| Frequency range: | 50-54 / 144-146 / 430-440 MHz |
| Mode: | FM |
| RF Power output: | Hi: 5/5/5 W (depending on voltage), Lo: 0.5/0.5/0.5 W |
| Voltage: | ? VDC |
| Current drain: | RX: Max 200 mA TX: Max 1.4 A |
| Impedance: | 50 ohms, SMA |
| Dimensions (W*H*D): | 58*107*29 mm |
| Weight: | 270 gr |
| Manufactured: | 199x-200x |
| Other: |
