Yaesu FT-857 Amateur Transceiver

回到主页

Amateur HF Transceivers

The Yaesu FT-857 is the worlds's smallest HF/VHF/UHF multimode amateur transceiver. But don't let the diminutive size fool you. The FT-857 is loaded with features, high power output and a receiver that blends the renowned performance of the FT-897 and FT-1000 Mark V. It provides coverage of the 160 to 6 meter bands plus the 144 MHz and 430 MHz bands! And look at the receive coverage: 0.1-76, 108-174 and 420-512 MHz. The front panel is removable and it is remotable with the optional YSK-857 separation kit. Refinements include: spectrum display, 32 color display, beacon mode, keyer, 200 alphanumeric memories and CTCSS.

The FT-857 rear panel features an SO239 input for your HF/6M antenna, and an SO-239 input for your 2M/440 MHz antenna. Includes MH31A8J hand mic, mounting bracket, DC power cord, spare ATC fuses.

Click here for detailed specifications.

Features
160-2 meters +440 Electronic Keyer 200 Alpha Memories DSP Option	100 Watts HF Output 50 Watts 2 Meter Output 20 Watts 440 MHz Output Spectrum Display

Options | Options With Photos

Order #	Item	Description
#4547	ATAS-120	Active tuning motorized mobile antenna.
#3804	ATBK-100	VHF-UHF antenna base/counterpoise kit for ATAS-120.
#0379	CT-39	Packet cable.
#3821	CT-58	Band data cable.
#3822	CT-62	CAT Computer interface cable.
#4187	DSP2	DSP bandpass filter, auto notch, NR & mic equalizer.
#4540	FC-30	Automatic antenna tuner.
#3631	FP-1023	Switching power supply 23 amp. 120/240 VAC.
#3640	FP-1030A	Linear power supply 30 amp.
#0420	MH-36E8J	DTMF Hand mic
#4414	MH-59A8J	DTMF remote hand mic.
#2187	TCXO-9	High stability option (± 0.5 PPM).
#1255	YF-122C	Collins 500 Hz CW filter.
#4188	YF-122CN	Collins 300 Hz CW narrow filter.
#0803	YF-122S	Collins 2.3 kHz SSB filter.
#3847	YSK-857	Head separation kit (19.6 ft.) including mic extension cable.
