| Frequency range: | 144-146/430-440/1240-1300 MHz |
| Mode: | FM |
| RF Power output: | Hi: 50/35/10 W, Mid: ?/?/? W, Lo: ?/?/? W |
| Voltage: | 13.8 VDC |
| Current drain: | RX: Max 3.2 A, TX: Max 12 A |
| Impedance: | 50 ohms |
| Dimensions (W*H*D): | 140*50*195 mm |
| Weight: | 2.1 Kg |
| Manufactured: | 1994-19xx |
| Other: | RX: 118-174 / 320-479 / 1000-1400 MHz. Triple RX |
| Related documents: |
