Repeater Information
W5UK/R - 444.200 MHz (+ others!)
Our UHF repeater (input 449.200, PL 114.8 Hz) is at a fabulous site at the 500 foot level on the WWL-TV tower in Gretna, La. The tower has full emergency power, and the repeater is housed in an air conditioned rack cabinet on a platform accessible via an elevator which goes up the center of the tower. The repeater now sports a Decibel Products DB-420 folded dipole array meaning that citywide coverage is much improved!
The UHF repeater is a converted Motorola Mitrek
operating with a whopping 20 watts output. But, construction is continuing on a new system that, when
installed, will dramatically increase range and capabilities.
The repeater uses an NHRC-4 controller and
WB2WHC 2-channel voter. Plans are to replace the 2-channel voter and install remote receivers a key locations
around the metro area, affording
excellent coverage throughout the New Orleans region. The
new repeater system will also include a 52.73 MHz receiver and 224.52 MHz
transmitter at the Channel 4 tower, with the 53.73 transmitter in St. Rose and the 222.92 receiver located at an unconfirmed (as yet) location.
When complete, a user will be able to access
the repeater by UHF, 6M or 220 and come out on all of the other frequencies.
The 444.2 machine is RF-linked to the 444.275 KD5QD repeater in Sorrento, LA, which in turn is linked to 443.050 in Port Allen (near Baton Rouge), providing solid communications along much of the N.O.-B.R. I-10 corridor.
And, if that’s not enough…tune-up is complete
on a Repco Dimension repeater crystalled for 443.200 (input
448.200, no PL) which will shortly be at home on the Northshore.
STAY TUNED FOR UPDATES!
Click here for tower site photos!
Thanks
to
for the excellent facilities!
W5UK-9 - 144.39 MHz
The W5UK-10 dedicated APRS digipeater operated flawlessly for the last several years until power supply problems knocked it off. A new APRS digi, W5UK-9, uses an MFJ-1270C TNC (with PacComm eprom) to a Motorola Mitrek feeding a multiband antenna at 500 feet. W5UK-9 operates as a wide area digipeater and regularly receives mobiles and relays from Mississippi, Alabama and Florida. This system operates with full back-up battery power.
WB5LLI/R - 53.130 MHz
This repeater is maintained by GNOARC members, and was licensed to the late Hank Arsaga, W5VAS, now sadly a Silent Key. This 6 meter repeater is currently on the air from a 225 foot high location in St. Rose, La. The input frequency is down 1 MHz, at 52.130. We are in the process of changing frequencies (planned--53.73 MHz), and as mentioned elsewhere, this repeater will be linked to 444.200. Six meter FM is a lot of fun; if you haven't tried it, c'mon aboard!
