| Frequency range: | 144-146 / 430-440 MHz (12.5/25 KHz steps) |
| Mode: | FM |
| RF Power output: | Hi: 25/25 W, Lo: 3/3 W |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | 13.8 VDC |
| Current drain: | RX: 600 mA, TX: Max 7 A |
| Impedance: | 50 ohms |
| Dimensions (W*H*D): | 150*50*168 mm |
| Weight: | 1.5 Kg |
| Manufactured: | 1985-19xx |
| Other: | |
| Related documents: |
