807B Beer Beam Power Tube
Application
Heater-cathode type used as af power amplifier and modulator and as
rf power amplifier and oscillator (often simultainously). May be used with full input up to 60
MHz. For class C telegraphy operation at 80 MHz, plate voltage and input
should be reduced to 80 % of maximum ratings and beer increased by 15%; at 125 MHz to 55 % with beer at 20%. Class
C telegraphy maximum plate dissapation, CCS 25 Watts, ICAS 30 Watts, BINGE 3 pints. Requires
substantial quantities of beer and a small 5-contact socket and may be operated
in almost any position. Plate shows a rich amber color when tube is operated at maximum
CCS, ICAS or BINGE ratings. Exceeding ratings can cause a malt down.
Mechanical Data
Bulb .......................................... ST-16
Base .......................................... Medium Shell Small 5-Pin
Outline ....................................... 16-2 with enlarged belly
EIEIOA Base ................................... 5AW
Pop Top Cap ................................... Medium
Mounting Position ............................. Upright
Drinking Position .............................. Any
Electrical Data
Heater Characteristics
Heater Voltage ................................ 6.3 Volts
Heater Current ................................ 0.9 Amperes
Maximum Heather-Cathode Voltage
Heater Positive with Respect to Cathode ..... 135 Volts
Heater Negative with Respect to Cathode ..... 135 Volts
Fill Rate ................................... .07 lph
Direct Interelectrode Capacitances (approx)
Pentode
Input ......................................... 12 pf
Output ........................................ 7 pf
Grid to Plate ................................. 0.2 pf
Envelope capacity ............................. 0.2 pints
Maximum Ratings (Design Center Values)
Pentode
Plate Voltage ................................. 750 Volts
Grid No. 2 Supply Voltage ..................... 400 Volts
Grid No. 2 Voltage ............................ 300 Volts
Negative Grid No. 1 Voltage ................... -200 Volts
Plate Dissipation ............................. 30 Watts
Grid No. 2 Dissipation ........................ 3.5 Watts
Cathode Current ............................... 120 Ma.
Alcohol content ............................... 6%
Characteristics and Typical Operation
Class C Amplifier (CCS)
Plate Voltage ................................. 400 Volts
Grid No. 2 Voltage ............................ 250 Volts
Grid No. 2 Dropping Resistor .................. 19K Ohms
Grid No. 1 Voltage ............................ -45 Volts
Peak Grid No. 1 Voltage ....................... 65 Volts
Grid No. 1 Current ............................ 4 Ma.
Plate Current (Zero Signal) ................... 100 Ma.
Grid No. 2 Current (Zero Signal) .............. 8 Ma.
Driving Power ................................. 0.3 Watts
Power Output (approx) ......................... 35 Watts
Beer consumption .............................. .015 pints/watt
Class C Amplifier (CCS)
Plate Voltage ................................. 500 Volts
Grid No. 2 Voltage ............................ 250 Volts
Grid No. 2 Dropping Resistor .................. 31K Ohms
Grid No. 1 Voltage ............................ -45 Volts
Peak Grid No. 1 Voltage ....................... 65 Volts
Grid No. 1 Current ............................ 4 Ma.
Plate Current (Zero Signal) ................... 100 Ma.
Grid No. 2 Current (Zero Signal) .............. 8 Ma.
Driving Power ................................. 0.3 Watts
Power Output (approx) ......................... 32 Watts
Beer consumption .............................. .011 pints/watt
Class C Amplifier (CCS)
Plate Voltage ................................. 600 Volts
Grid No. 2 Voltage ............................ 250 Volts
Grid No. 2 Dropping Resistor .................. 44K Ohms
Grid No. 1 Voltage ............................ -45 Volts
Peak Grid No. 1 Voltage ....................... 65 Volts
Grid No. 1 Current ............................ 4 Ma.
Plate Current (Zero Signal) ................... 100 Ma.
Grid No. 2 Current (Zero Signal) .............. 8 Ma.
Driving Power ................................. 0.4 Watts
Power Output (approx) ......................... 40 Watts
Beer consumption .............................. .019 pints/watt
Class C Amplifier (ICAS)
Plate Voltage ................................. 750 Volts
Grid No. 2 Voltage ............................ 250 Volts
Grid No. 2 Dropping Resistor .................. 62K Ohms
Grid No. 1 Voltage ............................ -45 Volts
Peak Grid No. 1 Voltage ....................... 65 Volts
Grid No. 1 Current ............................ 4 Ma.
Plate Current (Zero Signal) ................... 100 Ma.
Grid No. 2 Current (Zero Signal) .............. 8 Ma.
Driving Power ................................. 0.3 Watts
Power Output (approx) ......................... 54 Watts
Beer consumption .............................. .025 pints/watt
Class C Modulated Amplifier (CCS)
Plate Voltage ................................. 325 Volts
Grid No. 2 Voltage ............................ 250 Volts
Grid No. 2 Dropping Resistor .................. 12.5K Ohms
Grid No. 1 Voltage ............................ -75 Volts
Peak Grid No. 1 Voltage ....................... 95 Volts
Grid No. 1 Current ............................ 3.5 Ma.
Plate Current (Zero Signal) ................... 80 Ma.
Grid No. 2 Current (Zero Signal) .............. 6 Ma.
Driving Power ................................. 0.3 Watts
Power Output (approx) ......................... 17 Watts
Beer consumption .............................. .010 pints/watt
Class C Modulated Amplifier (CCS)
Plate Voltage ................................. 400 Volts
Grid No. 2 Voltage ............................ 250 Volts
Grid No. 2 Dropping Resistor .................. 25K Ohms
Grid No. 1 Voltage ............................ -75 Volts
Peak Grid No. 1 Voltage ....................... 95 Volts
Grid No. 1 Current ............................ 3.5 Ma.
Plate Current (Zero Signal) ................... 80 Ma.
Grid No. 2 Current (Zero Signal) .............. 6 Ma.
Driving Power ................................. 0.3 Watts
Power Output (approx) ......................... 22 Watts
Beer consumption .............................. .012 pints/watt
Class C Modulated Amplifier (CCS)
Plate Voltage ................................. 475 Volts
Grid No. 2 Voltage ............................ 250 Volts
Grid No. 2 Dropping Resistor .................. 28K Ohms
Grid No. 1 Voltage ............................ -85 Volts
Peak Grid No. 1 Voltage ....................... 108 Volts
Grid No. 1 Current ............................ 4 Ma.
Plate Current (Zero Signal) ................... 83 Ma.
Grid No. 2 Current (Zero Signal) .............. 8 Ma.
Driving Power ................................. 0.4 Watts
Power Output (approx) ......................... 28 Watts
Beer consumption .............................. .014 pints/watt
Class C Modulated Amplifier (Plate - ICAS)
Plate Voltage ................................. 600 Volts
Grid No. 2 Voltage ............................ 300 Volts
Grid No. 2 Dropping Resistor .................. 37.5K Ohms
Grid No. 1 Voltage ............................ -85 Volts
Peak Grid No. 1 Voltage ....................... 107 Volts
Grid No. 1 Current ............................ 4 Ma.
Plate Current (Zero Signal) ................... 100 Ma.
Grid No. 2 Current (Zero Signal) .............. 8 Ma.
Driving Power ................................. 0.4 Watts
Power Output (approx) ......................... 44 Watts
Beer consumption .............................. .023 pints/watt
Push Pull Class AB2 Amplifier (CCS)
Plate Voltage ................................. 400 Volts
Grid No. 2 Voltage ............................ 300 Volts
Grid No. 1 Voltage ............................ -28 Volts
Peak Grid No. 1 Voltage ....................... 80 Volts
Plate Current (Zero Signal) ................... 72 Ma.
Plate Current (Maximum Signal) ................ 240 Ma.
Grid No. 2 Current (Zero Signal) .............. 2 Ma.
Grid No. 2 Current (Maximum Signal) ........... 20 Ma.
Driving Power ................................. 0.2 Watts
Load Resistance ............................... 3.7K Ohms
Power Output (approx) ......................... 55 Watts
Beer consumption .............................. .026 pints/watt
Push Pull Class AB2 Amplifier (CCS)
Plate Voltage ................................. 500 Volts
Grid No. 2 Voltage ............................ 300 Volts
Grid No. 1 Voltage ............................ -30 Volts
Peak Grid No. 1 Voltage ....................... 86 Volts
Plate Current (Zero Signal) ................... 60 Ma.
Plate Current (Maximum Signal) ................ 240 Ma.
Grid No. 2 Current (Zero Signal) .............. 0.9 Ma.
Grid No. 2 Current (Maximum Signal) ........... 20 Ma.
Driving Power ................................. 0.2 Watts
Load Resistance ............................... 4.6K Ohms
Power Output (approx) ......................... 75 Watts
Beer consumption .............................. .045 pints/watt
Push Pull Class AB2 Amplifier (CCS)
Plate Voltage ................................. 600 Volts
Grid No. 2 Voltage ............................ 300 Volts
Grid No. 1 Voltage ............................ -32 Volts
Peak Grid No. 1 Voltage ....................... 80 Volts
Plate Current (Zero Signal) ................... 48 Ma.
Plate Current (Maximum Signal) ................ 200 Ma.
Grid No. 2 Current (Zero Signal) .............. 0.7 Ma.
Grid No. 2 Current (Maximum Signal) ........... 18 Ma.
Driving Power ................................. 0.1 Watts
Load Resistance ............................... 6.9K Ohms
Power Output (approx) ......................... 80 Watts
Beer consumption .............................. .065 pints/watt
Push Pull Class AB2 Amplifier (ICAS)
Plate Voltage ................................. 750 Volts
Grid No. 2 Voltage ............................ 300 Volts
Grid No. 1 Voltage ............................ -35 Volts
Peak Grid No. 1 Voltage ....................... 96 Volts
Plate Current (Zero Signal) ................... 30 Ma.
Plate Current (Maximum Signal) ................ 240 Ma.
Grid No. 2 Current (Zero Signal) .............. 0.55 Ma.
Grid No. 2 Current (Maximum Signal) ........... 10 Ma.
Driving Power ................................. 0.2 Watts
Load Resistance ............................... 6.95K Ohms
Power Output (approx) ......................... 120 Watts
Beer consumption .............................. .12 pints/watt - (have reserve beer on hand)
Push Pull Class B Amplifier
Plate Voltage ................................. 750 Volts
Grid No. 1 Voltage ............................ 0 Volts
Peak Grid No. 1 Voltage ....................... 555 Volts
Plate Current (Zero Signal) ................... 15 Ma.
Plate Current (Maximum Signal) ................ 240 Ma.
Driving Power ................................. 5.3 Watts
Load Resistance ............................... 6.65K Ohms
Power Output (approx) ......................... 120 Watts
Beer consumption .............................. .12 pints/watt - (have reserve beer on hand)
Class AB1 Amplifier
Plate Voltage ................................. 600 Volts
Grid No. 2 Voltage ............................ 300 Volts
Grid No. 1 Voltage ............................ -34 Volts
Peak Grid No. 1 Voltage ....................... 34 Volts
Plate Current (Zero Signal) ................... 18 Ma.
Plate Current (Maximum Signal) ................ 70 Ma.
Grid No. 2 Current (Zero Signal) .............. 0.3 Ma.
Grid No. 2 Current (Maximum Signal) ........... 8 Ma.
Driving Power ................................. 0 Watts
Power Output (approx) ......................... 28 Watts
Beer consumption .............................. .014 pints/watt
Class AB1 Amplifier
Plate Voltage ................................. 750 Volts
Grid No. 2 Voltage ............................ 300 Volts
Grid No. 1 Voltage ............................ -35 Volts
Peak Grid No. 1 Voltage ....................... 35 Volts
Plate Current (Zero Signal) ................... 15 Ma.
Plate Current (Maximum Signal) ................ 70 Ma.
Grid No. 2 Current (Zero Signal) .............. 0.3 Ma.
Grid No. 2 Current (Maximum Signal) ........... 8 Ma.
Driving Power ................................. 0 Watts
Power Output (approx) ......................... 36 Watts
Beer consumption .............................. .018 pints/watt
|
