Yaesu 991A







Menu Settings









  Item Default Settings EZ-Pix Settings for FT8
1 AGC FAST DELAY 300ms 300ms 300ms
2 AGC MID DELAY 700ms 700ms 700ms
3 AGC SLOW DELAY 3000ms 3000ms 3000ms
4 HOME FUNCTION SCOPE SCOPE SCOPE
5 MY CALL INDICATION 1sec 5sec 5sec
6 DISPLAT COLOUR BLUE BLUE BLUE
7 Dimmer LED 2 2 2
8 Dimmer TFT 8 8 8
9 Bar MTR Peak Hold OFF OFF OFF
10 DVS RX Out Level 50 50 50
11 DVS TX Out Level 50 50 50
12 Keyer Type ELEKEY=B ELEKEY=B ELEKEY=B
13 Keyer DOT/DASH NOR NOR NOR
14 CW Weight 3 3 3
15 Beacon Interval OFF OFF OFF
16 Number Style 1290 1290 1290
17 Contest Number 1 1 1
18 CW Memory 1 TEXT TEXT TEXT
19 CW Memory 2 TEXT TEXT TEXT
20 CW Memory 3 TEXT TEXT TEXT
21 CW Memory 4 TEXT TEXT TEXT
22 CW Memory 5 TEXT TEXT TEXT
23 NB Width 3msec 3msec 3msec
24 NB Rejection  30dB 30dB 30dB
25 NB Level 5 5 5
26 BEEP Level 50 50 50
27 Time Zone 00:00 00:00 00:00
28 GPS/232C Select GPS1 GPS1 GPS1
29 232C RATE 4800bps 9600bps 9600bps
30 232C TOT 10msec 10msec 10msec


  Item Default Settings EZ-Pix Settings for FT8
31 CAT RATE 4800bps 9600bps 9600bps
32 CAT TOT 10msec 100msec 100msec
33 CAT RTS ENABLE ENABLE ENABLE
34 MEN GROUP DISABLE DISABLE DISABLE
35 QUICK SPLIT FREQ 5KHz 5KHz 5KHz
36 TX TOT 10min 10min 10min
37 Mic Scan ENABLE ENABLE ENABLE
38 Mic Scan Resume TIME TIME TIME
39 Ref Freq ADJ 0 0 0
40 Clar Mode Select RX RX RX
41 AM LCUT Freq OFF OFF OFF
42 AM LCUT Slope 6dB/oct 6dB/oct 6dB/oct
43 AM HCUT Freq OFF OFF OFF
44 AM HCUT Slope 6dB/oct 6dB/oct 6dB/oct
45 AM Mic Select MIC MIC MIC
46 AM Out Level 50 50 50
47 AM PTT Select DAKY DAKY DAKY
48 AM Port Select DATA DATA DATA
49 AM DATA GAIN 50 50 50
50 CW LCUT Freq 250Hz 250Hz 250Hz
51 CW LCUT Slope 18dB/oct 18dB/oct 18dB/oct
52 CW HCUT 1200Hz 1200Hz 1200Hz
53 CWHCUT Slope 18dB/oct 18dB/oct 18dB/oct
54 CW Out Level 50 50 50
55 CW Auto Mode OFF OFF OFF
56 CW BK-IN Type SEMI SEMI SEMI
57 CW BK-IN Delay 200msec 200msec 200msec
58 CW WAVE Shape 4msec 4msec 4msec
59 CW Freq Display PITCH OFFSE PITCH OFFSE PITCH OFFSE
60 PC Keying OFF OFF OFF


  Item Default Settings EZ-Pix Settings for FT8
61 QSK DELAY TIME 15msec 15msec 15msec
62 DATA MODE PSK OTHERS OTHERS
63 PSK TONE 1000Hz 1500Hz 1500Hz
64 OTHERS DISP (SSB) 0Hz 1500Hz 1500Hz
65 OTHERS SHIFT (SSB) 0Hz 1500Hz 1500Hz
66 DATA LCUT FREQ 300Hz Off Off
67 DATA LCUT Slope 18dB/oct 18dB/oct 18dB/oct
68 DATA HCUT Freq 3000Hz OFF OFF
69 DATA HCUT Slope 18dB/oct 18dB/oct 18dB/oct
70 DATA IN Select REAR REAR REAR
71 DATA PTT Select DAKY RTS RTS
72 DATA PORT Select DATA USB USB
73 DATA OUT LEVEL 50 50 50
74 FM Mic Select MIC MIC MIC
75 FM OUT LEVEL 50 50 50
76 FM PKT PTT Select DAKY RTS RTS
77 FM PKT PORT Select DATA USB USB
78 FM PKT Gain 50 50 50
79 FM PKT Mode 1200 1200 1200
80 RPT Shift 28MHz 100kHz 100kHz 100kHz
81 RPT Shift 50MHz 1000kHz 1000kHz 1000kHz
82 RPT Shift 144MHz 600kHz 600kHz 600kHz
83 RPT Shift 430MHz 5000kHz 1600KHz 1600KHz
84 ARS 144MHz ON ON ON
85 ARS 430MHz ON Off Off
86 DCS Polarity Tn-Rn Tn-Rn Tn-Rn
87 Radio ID GO3xF GO3xF GO3xF
88 GM Display OFF Distance Distance
89 Distance 1 Miles Miles
90 AMS TX Mode Auto Auto Auto




  Item Default Settings EZ-Pix Settings for FT8
91 Standby Beep On On On
92 RTTY Lcut Freq 300Hz 300Hz 300Hz
93 RTTY Lcut Slope 18dB/oct 18dB/oct 18dB/oct
94 RTTY Hcut Freq 3000Hz 3000Hz 3000Hz
95 RTTY Hcut Slope 18dB/oct 18dB/oct 18dB/oct
96 RTTY Shift Port Shift Shift Shift
97 RTTY Polarity-RX NOR NOR NOR
98 RTTY Polarity-TX NOR NOR NOR
99 RTTY Out Level 50 50 50
100 RTTY Shift Freq 179Hz 179Hz 170Hz
101 RTTY Mark Freq 2125Hz 2125Hz 2125Hz
102 SSB Lcut Freq 100Hz 100Hz 100Hz
103 SSB Lcut Slope 6dB/oct 6dB/oct 6dB/oct
104 SSB Hcut Freq 3000Hz 3000Hz 3000Hz
105 SSB Hcut Slope 6dB/oct 6dB/oct 6dB/oct
106 SSB Mic Select Mic Mic Mic
107 SSB Out Level 50 50 50
108 SSB PTT Select DAKY RTS RTS
109 SSB PORT Select DAKY USB USB
110 SSB TX BPF 300-2700 300-2700 300-2700
111 APF Width Medium Wide Wide
112 Controur Level 15 15 15
113 Controur Width 10 10 10
114 IF Notch Width Wide Wide Wide
115 SCP Display Mode Spectrum Water Fall Water Fall
116 SCP Span Freq 100KHz 50KHz 50KHz
117 Spectrum Colour Sky Blue Sky Blue Sky Blue
118 Water Fall Colour Multi Multi Multi
119 Prmtrc Eq1 Freq Off Off Off
120 Prmtrc EQ1 Level 5 5 5


  Item Default Settings EZ-Pix Settings for FT8
121 Prmtrc EQ1 BWTH 10 10 10
122 Prmtrc EQ2 Freq Off Off Off
123 Prmtrc EQ2 Level 5 5 5
124 Prmtrc EQ2 BWTH 10 10 10
125 Prmtrc EQ3 Freq Off Off Off
126 Prmtrc EQ3 Level 5 5 5
127 Prmtrc EQ3 BWTH 10 10 10
128 P-PRMTRC EQ1 FREQ 200 200 200
129 P-PRMTRC EQ1 LEVEL 0 0 0
130 P-PRMTRC EQ1 BWTH 2 2 2
131 P-PRMTRC EQ2 FREQ 800 800 800
132 P-PRMTRC EQ2 LEVEL 0 0 0
133 P-PRMTRC EQ2 BWTH 1 1 1
134 P-PRMTRC EQ3 FREQ 2100 2100 2100
135 P-PRMTRC EQ3 LEVEL 0 0 0
136 P-PRMTRC EQ3 BWTH 1 1 1
137 HF TX MAX POWER 100 100 100
138 50M TX Max Power 100 100 100
139 144M TX MAX POWER 50 50 50
140 430M TX MAX POWER 50 50 50
141 TUNER SELECT INTERNAL INTERNAL INTERNAL
142 VOX SELECT MIC MIC MIC
143 VOX GAIN 50 50 50
144 VOX DELAY  500msec 500msec 500msec
145 ANTI VOX GAIN 50 50 50
146 DATA VOX GAIN 50 50 50
147 DATA VOX GAIN 100msec 100msec 100msec
148 ANTI DVOX GAIN 0 0 0
149 EMERGENCY FREQ TX DISABLE DISABLE DISABLE
150 PRT / WIRES FREQ MANUAL MANUAL MANUAL
151 PRESET FREQUNCY 145.375.00 145.375.00 145.375.00
152 SEARCH SETUP HISTORY HISTORY HISTORY
153 WIRES DG-ID AUTO AUTO AUTO
