(above) A "BEFORE" restoration
pic of an AC-1
(above) Note the different
paint scheme on this AC-1. Instead of the OVAL AMECO logo it
has a cursive version.
(above) Butchered AC-1's are
not unusual. Someone appears to have "redesigned" the
plug-in coil on this one. And what's that gooey white stuff
on the transformer? Ugh.
(above) Kind of a muddy photo, but note the classic EF Johnson two-wire plug in the tube socket |
(Above) Someone's been arc welding on the chassis surface. |
(Above) Chassis repainted and meter hole filled in. Nice key, too. |
(Above) At one point in their production run, Ameco supplied their AC-1 kits with red knobs. |
(Above) AC-1 clone. Ya gotta love it. |
(above) Someone painted this one GREEN! Argh! And look under the chassis. The butchery! |
(above) No, it's not an AC-1 or a clone. It's a MEISSNER NOVICE TRANSMITTER circa 1950's. Could be a 6L6 osc and 6X5 rectifier, or a 5Z3 rectifier and a 6V6 osc. Hard to tell. |
(above) a peek under the hood of K6ESE's "chirp-less" AC-1, modified with OA2 regulator and trimmer cap. Note Sprague "atom" electrolytic, color-coordinated resistors and caps, and flawless wiring. This is a showroom quality rig! |
