Worldwide packet uplink: 145.990 MHz FM
Region 1 voice uplink: 145.200 MHz FM
Region 2/3 voice uplink: 144.490 MHz FM
Worldwide downlink: 145.800 MHz FM
TNC callsign RS0ISS
The ARISS initial station was launched September 2000 aboard shuttle Atlantis.
ARISS is made up of delegates from major national amateur radio organizations, including AMSAT.
Status: Operational.
The current Expedition 6 crew is:
Commander Ken Bowersox, KD5JBP
Flight Engineer Nikolai Budarin, RV3FB
NASA ISS Science Officer Don Pettit, KD5MDT
Don Petit, KD5MDT has been active on voice.
ARISS International Chairman Frank Bauer, KA3HDO, has requested that amateurs refrain from sending e-mail to the ISS crew via the onboard RS0ISS Personal Message System (PMS). "The crew is not answering the e-mail, and we really don't expect them to. If things change, we'll let you know."
Alain, IZ6BYY and Claudio, IK1SLD wish to announce the opening of the ISS Fan Club
. http://www.issfanclub.comThe ISS Fan Club announces the introduction of the "ISS Achievement Award". Visit http://www.issfanclub.com/iaa
Information on how to access the amateur radio equipment aboard the ISS is available at http://www.marex-na.org/fileshtml/unprotopage.html
The ISS daily crew schedule can be found at http://spaceflight.nasa.gov/station/timelines/. When crew members have free time, they may be available for amateur radio operations.
U.S. callsign: NA1SS
Russian callsigns: RS0ISS, RZ3DZR
The QSL routes for stations working the International Space Station (all callsigns):
| U.S stations: | Margie Bourgoin KB1DCO Attn: ARISS Expedition-1 (or 2, 3, etc.) QSL ARRL, 225 Main Street Newington, Connecticut 06111 |
SASE required |
| Canadian stations: | Radio Amateurs of Canada Attn: ARISS Expedition-1 (or 2, 3, etc.) QSL 720 Belfast Road, Suite 217 Ottawa, Ontario K1G 0Z5 |
|
| European stations: | AMSAT-France 16, rue de la Vallee 91360 Epinay sur Orge, France |
SASE and 2 IRC's required |
[ANS thanks Will Marchant, KC6ROL, and Jean-Louis Rault, F6AGR, for this information]
Uplink: 145.850 to 145.950 MHz CW/USB
432.125 to 432.175 MHz CW/LSB
Downlink: 29.400 to 29.500 MHz CW/USB
145.975 to 145.925 MHz CW/USB
Beacon: 29.502 MHz, 145.972 MHz, 435.1 MHz, 2304.1 MHz
Launched: November 15, 1974 by a Delta 2310 from Vandenberg Air Force Base, Lompoc,
California.
Status: Semi-operational in sunlight.
After being declared dead 21 years ago in mid 1981 due to battery failure, AO-7 has miraculously sprung back to life and was first detected by Pat Gowen, G3IOR on June 21, 2002 at 1728 UTC. Jan King, W3GEY reports AO-7 is running off the solar panels only. It will only be on when in sunlight and off in eclipse. Therefore, AO-7 will reset each orbit and may not turn on each time.
On July 11, 2002 AO-7 was successfully commanded for the first time since it was declared dead 21 years ago. Commands were sent and accepted to change the CW beacon code speed.
Command investigation continues. So far, 11 different commands have been accepted by AO-7.
Yoshi Imaishi, JF6BCC is compiling an excellent list of observations. Please send him whatever you have. [email protected]
You can view the list at http://plaza16.mbn.or.jp/~palau/temp/AO7-mode-report.xls
Tim, K3TZ has written a program to decode AO-07 telemetry. The program can be downloaded at http://www.qsl.net/k3tz/files/K3TZ_AO-07_Telemetry_Decoder_0.5.zip
For more info: http://www.amsat.org/amsat/sats/n7hpr/ao7.html
[ANS thanks Pat Gowen, G3IOR and Jan King, W3GEY for this information]
Stacey Mills, W4SM, has more information about the satellite at http://www.cstone.net/~w4sm/AO-10.html
[ANS thanks Stacey Mills, W4SM, for his AO-10 status information and web site]
Uplink 145.975 MHz FM
Downlink 435.070 MHz FM
Launched January 22, 1990 by an Ariane launcher from Kourou, French Guiana
Operational.
John, K6YK reports that VP5/W6XK (Turks and Caicos, grid FL41) is active until January 7.
Tim, KG8OC, features UO-14 information on the Michigan AMSAT web site, see http://www.qsl.net/kg8oc
Ray, W2RS, has revised the AO-27 FAQ on http://www.amsat.org/amsat/intro/ao27faq.html to include information on UO-14.
Ramon, VE7RKK was active from TF, Iceland and OX, Greenland.
[ANS thanks Chris Jackson, G7UPN / ZL2TPO, for UO-14 information]
Uplink 145.858 to 145.898 MHz CW/USB
Downlink 29.354 to 29.394 MHz CW/USB
Beacon 29.352 MHz (intermittent)
SSB meeting frequency 29.380 MHz (unofficial)
Launched December 26, 1994 from the Baikonur Cosmodrome
Semi-operational, Mode A (2m uplink, 10m downlink)
Dave, WB6LLO, has operating information for both RS-15 and RS-13 on his personal web site. In addition to satellite data, antenna information for mode A operation is also featured. The WB6LLO web site URL is http://home.san.rr.com/doguimont/uploads
Uplink 145.900 to 146.000 MHz CW/LSB
Downlink 435.800 to 435.900 MHz CW/USB
Beacon: 435.795 MHz
Launched February 7, 1990 by an H1 launcher from the Tanegashima Space Center in Japan
Operational.
FO-20 is in mode JA continuously.
Tak, JA2PKI, reported FO-20 control station operators believe that the UVC (Under Voltage Controller) is now regulating the transponder. The controller monitors battery voltage and tries to protect the batteries from over discharge.
[ANS thanks Kazu Sakamoto, JJ1WTK for the FO-20 status reports]
Beacon: 145.828, 435.319 MHz
Launched: November 28, 2002 aboard a Kosmos 3-M rocket from Plesetsk.
Status: Telemetry heard on the 70 cm beacon.
RS-20 is an experimental payload aboard the Russian satellite known as Mozhayets -- a navigational and scientific satellite. RS-20 transmits CW telemetry. Each frame begins and ends with the call sign RS-20.
Table for decoding telemetry is as follows:
Name Limits Decoding Assignment
RS 20 The callsign UBS N=100:170 U=N / 10 Volts On board voltage IBS N=10:250 I=N / 100 Ampers On board current USUN N=0:180 U=N / 10 Volts Charge voltage from solar battery ISUN N=0:180 I=N / 100 Ampers Charge current from solar battery ITXA N=0:170 I=N / 100 Ampers D.C. current of the 435 MHz Tx PTXA N=0:70 P=N / 10 Watts UHF power of the 435 MHz Tx TTXA N=50:190 T=N - 100 deg C Temperature of the 435 MHz Tx ITXB N=0:150 I=N / 100 Ampers D.C. current of the 145MHz Tx PTXB N=0:70 P=N / 10 Watts VHF power of the 145MHz Tx TTXB N=50:190 T=N - 100 deg C Temperature of the 145MHz Tx TEXT N=30:250 T=N - 100 deg C Temperature of the outer case TINT N=30:190 T=N - 100 deg C Temperature of the inner case TOR N=10:250 T=N - 100 deg C Temperature of the Earth sensor UOR N=0:100 U=N / 10 Volts Temperature of the Sun sensor MTX N=0:255 Table of operational modes. The housekeeping info. MRX N=0:255 Table of operational modes. The housekeeping info. RS 20 The callsign
Please send reception reports to [email protected] or [email protected]
[ANS thanks Alexander N. Zaitzev, RW3DZ for this information]
Uplink 145.850 MHz FM
Downlink 436.795 MHz FM
Launched September 26, 1993 by an Ariane launcher from Kourou, French Guiana
Operational, mode J.
January 4th, 2003
The TEPR states have been reprogrammed for more normal operations instead of the battery
saving mode that we have been running in for the last few months. As of Jan 3rd, the
batteries are looking good.
Jeff, KB2M reported on 01/04/03 that AO-27 is back on the air.
The latest information on AO-27 from control operator Michael Wyrick, N3UC (former N4USI), can be found at http://www.ao27.org
An AO-27 question-and-answer page is available on the AMSAT-NA web site, with updates by Ray, W2RS: http://www.amsat.org/amsat/intro/ao27faq.html.
[ANS thanks AMRAD for AO-27 information]
Mineo, JE9PEL, has an FO-29 satellite telemetry analysis program that will automatically analyze all digital telemetry from the satellite (such as current, voltage and temperature). FO29CWTE is available at
http://www.ne.jp/asahi/hamradio/je9pel/[ANS thanks Kazu Sakamoto, JJ1WTK, for the FO-29 status reports]
Uplink 145.850 MHz
Downlink 436.775 MHz
Broadcast Callsign SASAT1-11
BBS SASAT1-12
Launched: September 26, 2000 aboard a converted Soviet ballistic missile from the Baikonur
Cosmodrome.
Operational but intermittent
The spacecraft is operating in Mode J, currently configured as an analog FM voice repeater, as power and spacecraft experiments permit.
Further information is available at http://www.amsat.org/amsat/sats/n7hpr/so41.html
[ANS thanks Turki Al-Saud for this information]
Uplink: 145.850 MHz (67.0 Hz PL tone)
Downlink: 436.775 MHz
Launched: December 20, 2002 aboard a converted Soviet ballistic missile from the Baikonur
Cosmodrome.
Status: Operational.
SaudiSat-1C carries several experiments, including a new mode J FM amateur repeater experiment operating on 145.850 MHz uplink and 436.800 MHz downlink. The repeater is available to amateurs worldwide as power permits, using a 67.0 Hertz tone on the uplink, for on-demand activation.
For tracking, the TLE for NORAD #27607 (CELESTRAK: PAYLOAD C) is recommended.
[ANS thanks Turki Al-Saud for this information]
Downlink 145.826 MHz FM, 1200 baud PSK
Beacon 2401.500 MHz
Launched March 1, 1984 by a Delta-Thor rocket from Vandenberg Air Force Base in California
Semi-operational.
OSCAR-11 is currently operating in a default mode, controlled by the watch-dog timer. The satellite transmits continuous ASCII telemetry for about seven days on 145.826 MHz, followed by about 14 days of silence. The mode-S beacon on 2401.500 MHz is ON continuously.
At the present time, ground control are unable to command the satellite, due to low temperatures affecting the command decoder. They will attempt to command the satellite when the command decoder temperature has risen to 15C.
The following operating schedule is currently suspended.
ASCII status (210 seconds)
ASCII bulletin (60 seconds)
BINARY SEU (30 seconds)
ASCII TLM (90 seconds)
ASCII WOD (120 seconds)
ASCII bulletin (60 seconds)
BINARY ENG (30 seconds)
The ASCII bulletin is currently a static message, detailing modes and frequencies of all the amateur radio satellites.
More information on OSCAR-11 is available at http://www.users.zetnet.co.uk/clivew/
[ANS thanks Clive Wallis, G3CWV, for OSCAR-11 status information]
Uplink 145.900, 145.920, 145.940, 145.960 MHz FM,
1200 bps Manchester FSK
Downlink 437.025 MHz SSB, 1200 bps RC-BPSK 1200 Baud PSK
Beacon 2401.1428 MHz.
Broadcast callsign: PACSAT-11
BBS: PACSAT-12
Launched January 22, 1990 by an Ariane launcher from Kourou, French Guiana
Semi-operational. Digipeater on.
A WOD collection of current graphics along with general information and telemetry samples can be found at http://www.telecable.es/personales/ea1bcu
[ANS thanks Miguel A. Menendez, EA1BCU, for AO-16 status information.]
Uplink 145.900 MHz FM
Downlink 435.120 MHz FM 9600 Baud FSK
Broadcast callsign: UOSAT5-11
BBS: UOSAT5-12
Launched July 17, 1991 by an Ariane launcher from Kourou, French Guiana
Operational
On November 21, 2002 Chris Jackson, G7UPN reported:
UO-22 is operating OK at the moment. Some new software has been loaded to try and keep the downlink operating most of the time. It seems that after around 60000 charge/discharge cycles the Nicad batteries are starting to show their age!
The downlink will be switched off from time to time over certain parts of the globe. This is required to allow the attitude control system to operate correctly since the power system cannot supply enough power to support both the transmitter and the magnetorquers.
More information on the satellite is available at http://www.sstl.co.uk/
[ANS thanks Chris Jackson, G7UPN/ZL2TPO, for UO-22 information and Jim Weisenberger, AA7KC, for status information]
Uplink 145.875, 145.900, 145.925, 145.950 MHz FM
Downlink 435.812 MHz SSB, 1200 Baud PSK
Broadcast callsign: ITMSAT-11
BBS: ITMSAT-12
Launched September 26, 1993 by an Ariane launcher from Kourou, French Guiana
Semi-operational.
Digipeater function is on, open for APRS users.
On November 18, 2002 Alberto, IK2BD reported:
The current configuration of IO-26 allows only limited telemetry in MBL (safe) mode. To enable full telemetry and digipeating, we must re-load the full IHT high level software suite. This was delayed several times, but we plan to do that in the near future. When the IHT code is running, the bulletin will announce that.
[ANS thanks ITAMSAT Project Manager Alberto E. Zagni, I2KBD, for this information]
Uplink/downlink 145.827 MHz 1200 baud AX-25 AFSK via W3ADO-1
Aux/Uplink 435.250 MHz 9600 baud via PCSAT (off)
APRS Downlink 144.390 MHz (Region 2)
Launched: September 30, 2001 aboard an Athena-1 rocket from the
Kodiak Alaska launch complex.
Status: Operational
PCSat is a 1200-baud APRS digipeater designed for use by stations using hand-held or mobile transceivers. Downlinks feed a central web site http://pcsat.aprs.org. The APRS-equipped PCSat was built by midshipmen from the U.S. Naval Academy under the guidance of Bob Bruninga, WB4APR.
A new version of PCSAT.EXE has been posted at ftp://tapr.org/dosstuff/APRSdos/pcsat017.zip
For more information, visit the PCSat web site at http://web.usna.navy.mil/~bruninga/pcsat.html
[ANS thanks Bob Bruninga, WB4APR, for PCSat information]
Uplink 145.850 or 145.925 MHz 9600 baud FSK
Downlink 437.325 MHz
Broadcast callsign: MYSAT3-11
BBS: MYSAT3-12
NUP: MYSAT3-10
Launched September 26, 2000 aboard a converted Soviet ballistic missile from the Baikonur
Cosmodrome
Status: Operational at 38k4 baud FSK
TiungSat-1 is Malaysia's first micro-satellite and in addition to commercial land and weather imaging payloads will offer FM and FSK amateur radio communication.
TiungSat-1, named after the mynah bird of Malaysia, was developed as a collaborative effort between the Malaysian government and Surrey Satellite Technology Ltd.
Uplink 435.275 1200-baud AX.25
Downlink 145.825 9600-baud AX.25
(optional voice message)
Broadcast callsign: DP0AIS
Launched: December 20, 2002 aboard a converted Soviet ballistic missile from the Baikonur
Cosmodrome.
Status: Operational.
SAFIR-M is a German amateur radio payload onboard the small German scientific satellite "RUBIN-2".
SAFIR-M was built by the German amateur radio association "AATiS e.V." (German acronym for "Arbeitskreis Amateurfunk und Telekommunikation in der Schule", which means: 'working group for amateur radio and telecommunications in schools').
SAFIR-M is designed as a "store and broadcast" system for APRS based messages, dedicated for the use of schools in combination with the existing WX-Net and planned buoy experiments in Germany.
Following listener reports and analysis, the TLE for NORAD #27605 (CELESTRAK: PAYLOAD A) is recommended.
The analysis of a recorded WAV file of a pass over Germany from 24.12.2002, 05:38 - 05:40 UTC shows unexpected effects:
a) The TX clock rate of the SAFIR-M 9k6 modem seems to have 9844 baud instead of expected 9600 baud. Reception of frames may be still possible with high RX field strength so that the DPLL of the ground equipment can lock within its tolerance range.
b) Additionally, it seems that the data line for bit 0 to the external memory of the PIC is stuck at "0", so that the parts of the transmitted MH frames could be damaged. CRC, NRZI, stuffing and scrambling are done correctly from the faulty data source.
For further examination, Martin DG8UAU has written a small software "SAFIR-M Decoder" (28 KB) to allow decoding of the received DATA0 frames. It is available at
http://amend.gmxhome.de in the section Aktuelles.Details on SAFIR-M can be found at
http://amend.gmxhome.de.
Information about AATiS e.V. is available at
http://www.aatis.de
[ANS thanks Oliver Amend, DG6BCE for this information]
Uplink 145.840, 145.860, 145.880,
145.900 MHz 1200 bps Manchester FSK
Downlink 437.150 MHz SSB, 1200 bps RC-BPSK
CW Downlink 437.125 MHz
Broadcast callsign: LUSAT-11
BBS: LUSAT-12
Launched January 22, 1990 by an Ariane launcher from Kourou, French Guiana
The CW beacon is sending eight telemetry channels and one status channel on 437.126 MHz. No BBS service is available. The digipeater is not active.
General information and telemetry samples can be found at http://www.telecable.es/personales/ea1bcu
[ANS thanks Miguel A. Menendez, EA1BCU, for LO-19 status information.]
Downlink: 435.325, 435.225 MHz FM (9600-baud FSK)
Uplinks: 145.860, 145.880, 145.890, 145.930 FM
Downlink: 435.225 MHz FM (9600-baud FSK)
(435.325 n/a - temperature problems)
Uplinks: 145.850, 145.890, 145.930 FM
1269.700, 1269.800, 1269.900 FM
Broadcast Callsign: 4XTECH-11
BBS Callsign: 4XTECH-12
Launched July 10, 1998 by a Russian Zenit rocket from the Baikonur Cosmodrome
Semi-operational.
As of October 22, 2002 the BBS is running and partially operational. There is a 2 PB user limit. System beacon every 30 seconds. Downlink output power has been reduced to 1 watt.
WinTelem v1.0 - TechSat's telemetry decoding software is now available for amateur use.
For more info check: http://www.iarc.org/techsat/
[ANS thanks Tidhar Teucher, 4Z5CA, and Shlomo Menuhin, 4X1AS for GO-32 status information]
Downlink 437.910 MHz FM 9600 Baud FSK
Launched October 24, 1998 by a Delta 2 rocket from Cape Canaveral in Florida
Semi-operational.
The satellite is not currently available for uplink transmissions and image and transponder recovery efforts have been unsuccessful.
SEDSAT-1 signifies Students for the Exploration and Development of Space (satellite number one).
SedSat-1 has downlinked months worth of telemetry data on the performance of its electrical power system parameters. The Nickel Metal Hydride batteries on the spacecraft were experimental and experienced some abuse due to a power negative situation. This information has provided NASA with useful information. With the exception of the imaging system and the use of the transponders, SedSat-1 has been judged a success.
For more information on SedSat-1 visit the satellite web site at http://www.seds.org/sedsat
ANS has no further information.
Uplink 21.210 to 21.250 MHz CW/USB
Downlink 29.410 to 29.450 MHz CW/USB
Beacon 29.408 MHz
Robot 29.454 MHz
Launched February 5, 1991 aboard a Russian Cosmos C launcher
Non-operational.
Hams reporting to the RS-12/13 Forum from across the US and Europe have stated that they have not been able to hear any beacons from either the RS-12 or RS-13 satellite packages since August 20, 2002.
Jerry, K5OE reports the following:
I recently queried several of my Russian friends and received this response from Oleg, RV3TH, in Nihzni Novgorod:
Yesterday I made a telephone call to my friend from Siberia. He works in one of the checking centres for satellites. He says: "Electronical devices of satellite COSMOS2123 (and RS12/13) perished after superpower protonflashes on the Sun (July/August 2002)" Control devices and receivers perished first, and then a beacon. They have hopes to restore the satellite, but it is very small. Jerry, you can use this information, but it is NON OFFICIAL information. (above paraphrased by N1JEZ)
The latest information on RS-12 and RS-13 can be found on the AC5DK RS-12/13 Satellite Operators page:
http://www.qsl.net/ac5dk/rs1213/rs1213.html
[ANS thanks Kevin Manzer, AC5DK, for RS-12 information]
Uplink 21.260 to 21.300 MHz CW/USB
Downlink 145.860 to 145.900 MHz CW/USB
Beacon 145.860 MHz
Robot 145.908 MHz
Launched February 5, 1991 aboard a Russian Cosmos C launcher
Non-operational.
Hams reporting to the RS-12/13 Forum from across the US and Europe have stated that they have not been able to hear any beacons from either the RS-12 or RS-13 satellite packages since August 20, 2002.
Jerry, K5OE reports the following:
I recently queried several of my Russian friends and received this response from Oleg, RV3TH, in Nihzni Novgorod:
Yesterday I made a telephone call to my friend from Siberia. He works in one of the checking centres for satellites. He says: "Electronical devices of satellite COSMOS2123 (and RS12/13) perished after superpower protonflashes on the Sun (July/August 2002)" Control devices and receivers perished first, and then a beacon. They have hopes to restore the satellite, but it is very small. Jerry, you can use this information, but it is NON OFFICIAL information. (above paraphrased by N1JEZ)
[ANS thanks Kevin Manzer, AC5DK, for this information]
Uplink 145.850, 145.900 MHz FM
Downlink 435.175 MHz FM, 9600 Baud FSK
Broadcast callsign: HL01-11
BBS: HL01-12
Launched August 10, 1992 by an Ariane launcher from Kourou, French Guiana
Status: Non-operational
Jim, AA7KC, reports that KO-23's downlink transmitter continues in a non-operational status.
[ANS thanks Jim Weisenberger, AA7KC, and KyungHee Kim, HL0ENJ, for KO-23 status information]
Uplink 145.980 MHz FM
Downlink 436.500 MHz FM, 9600 Baud FSK
Broadcast callsign: HL02-11
BBS: HL02-12
Launched September 26, 1993 by an Ariane launcher from Kourou, French Guiana
Non-operational.
[ANS thanks Jim Weisenberger, AA7KC, for this information]
Uplink/downlink frequency (listed on the PanSat
web site) 436.500 MHz
Launched October 30, 1998 by the Shuttle Discovery
Status: Telemetry downloads only.
The satellite is not available for general uplink transmissions.
The Naval Postgraduate School developed PanSat. At the time of launch, PanSat spread-spectrum digital transponders were to be available to amateur radio operators along with software to utilize this technology.
The satellite is still operating, however, the spread spectrum packet radio portion never took place. The spacecraft is now beyond it's initial 2-year mission life, but telemetry records are still being downloaded.
For more information, visit the official PANSAT web site at:
http://www.sp.nps.navy.mil/pansat/
PanSat was the featured cover article in the July/August 1999 issue of the AMSAT-NA Journal (written by KD6DRA and N7HPR).
ANS has no further information.
Uplink 145.960 MHz, 9600 baud FSK
Downlink 437.025, 437.400 MHz, 9600 baud FSK
Broadcast callsign: UO121-11
BBS: UO121-12
Launched April 21, 1999 by a Russian launcher from the Baikonur Cosmodrome
Status: Unknown
UO-36 carries a number of imaging payloads, digital store-and-forward communications and mode L/S transponders.
Paul, KB2SHU, tells ANS that UO-36 has not been operational (over North America) since late July 2001. In addition, Sangat, 9M2SS, reports he has not copied UO-36 since July 30, 2001.
Further information on UO-36 is available at http://www.sstl.co.uk/
[ANS thanks Chris G7UPN/ZL2TPO, and the University of Surrey, for this information]
Uplink to be released
Downlink 437.075 MHz
Broadcast Callsign SASAT2-11
BBS SASAT2-12
Launched September 26, 2000 aboard a converted Soviet ballistic missile from the Baikonur
Cosmodrome
Status: Unknown. ANS has received no additional information.
When/if operational, SaudiSat-1B will operate as 9600-baud digital store-and-forward systems as well analog FM repeater mode capability. One of two new ham satellites from the Kingdom of Saudi Arabia built by the Space Research Institute at the King Abdulaziz City for Science and Technology.
Further information is available at http://www.amsat.org/amsat/sats/n7hpr/so42.html
[ANS thanks Turki Al-Saud for this information]
Downlink 437.095 MHz 1200 baud AX-25 AFSK
Uplink 145.945 MHz UI digipeater
Launched: September 30, 2001 aboard an Athena-1 rocket from the Kodiak, Alaska launch
complex.
Status: Non-operational
Student built Sapphire was launched through the U.S. Naval Academy Satellite program. Its primary missions are sensor experiments, a camera, and voice synthesizer. For more information, visit the Sapphire web site at http://students.cec.wustl.edu/~sapphire/sapphire_overview.html
Sample from a satellite track chart
