| Frequency range: | 160 - 80 - 40 - 30 - 20 - 17 - 15 - 12 - 10 m |
| Modes: | SSB / CW |
| Final Power Input: | 220W PEP for SSB and 180W DC for CW |
| Receiver Sensivity: | 0,25 uV at 10 dB S + N/N |
| Receiver Selectivity SSB/CW WIDE: | 2,4 kHZ ( - 6dB ), 3,6 kHz ( -60 dB ) |
| Receiver Selectivity CW NARROW: | With YK-88C ( option ) 500 Hz ( -6dB ), 1,5 kHz ( -60dB ) With YK-88CN ( option ) 270 Hz ( -6dB ), 1,1 kHz ( -60 dB ) |
| Variable Banndwith SSB with 2,4 kHz filter: CW with 500 Hz filter: |
500 Hz ~ 2,4 kHz ( -6dB ) continuously variable 500 Hz ~ 150 Hz ( -6dB ) continuously variable |
| Noch-filter Attenuation: | Better than 40 dB |
