Ilmari-2003, preparing for final integration:

Return to OH2AUE homepage
Return to OH2Z Ilmari page

 Bulkhead photos:

• box top side bulkhead interface with 2 m crossed dipoles and Mission Abort connectors (SMA)
• closeup photo of the ATV antenna connector on the box bottom side
• box bottom side view with ATV TX Big Wheel assembled
• APRS 45 degree whip antenna at the box corner
• box bottom connectors for 70 cm crossed dipoles and 80 m end fed antenna
• 14 V supply transport and handling connector "Safe"
• 14 V supply test connector "Test"
• 14 V supply flight connector "Arm"

Preliminary balancing:

• preliminary balancing, sensitivity of this simple string hung affair is a few grams at the box outer edge
• the previous photo is of the linear transponder end of the styrofoam box and without IHU & GPS RX
• preliminary balancing photo of the ATV transmitter end of the box, searching for final module locations
