Input: 105 - 125 VAC, 50-60 Hz or 210 - 250 VAC, 50-60 Hz
Output: 13.5 VDC +/- 0.5 VDC.
Regulation: Better than 1% no load to full load at 117 VAC.
Output Current: 20 ampere, full load.
Ripple: Less than 60 mV peak-to-peak at 18A at 117 VAC.
Circuit Breaker: Electronic latching. Factory set at 20A.
Over-Voltage Protection: Trips above 16V output.
Connectors: One 4-pin AMP MATE-N-LOC, two phono jacks for low current.
Size: HWD 5.5" x 7" x 12".
Wt: 15 lbs.
