| Frequency range: | 144-146 MHz |
| Mode: | FM |
| RF Power output: | Hi: 2.5-5 W (depending on voltage) Lo: 0.5 W El: 20 mW |
| Voltage: | 6-16 VDC |
| Current drain: | RX: Max 55 mA TX: Max 1.5 A |
| Impedance: | 50 ohms, BNC |
| Dimensions (W*H*D): | 58*135.5*29.5 mm |
| Weight: | 380 gr (with PB-10, antenna, and handstrap) |
| Manufactured: | 199x-199x (early nineties) |
| Other: | |
| Related documents: |
