71500_(___._) |
--- |
Blacksburg |
--- |
VA |
126.80 |
--- |
--- |
| Adjacent Frequency
at 10Kcs. must be > 50 Miles. |
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0146.72000-(100.0) |
K8RPT |
Ida |
Monroe |
MI |
296.97 |
351.34 |
Analog |
| Co-Frequency must be
> 100 Miles. |
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0146.73000-(127.3) |
KB8QEU |
Sugarloaf
Branch |
Floyd |
KY |
0.00 |
0.00 |
Analog |
| 0146.73000-(162.2) |
N1DJS |
Georgetown |
Brown |
OH |
105.18 |
322.16 |
Analog |
| 0146.73000_(___._) |
--- |
Lewisburg |
--- |
WV |
109.60 |
--- |
--- |
| 0146.73000-(100.0) |
KC8CSE |
Alderson
- Keeney Knob
- Keeney Mountain
|
Summers |
WV |
113.02 |
87.39 |
Analog |
| 0146.73000-(118.8) |
WB4GBI |
Newport
- English Mountain |
Cocke |
TN |
126.30 |
195.18 |
Analog |
| 0146.73000_(___._) |
--- |
Newport |
--- |
TN |
126.50 |
--- |
--- |
| 0146.73000-(077.0) |
W8OG |
Springfield |
Clark |
OH |
166.89 |
339.48 |
YSF |
| Adjacent Frequency at 10Kcs.
>must be >
50 Miles. |
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0146.74000-(100.0) |
KJ4LEL |
Rogersville |
Lauderdale |
AL |
322.73 |
233.83 |
Analog |
| Adjacent Frequency
at 15 must be > 50 Miles. |
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0146.74500_(___._) |
--- |
Madison |
--- |
WV |
56.90 |
--- |
--- |
| 0146.74500-(None
) |
K8HO |
Elm Grove |
Pike |
OH |
98.42 |
345.53 |
Analog |
| 0146.74500-(114.8) |
W8TAP |
Constitution
- WTAP tower |
Washington |
OH |
131.62 |
27.62 |
Analog |
| 0146.74500_(___._) |
--- |
Roanoke
- Poor Mountain
|
Roanoke |
VA |
143.70 |
--- |
--- |
| 0146.74500-(094.8) |
KC4QPR |
Morganton
- Walker Top Mountain |
Burke |
NC |
150.48 |
158.37 |
Analog |
| 0146.74500-(107.2) |
K1GG |
Roanoke
- Poor Mtn |
Roanoke |
VA |
154.24 |
99.45 |
Analog |
021071-010-114
| Adjacent Frequency
at 20Kcs. must be > 25 Miles. |
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0224.88000_(___._) |
--- |
Elizabethton |
--- |
TN |
91.00 |
--- |
--- |
| 0224.88000-(None
) |
K4LNS |
Elizabethton |
Carter |
TN |
95.36 |
163.18 |
Analog |
| 0224.88000_(___._) |
--- |
Somerset |
--- |
KY |
111.40 |
--- |
--- |
| 0224.88000-(None
) |
N4AI |
Somerset |
Pulaski |
KY |
111.70 |
249.63 |
Analog |
| Co-Frequency must be
> 100 Miles. |
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0224.90000-(127.3) |
KB8QEU |
Sugarloaf
Branch |
Floyd |
KY |
0.00 |
0.00 |
Analog |
| 0224.90000-(100.0) |
W4WC |
Greeneville |
Greene |
TN |
104.41 |
183.83 |
Analog |
| 0224.90000-(127.3) |
K5VOM |
Winchester |
Randolph |
IN |
206.65 |
323.97 |
Analog |
| <Adjacent Frequency at 20Kcs.
must be > 25 Miles. |
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0224.92000-(114.8) |
KF8YO |
Minford |
Scioto |
OH |
79.88 |
349.27 |
Analog |
| 0224.92000_(___._) |
--- |
Hartford |
--- |
TN |
127.00 |
--- |
--- |
021071-010-115
Adjacent Frequency at 25 is
not regulated.
However, here is the table for information,
only. |
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0442.87500_(___._) |
--- |
Johnson
City |
--- |
TN |
77.20 |
--- |
--- |
| 0442.87500+(100.0) |
AE4BT |
Johnson City |
Washington |
TN |
94.61 |
167.66 |
Analog |
| 0442.87500_(___._) |
--- |
Alderson |
--- |
WV |
109.40 |
--- |
--- |
| Aadjacent
Frequency at 12.5Kcs must be > 50
Miles. |
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0442.88250+(___._) |
--- |
None within 600 Miles |
--- |
--- |
0.00 |
--- |
--- |
| Co-Frequency must be
> 75 Miles. |
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0442.90000+(123.7) |
KB8QEU |
Sugarloaf
Branch |
Floyd |
KY |
0.00 |
0.00 |
Analog |
| 0442.90000+(077.0) |
KI4FRJ |
London |
Laurel |
KY |
84.40 |
244.13 |
YSF |
| 0442.90000_(___._) |
--- |
London |
--- |
KY |
89.40 |
--- |
--- |
| 0442.90000_(___._) |
--- |
UNICOI |
--- |
TN |
102.60 |
--- |
--- |
| 0442.90000+(100.0) |
WB4IXU |
Erwin |
Unicoi |
TN |
103.84 |
168.95 |
Analog |
| 0442.90000+(
CC07) |
W8JL |
Marietta |
Washington |
OH |
138.43 |
28.88 |
DMR |
| 0442.90000_(___._) |
--- |
Floyd |
--- |
VA |
141.10 |
--- |
--- |
| 0442.90000+(114.8) |
W4FCV |
Floyd
- Floyd School
Adminstrations
Offices |
Floyd |
VA |
142.06 |
111.01 |
YSF |
| 0442.90000+(067.0) |
NA6Q |
Clarksville |
Hamilton |
IN |
172.04 |
285.54 |
Analog |
| Adjacent
Frequency at 12.5Kcs must be > 50
Miles. |
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0442.91250+(
CC01) |
K4OZE |
Bethpage |
Sumner |
TN |
213.50 |
248.23 |
DMR |
Adjacent Frequency at
25Kcs, is not regulated.
However,
here is the table for information, only. |
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0442.92500+(103.5) |
N2UGA |
Newport
- Halls Top |
Cocke |
TN |
120.73 |
192.91 |
Analog |
| 0442.92500_(___._) |
--- |
Newport |
--- |
TN |
122.00 |
--- |
--- |
| 0442.92500_(___._) |
--- |
Bent
Mountain |
--- |
VA |
148.00 |
--- |
--- |
| 0442.92500+(107.2) |
W4KZK |
Bent Mountain
- Slings Gap |
Roanoke |
VA |
154.24 |
99.45 |
Analog |
021071-010-116
Adjacent Frequency
at 25Kcs, is not regulated.
However, here is the table for information,
only. |
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0927.57500-(131.8) |
K9NZF |
Lynn |
Randolph |
IN |
203.89 |
324.54 |
Analog |
| Ajacent
Frequency at 12.5Kcs must be > 50 Miles. |
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0927.58750-(131.8) |
KA8ZNY |
Jersey |
Licking |
OH |
164.91 |
359.68 |
P-25 |
Co-Frequency must > 75 Miles.
|
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0927.60000-(127.3) |
KB8QEU |
Sugarloaf
Branch |
Floyd |
KY |
0.00 |
0.00 |
Analog |
| 0927.60000_(___._) |
--- |
Bent
Mountain |
--- |
VA |
148.10 |
--- |
--- |
| Adjacent
Frequency at 12.5Kcs must be > 50
Miles. |
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0927.61250_(___._) |
--- |
Mooresburg |
--- |
TN |
92.80 |
--- |
--- |
| 0927.61250-(114.8) |
KE4KQI |
Mooresburg |
Hawkins |
TN |
95.94 |
197.65 |
Analog |
| 0927.61250-(118.8) |
K4KAY |
Charlotte |
Mecklenburg |
NC |
198.18 |
147.91 |
Analog |
Adjacent Frequency
at 25Kcs, is not regulated.
However, here is the table for information,
only |
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0927.62500-(None
) |
N4GJF |
Buford |
Gwinnett |
GA |
256.00 |
196.89 |
Analog |
021071-010-713
| AdjacentFrequency at
20Kcs. must
be >
25 Miles. |
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0145.22000_(___._) |
--- |
London |
--- |
KY |
83.30 |
--- |
--- |
| Adjacent Frequency
at 10Kcs. must be > 50 Miles. |
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0145.23000_(___._) |
--- |
Beckley/oak
Hill |
--- |
WV |
78.60 |
--- |
--- |
| 0145.23000-(100.0) |
N8FWL |
Lick Knob
- Paint Mountain
– Kingston |
Raleigh |
WV |
78.77 |
75.44 |
P-25 |
| 0145.23000_(___._) |
--- |
KNOXVILLE |
--- |
TN |
120.10 |
--- |
--- |
| 0145.23000-(103.5) |
W4KEV |
Knoxville
- WIMZ Tower |
Knox |
TN |
135.98 |
210.01 |
Analog |
| Co-Frequency must
be >
100 Miles. |
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
0145.24000+(None
)
|
KB8QEU |
Sugarloaf
Branch |
Floyd |
KY |
0.00 |
0.00 |
P-25
|
| 0145.24000+(None
) |
KJ4MKV |
Little Mountain |
Newberry |
SC |
251.51 |
162.89 |
DStar |
| Adjacent Frequency at 10Kcs.must
be > 50 Miles. |
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0145.25000_(___._) |
--- |
Bluefield |
--- |
VA |
84.80 |
--- |
--- |
| 0145.25000_(___._) |
--- |
Gray |
--- |
TN |
87.20 |
--- |
--- |
| 0145.25000-(None
) |
WM4T |
Gray |
Washington |
TN |
87.35 |
171.59 |
YSF |
| 0145.25000-(110.9) |
AD4YJ |
Lexington |
Fayette |
KY |
101.47 |
285.20 |
Analog |
| 0145.25000_(___._) |
--- |
Lexington |
--- |
KY |
101.60 |
--- |
--- |
| 0145.25000-(162.2) |
KB8CWC |
Blanchester |
Clinton |
OH |
132.04 |
328.66 |
Analog |
| 0145.25000-(
CC07) |
AC8GI |
Thornville |
Licking |
OH |
154.80 |
5.62 |
DMR |
| Adjacent Frequency at 20Kcs.
must be >
25 Miles. |
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0145.26000-(None
) |
KK4CWX |
Oneonta
- Straight Mountain |
Blount |
AL |
332.93 |
220.50 |
YSF |
021071-010-813
| Adjacent
Frequency at 20Kcs. must be > 25 Miles. |
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0145.00000x(None
) |
AG4NX |
Adamsville |
Hardin |
TN |
353.35 |
243.86 |
Analog |
| >Co-Frequency must be
> 100 Miles. |
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
0145.02000+(None
)
|
KB8QEU |
Sugarloaf
Branch |
Floyd |
KY |
0.00 |
0.00 |
DMR |
| 0145.02000+(None
) |
KK4VQG |
Caryville |
Campbell |
TN |
128.11 |
222.76 |
DStar |
| 0145.02000+(None
) |
KI4GOM |
Waleska
- Pine Log Mountain
|
Berrien |
GA |
253.79 |
204.58 |
DStar |
| Adjacent
Frequency at 20Kcs. must be > 25
Miles. |
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0145.04000_(___._) |
--- |
3106
Green Top Road. |
--- |
TN |
138.90 |
--- |
--- |
| 0145.04000+(
CC01) |
KD4CWB |
Knoxville
- Bluff Mountain\ |
Sevier |
TN |
142.92 |
205.98 |
DMR |
021071-010-815
Adjacent Frequency at 25Kcs,
is not regulated.
However,
here is the table for information, only.
|
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0444.92500_(___._) |
--- |
Olive
Hill |
--- |
KY |
51.50 |
--- |
--- |
| 0444.92500+(146.2) |
N8MDG |
Constitution
- On the WTAP tower |
Washington |
OH |
131.77 |
27.87 |
Analog |
| Adjacent
Frequency at 12.5Kcs must be > 50
Miles.
|
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0444.93750_(___._) |
--- |
Gray |
--- |
KY |
85.60 |
--- |
--- |
| 0444.93750+(097.4) |
W8VFR |
Eaton |
Preble |
OH |
177.31 |
324.61 |
Analog |
| Co-Frequency
must be >75 Miles. |
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0444.95000+(127.3) |
KB8QEU |
Sugarloaf
Branch |
Floyd |
KY |
0.00 |
0.00 |
DMR |
| 0444.95000+(103.5) |
KK4RID |
Clinchco
- Hale Mountain |
Dickenson |
VA |
39.96 |
151.48 |
Analog |
| 0444.95000_(___._) |
--- |
Clincho |
--- |
VA |
42.00 |
--- |
--- |
| 0444.95000_(___._) |
--- |
SouthCharleston |
--- |
WV |
70.00 |
--- |
--- |
| 0444.95000+(203.5) |
WB8CQV |
Charleston |
Kanawha |
WV |
75.07 |
50.86 |
Analog |
| 0444.95000_(___._) |
--- |
Lexington |
--- |
KY |
95.80 |
--- |
--- |
| 0444.95000+(088.5) |
KK4PQU |
Lexington |
Fayette |
KY |
101.47 |
285.20 |
Analog |
| 0444.95000_(___._) |
--- |
Jefferson
City |
--- |
TN |
119.20 |
--- |
--- |
| 0444.95000+(131.8) |
W8SAI |
Mason |
Warren |
OH |
145.62 |
323.91 |
Analog |
| 0444.95000+(None
) |
W8TJT |
Zanesville |
Muskingum |
OH |
161.44 |
13.16 |
Analog |
| Adjacent
Frequency at 12.5Kcs must be > 50
Miles.
|
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0444.96250+(
CC01) |
KG4LHQ |
Owensboro |
Daviess |
KY |
241.46 |
272.61 |
DMR |
| 0444.96250+(None
) |
K8BTP |
Salem |
Columbiana |
OH |
244.43 |
23.31 |
Analog |
Adjacent Frequency at 25Kcs,
is not regulated.
However,
here is the table for information, only.
|
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
| 0444.97500_(___._) |
--- |
Ashland |
--- |
KY |
53.60 |
--- |
--- |
| 0444.97500_(___._) |
--- |
Morristown |
--- |
TN |
92.80 |
--- |
--- |
| 0444.97500_(___._) |
--- |
Nicholasville |
--- |
KY |
102.00 |
--- |
--- |
| 0444.97500+(None
) |
K4HH |
Nicholasville |
Jessamine |
KY |
103.10 |
278.71 |
YSF |
| 0444.97500_(___._) |
--- |
Pearisburg |
--- |
VA |
105.60 |
--- |
--- |
| 0444.97500+(103.5) |
KD4BNQ |
Pearisburg
- Dismal Peak |
Giles |
VA |
105.67 |
105.47 |
Analog |
| 0444.97500+(141.3) |
KQ4E |
Morristown |
Hamblen |
TN |
105.80 |
198.10 |
YSF |
021071-010-999
This Table is
not really necessary, for SERA has n
ability to co-ordinate 5
Gigacycle band,
it is just
here to inform the interested.
|
| Output±(Tone ) |
COR |
Location |
County |
ST |
RANGE |
Head °
|
Mode |
5825.00000M(None
)
|
KB8QEU |
SugarloafBranch |
Floyd |
KY |
0.00 |
0.00 |
Digital |
|
