| Frequency range: | TX: 50-54 / 144-146 / 430-440 MHz RX: 0.5-15 / 48-999 MHz |
| Mode: | FM |
| RF Power output: | Hi: 5/5/4.5 W, Low3: 2.5/2.5/2.5 W, Low2: 1/1/1 W, Low1: 0.3/0.3/0.3 W |
| Voltage: | 7.2 VDC (internal), 13.8 VDC (external) |
| Current drain: | RX: Max 150 mA, TX: Max 1.9 A |
| Impedance: | 50 ohms |
| Dimensions (W*H*D): | 58*88*27 mm |
| Weight: | 255 gr |
| Manufactured: | 19xx-19xx |
| Other: | |
| Related documents: |
