"W4XE Repeater Group"

Green Mtn Repeater System

W4XE Trustee

This is an open repeater system supported by private individuals.

This repeater system is composed of two repeater sites located on a mountain chain east of the city of Huntsville, AL. that runs in a roughly North-South direction. The sites are about 10 miles apart.

The main site 443.625 is NE of HSV on Monte-Sano Mtn, ~1600' above sea level (~600 HATT) and located on a 130' tower. This is a 110W GE Mastr II repeater base station running into a TX/RX duplexor. The controller is a RC-210 supporting cw & digital voice ID. The antenna is an ARX-270 with 1/2" hardline. This site also includes the 440 remote base and an RF link to Echolink.

The secondary site was 444.300 is SE of HSV on Green Mtn, 1350' above sea level (~600' HATT) and located on a 50' tower. This was a commerical GE Mstr II 100W repeater with ACC RC-96 and autopatch. This repeater is currently down for upgrades.

The machines both enjoy a 50 mile range at the outer limits which includes Alabama coverage of Huntsville, Madison, Decatur, Morgan City, Athens, Scottsboro, Guntersville and across the Tennesse border, 20 miles to our north. Our 2 mtr remote base gives us access to remote cities such as Birmingham, AL and Nashville, TN stations at distances over 100 miles+.

W4XE ã 2007
