In the Summer of 2003, I operated ALAN9001 in my room.

Now, here is my corner.

The appearance of YAESU FT-80C:

Specification:

Frequency range	10-160 m + WARC
Mode	AM/FM/SSB/CW
RF Power output	FM/SSB/CW 100 W
	AM 25 W
Sensitivity	SSW/CW < 0.50 µV
	AM < 2 µV
	FM < 0.70 µV
Voltage	DC 13.5 V ± 10 %
Current drain	RX 1 A
	AX max19 A
Impedance	50 Ω
Channel Capacity	20
Dimensions (WxHxD)	238x93x238 mm
Weight	3.5 kg

Owner's Manual: FT-80C（need to install Adobe Acrobat Reader）

The appearance of ALAN9001:

Specification:

Owner's Manual(01\02\03\04\05\06\07\08\09\10\11):

The appearance of Kenwood TH-78A:

Specification:

Owner's Manual: TH-78manual（need to install Adobe Acrobat Reader）

The appearance of Motorola M208:

Specification:

Technical Specifications
Frequency	136-156 MHz
Operating mode	FM
Channel Capacity	16
Dimensions	1.73" x 6.61" x 4.25"
Weight	36 oz.
Transmitter
RF Output	10-25 W
Receiver
Channel Spacing	12.5 or 20/25/30 kHz
Sensitivity TIA: 12dB SINAD	0.30µV
Audio Output	3 W

The appearance of Anritsu receiver RG53A:

Specification:

I can't talk about it in detail. If there is a suitable antenna, it can work on long wave, medium wave and short wave. Its operating mode includes CW, DSB, SSB and FAX/RTTY.
