Resistor R-332 is selected to set the power output to 100 watts, +/- 1 dB. R-332 may be any one of the following four 1% resistor values:
- 1180 ohm [PN 6-1181-12]
- 1200 ohm [PN 6-122-12]
- 1210 ohm [PN 6-1211-12]
- 1240 ohm [PN 6-1241-12]
Always replace R-332 with a resistor of the same value.
