511 Repeater Association System Profile: 145.110 KN9E Repeater

Continuously serving Indiana amateurs since 1984. Transmitter located in New Whiteland, Indiana (15 miles south of Indianapolis) operating at 250 watts. First in Indiana to use a full time PL tone (88.5 Hz). First in Indiana to successfully utilize remote receivers . Four remote receivers located throughout Central Indiana 1 - Indianapolis (I) - Located at KM9S in Franklin at 40 feet. 2 - Flatrock (F) - located on SR 252 near Edinburgh 35 miles south of Indianapolis at 160 feet. 3 - Banta (M) - located near Banta in Morgan County at 80 feet. 4 - Franklin (B) - located on US 31 in Franklin at 80 feet.  Click here to see a map of all of our sites! This will soon be updated!  Click here to see the 511 Coverage Map! Most of our link receivers are converted General Electric Mastr II® mobiles. These work very well and are very selective and sensitive with ARR® GasFet preamps. We use a variety of antennas including a Hustler G7-144 at the main transmitter, and a Comet GP-9N dual bander. Full signal to noise voting is provided by a Doug Hall Electronics© four channel voter card. S-Com Industries© 7K Controller provides all of the control functions and autopatch with autodials; digital audio delay module cuts off most squelch tails. Wide area autopatch; calling areas include all of Johnson County and parts of Marion, Morgan, Shelby, Brown and Bartholomew Counties.

511 Repeater Association System Profile: 444.075 KM9S Repeater

Main transmitter and reciever are located in Morgan County near Banta - 20 miles southwest of Indianapolis. First in Indiana to use a full time PL tone (100.0 Hz). First in Indiana to successfully utilize remote receivers Duplexed system with one duplexed and one remote reciever. Remote receiver located in Downtown Indianapolis on Wishard Hospital. Main site antenna is a Comet GP-9N mounted at 80 feet. Full signal to noise voting is provided by a home-brew two channel voter. S-Com Industries© 7K Controller provides all of the control functions and autopatch with autodials; digital audio delay module cuts off most squelch tails. 200 watt Henry Radio® amplifier. Wide area autopatch; calling areas include all of Johnson County and parts of Marion, Morgan, Shelby, Brown and Bartholomew Counties.
