| Frequency range: | 50-54 MHz |
| Mode: | FM |
| RF Power output: | Hi: 10 W, Mid: 3 W, Lo: 0.5 W |
| Voltage: | 13.8 VDC |
| Current drain: | RX: Max 1 A, TX: Max 3.8 A |
| Impedance: | 50 ohms |
| Dimensions (W*H*D): | 140*40*124 mm |
| Weight: | 800 gr |
| Manufactured: | 19xx-19xx |
| Other: | |
| Related documents: |
