Mount it in a vehicle, take it on a DX-pedition or use it as a permanent base
station transceiver and you'll see that the compact TS-60S packs a hefty punch.
The easy to use menu system adds flexibility and the powerful cooling fan with
heat sink ensures stable operation in any situation.
|
|
Antenna Impedance | 50 ohms |
Dimensions (W x H x D) | 7-1/16 x 2-3/8 x 9-3/16 in (179 x 60 x 233 mm) |
Frequency Range | TX:
50-54MHz RX: 50-54MHz |
Frequency Stability | less than ±10x10-6, less than ±0.5x10-6 with SO-2 |
Microphone Impedance | 600 ohms |
Mode | A1A (CW), J3E (SSB), A3E (AM), F3E (FM) |
Operating Temperature Range | -20° - 60°C |
Power Requirement | 13.8V DC ±15% |
Weight (approx.) | 6.4lbs (2.9kg) |
Audio Output Impedance | 8 ohms |
Audio Output Power | Greater than 2 W (500 µV antenna input, 10% distortion) |
Circutrity FM | Triple conversion system |
Circutrity SSB, AM, CW | Double conversion system |
IF Rejection | Greater than 80dB |
Image Ratio | Greater than 70dB |
Intermediate Frequency 1st IF | 73.045 MHz |
Intermediate Frequency 2nd IF | 10.695 MHz |
Intermediate Frequency 3rd IF | 445 kHz (FM only) |
RIT Variable Range | ±1.1 kHz (±2.2 kHz in extended mode) |
Selectivity AM | Greater than 5 kHz (-6 dB), Less than 40 kHz (-60 dB) |
Selectivity FM | Greater than 12 kHz (-6 dB), Less than 25 kHz (-50 dB) |
Selectivity SSB | Greater than 2.2 kHz (-6dB), Less than 4.8 kHz (-60 dB) |
Sensitivity AM | Less than 2µV |
Sensitivity FM | Less than 0.25µV |
Sensitivity SSB, CW | Less than 0.16µV |
Squelch Sensitivity FM | Less than 0.25µV |
Squelch Sensitivity SSB, CW, AM | Less than 2µV |
Carrier Suppression | more than 40dB |
Frequency response | 400 - 2600Hz (less than -10dB) |
Maximum Frequency Deviation | ± 5kHz |
Modulation AM | Low Level modulation |
Modulation FM | Reactance modulation |
Modulation SSB | Balanced modulation |
RF Output Power AM | 23 W |
RF Output Power SSB, CW, FM | 90 W |
Spurious Radiation | less than -50dB |
Unwanted Sideband Suppression | more than 40dB |
