Update 31/12/2023:
The last post of the year on the
last day of the year!
This has been a good year for me in general with
good health and low stress, as far as amateur radio goes it has also been a
good year for me. Conditions have not always been great especially taking into
account that we are heading towards the peak of a solar cycle but I have still
managed to make some memorable contacts and work quite a few new DXCC
band-slots.
I even managed to add 5 (confirmed, at least 8 in total)
new DXCC entities to my CW QRP totals. One of the most memorable ones was
Bouvet Isle, I managed to work them on a few bands when many with better
stations failed, and all of it with 5W!
I also added quite a few radios
to my collection, I have already had a lot of fun with them and I am sure I
will still enjoy them in 2024. I also added a few antennas to the station, the
6 band hex beam being the most important, I really love that antenna. My
upgraded 2 element 40m "dipole" really performed well, I have worked more DX
stations on 40m this year than in the 27 years as a licensed ham before that.
This year I joined the CWOps group, a privilege and lots of fun to work
the 4 CWT slots every week, lots of new friends!
After many years of
just working CW DX and contests I started making SSB and CW "rag-chew"
contacts again this year, nice to chat to like minded people again! It was
great to chat to so many old friends and make new ones. My almost daily 1 hour
plus CW chat with a friend has become a great tradition and helps to keep the
CW skills tuned.
I did enter 2 contests this year, the CQWW DX CW
contest and the ARRL 10m CW contest, I was not really prepared for either as
in both cases I did not really plan for a serious entry but in both cases I
was having so much fun that I ended up spending more time on the air than
planned. I am not expecting great results but I am still looking forward to
the results of the contests once they are released.
I think in 2024 I
will make a more serious effort for at least a few contests like the CQ WPX CW
and CQWW CW contests, I think it will even be fun to enter a few SSB contests
but then I will be running high power to reduce the frustration levels! I just
need to setup my head phones with microphone and foot pedal again.
The
last few days have produced more DX on the higher bands, lets hope this is a
sign of even better things to come!
If I look at this "blog", the 2023
one, it is the largest file with the most entries of any year since I started
doing this, let's see how large the 2024 file will become?
See/hear you
on the air in 2024!
Last sunrise of 2023
Update 28/12/2023:
The band conditions have been
slowly improving over the last few days, I have been hearing more stations on
the higher HF bands during the evenings, last night during the CWT test I
managed to make contacts on 20m, 15m and 10m till 10pm local time when the
contest stopped. Signals are still not extremely strong but at least there are
signals!
This morning 40m was not great to the North America, not sure
why that is but after a record number of contacts during the same timeslot
last week this week was rather poor.
I have not managed to work any
rare DX lately, the only really interesting station I managed to work was
OL750HOL, a special event station in the Czech Republic commemorating the
750'th birthday of a town.
OL750HOL
Hopefully by this time next week my new Yaesu FTdx-10 would be shipped and on
the way to me. Looking forward to comparing the receiver with the radios
currently in use this side.
Update 25/12/2023:
Merry Christmas!
Normally I would not be posting on 25 December but it has been a
quiet and relaxing day, the only notable thing was that for the first time in
over 10 days I actually heard some signals on 10m again and I even worked a
few, noting special but hopefully it is an indication that things will be
improving again!
This week during the CWT time slots I am going to try
to work some European stations during the 1900Z session in addition to the fun
I normally have on 40m during the 0300Z session, that is if there is
propagation!
Working DX on 10m under the watchful eye of one of
my fur-babies.
Update 24/12/2023:
Christmas eve! Almost Merry Christmas to
everyone!
The DX conditions are still bad, seems like the sun is rather
busy throwing stuff our way! I know conditions are bad when I am happy to work
a station in Finland and one in Latvia like today, normally those contacts
won't be noteworthy but when they are the only stations you can hear they
become noteworthy!
It was interesting that there would suddenly be an
opening towards a very specific area with reasonable signals while nothing
else is heard from anywhere else! I am pretty sure it was "long path"
propagation over both poles as the signals had that peculiar "polar flutter"
to them that made them quite difficult to copy even though they were not that
weak! That would also explain why there would be propagation while there was a
CME as the propagation would be over the dark side of the globe.
Yuris,YL3FT in Latvia, worked him across both
poles!
I was happy to see that my QSL for the DX'pedition to Laos, XW4DX I worked a while ago, has arrived, it is not a new country but it is new on 15 and with the pickings being so slim at the moment every new band-slot is special!
Confirmation of my 15m CW QRP contacts with XW4DX
Another nice addition to the collection was V44KAI Saint Kitts and Nevis, one of the islands in the leeward islands in the Lesser Antilles, Caribbean, on 40m, hopefully I will get a QSL via LoTW as this will be a new one on 40m. I have worked a station in Saint Kitts and Nevis before on 40m but I never received a QSL.
The tropical paradise of Saint Kitts and Nevis.
With the band conditions being bad with very weak signals and often lots
of QRM and static from summer storms it has not been easy to dig out new
stations, one thing I have noticed is that when things are really bad the
FTdx-5000MP is the best radio to hear the station, nothing else in my
collection gets close, not even the IC-7610. It will be interesting to see how
the Yaesu FTdx-10 will stack up to this. On paper it has a better receiver but
I do not think it has as many noise fighting tools as the FTdx-5000MP, time
will tell.
Update 21/12/2023:
Sadly I have not been making updates here
recently, mostly due to extremely poor band conditions. I must say right now
conditions are worse than what I have ever experienced in 3 solar cycles, well
it feels that way anyway! This is due to almost 2 weeks of solar flares and
CME's, every time the bands start to recover there is another event.
I
have worked a few stations on 10m and 12m but signals have been extremely weak. 40m
do open to the USA and Canada at around dawn but the opening only lasts around
45 minutes every day. Locally 40m is open, but not great in the mornings till
about 8am local time and then it opens again after 5pm local time. Once it is
open in the evenings it stays open till late with booming signals. Most of the
time I only run 10W for my evening rag-chew on 40m. Most of these sessions
last around 90 minutes till I have other commitments.
With the 40m band
open to the USA in the mornings the 0300Z CWT sessions have been fun. With my
higher antenna it is definitely easier to work US stations running 5W, most of
the time I can work every station I can hear. This morning I managed 38
stations in the 40 minutes the band was open, lots of fun! Unfortunately no
Wyoming station yet but I am patient. I did notice last night at 2000Z that I
could hear CW stations on 20m during the CWT session, unfortunately it was
right at the end of the session but I am planning to be on the air at the
start of the 1900Z session next week, it should get some stations from Europe
in the log for a change.
After running the superb (yes, I love it!)
Yaesu FTdx-5000MP for my 40m activities and DX'ing for a while I decided to
give another radio a chance yesterday. I have not used the Yaesu FT-1000MP mk5
for a while but it was fun to use it again and the receiver sounds fantastic!
It does not have the same noise fighting features as the 5000 but it is still
better than many more modern radios and with a full set of the optional
roofing and CW filters it is a great CW radio. The one thing I do not like
that much is how hot it runs during long TX sessions. Strangely it runs hot
even at 20W or below. I have been told it was designed to run at that
temperature but I still don't like it!
Yaesu FT-1000MP mk5 on 40m cw.
After using the Icom IC-7300 for a while I decided
I like that size modern radio quite a lot, even though it only has a single RX
it is still fine for local rag-chews and working casual contests like the CWT
tests. The one thing I would like is a slightly better receiver with better
filters, noise reduction and dynamic range.
This has led me to do some
research on what is available around the same size and what is best value for
money. I did seriously consider the Yaesu FTdx-710 but what I do not like is
the fact that it takes a few button presses and screen taps to get to the
filter settings. Since I often change filter settings during a contact that
will be a real pain, like it is on the IC-7300.
The option that is only
slightly more expensive and has a slightly better receiver is the Yaesu
FTdx-10. It has dedicated controls for the filters and it has the same
receiver and front-end as the "best in the world at any price" FTdx-101 radio.
Not only will this make a superb every day radio as well as a field/holiday
radio it will also give me the opportunity to see how good the Yaesu hybrid
SDR receiver really is. If it is that much better than what I have maybe a
FTdx-101MP is worth the cost.
I have found a "new in box" FTdx-10
locally, it is in an estate and I do have first option on it but the
price still needs to be set by the people handling the estate. Hopefully a
price will be set soon as I am keen to try this radio!
New baby on the way, Yaesu FTdx-10
Update on FTdx-10:
Shortly
after writing the above I was contacted by the person handling the estate and
the deal was done! So I will have a Yaesu FTdx-10 with SP-30 speaker in the
shack soon. Unfortunately it will only be shipped after 2 January 2024 due to
the holidays and the widow being away but I can live with that.
Update 14/12/2023:
The CWT test this morning was fun, as per
usual the during the 0300Z time slot only 40m was open and again as per usual
the opening did not even last the full hour but today signals were a lot
stronger that what I have heard over the last few months. I am not sure if
this was simply better conditions or it if it is due to my antenna that is now
4m higher.
Either way the result was double the usual number of
contacts, was great to hear signals way above the noise for a change !
Lots of signals to choose from!
By around
0340 the band suddenly started closing, only the strongest signals remained.
Unfortunately the good conditions did not continue on the other bands after
the contest, the rest of the morning and afternoon there was simply no
signals, well at least I managed to work a bunch of stations on 40m.
Not long after the contest I received news that a parcel arrived for me at the
local courier agent, I did not waste time to go pick it up!
As expected
it was my Yaesu FTdx-5000MP. Fortunately there was no shipping damage, always
a worry especially with items that are large and heavy like this. I must say
when I saw the box I was worried, it was a rather flimsy box and it showed
signs of being banged around a bit. At least it had lots of bubble wrap that
protected the radio.
After checking that there was no visible damage I
connected it up and had it on air in no time at all. Unfortunately the bands
were terrible so I could not make any QSO's, that will have to wait for early
evening I suppose. At least I will be able to test it during my evening 40m CW
chat.
I spent some time familiarizing myself with the radio again, it
has been a while since i used one. I also had to setup a few things to work
the way I like it. I wonder if the previous owner really used it, some things
like the "key press confirmation beep" was not setup in a usable way. With the
2 large speakers on to of the radio the beep was so loud it made your toes
curl!
Yaesu FTdx-5000MP ready to go! I sure missed this
radio in the shack.
I had forgotten what a great radio this is, in the photo above you can see the
"QRM Eliminator" on top of it. I had to used this unit on 40m as the QRM on
40m is so bad that without it I cannot hear much. Well I have now disconnected
it for the FTdx-5000MP, no need for it as the noise fighting tools on the
radio is so good. Suddenly the noise levels have dropped. I think this radio
will stay in the main operating position for quite a while!
Update 11/12/2023:
The day after the ARRL 10m contest,
I can still hear CW when things are quiet!
Unfortunately conditions
only improved slightly on the second day, this was as predicted.
Sunday conditions very similar to Saturday.
Even though the prediction for 10m on Sunday was still fair to poor I could
hear a few more stations but most of them were just in or above the noise.
There were around 15 - 20 stations that were very loud both days, always
wonder how that happens, do the have special antennas or do they run huge
power? I think in most cases it is good antennas since they hear well as well,
you can work most of them on first call.
The morning started with a
weak opening to Japan and the far east, it only produced around 10 contacts
but it did add 3 multipliers, one for Japan, Singapore and India each. After
that I worked a few European stations but after scanning up and down the band
a few times I gave up. After lunch I could hear more stations in Europe but
unfortunately I had already worked most of them.
As the afternoon
progressed the totals slowly increased but far slower than I would have liked.
By late afternoon I started hearing US and Canadian stations so the rate
increased a bit. There were also a few surprises like Caribbean stations and
one from Columbia.
By 1830Z I finally shut down as the signals were
dropping and every single station I could hear was already in the log.
The totals were not great, this is the third time I have competed in this
contest and by far the worst I have done. I think it is mostly due to
conditions, the previous two times were at solar cycle peaks and I had
stations right across the band many with strong signals.
I ended up
with 225 QSO's (and 1 duplicate!), there were 40 countries and 46 US states
including a very weak station from Wyoming, I just hope he got my call correct
as I had to repeat many times.
My total operating time was 10 hours.
Looking at the scores posted by other competitors on the 3830scores page
it appears that I am not the only one who found the conditions difficult.
Looking at the scores posted there I should end up in the top 10 work wide in
the QRP category and with a bit of luck maybe in the top 5, we will see!
A more complete report of the contest can be read
HERE.
I enjoyed the contest despite the difficult
conditions, when signals are weak every contact becomes a little victory! At
least I did not have that horrible QRM I had on the Sunday of the CQWW CW
contest. I am looking forward to the next contest and I am already planning a
few improvements to my station.
Other than the CWT tests I suppose the
next major contest will be the CQWW WPX contest, 25-26 May 2024, a contest I
really enjoy and have done well in in the past. I might just try a SSB contest
again, the CQWW WPX SSB contest a month earlier than the CW one would be a
good candidate but I will NOT be running QRP!
Update 9/12/2023:
This weekend we have the ARRL 10m
DX contest, always a great contest to collect some new DXCC band-slots even if
you don't want to compete.
After the fun I had in thee recent CQWW CW
contest I was looking forward to this, both for hopefully collecting a few "new"
ones but also to actually compete. The last time I tried to compete in this
contest was in 2014, see the results and report
HERE, it was fun but due to my mom falling ill I only ended up
spending 5 hours out of the 48 on the air making 372 QRP contacts. It did
result on a first place in class in Africa and 7'th in the world.
Unfortunately it looks like this weekend won't be as productive, the recent
solar CME's have really messed up the bands with the prediction for 10m only
being Fair during the day and Poor at night. We will see, as I write this it
is still morning and the band is totally closed, it might just open up
sometime this afternoon but I do not expect strong signals.
If it does
work out I will post an update later!
Propagation predictions for today, not great for
10m!
Update early evening, the band opened up better than expected, it was not
spectacular but still fun even running 5W. First I had a quick opening to the
far east and then it moved west to Europe. By around 1300Z the signals dropped
and I took a quick break. By the time I got back at about 1400Z the band
started opening to the east. By the time signals dropped to the point where it
became difficult to hear them at 1800Z I had managed to work quite a few
interesting stations, I will list them after the contest, and then I also
worked the usual bunch of US and Canadian stations. There was even a Wyoming
station in the batch, hope he QSL's.
So far the total QSO's stand at
125, not a lot but with conditions less than optimal I spent a lot of time
working the rarer stations, more for my DXCC totals than the contest but at
least they are multipliers so that helps. I will still see if I will actually
submit the log, I suppose it depends on how well it goes tomorrow.
Seem
like I still enjoy contesting!
On a different note, after reluctantly selling my Yaesu
FTdx-5000MP in 2018 I have been missing it, it really is a special radio and
the last of the full-size flagship radios with more controls than menu
options, the king of the era. Well today, during the contest I spotted an
advert popping up on a local amateur radio group for a pristine FTdx-5000MP,
within 15 minutes the deal was done!
Update 6/12/2023:
DX conditions have not been great
the last few days, I did manage to work a few stations but the bands seem
rather quiet most of the time. One surprise was a rather lonely D2EB, Angola,
calling on 10m. Angola is normally a bit close for 10m but he was loud and
gave me a 599 report. Unfortunately it is not a new one but still a nice
contact.
D2EB, he has been on the air from Angola for a
while
I was surprised to see
that I have already received the QSL for
5H3MB, Tanzania on 12m, that was quick, often you
have to wait a while for these contacts into "Dark Africa".
Other than
my usual evening CW QSO on 40m I have worked a few other local stations on 40m
as well, it is great to see that there are new CW operators coming on-air in
South Africa.
As a change I decided to use a different radio for a
while this week, I do seem to get bored with a radio after a while, this time
I chose the Yaesu FT-2000D, a radio that I have had for years but I have
hardly used it. I acquired it, along with a FT-950 in a new, still boxed and
unopened state from an estate in 2014. I received them the same week as my
FTdx-5000MP arrived (it was delayed more than 6 months in customs) so the 2
radio did not see any service as I was having too much fun with the
FTdx-5000MP.
The FT-2000D is equipped with the optional Inrad roofing
filters. I must say it is a great radio with fantastic sound and really
effective filters. On 40m I do not even need the external QRM Eliminator that
I have to use with radios like the IC-7300, the internal noise blanker and DSP
noise reduction along with the exclusive to Yaesu IPO function is really
effective.
I have added an internal SDR dongle on this radio, easy to
do as there is already an IF tap plug available internally and plenty space.
Using this along with the superb SDR Console and Omnirig software the radio
has a better user interface and spectrum scope/waterfall display than most
modern radios, a great combination.
FT-2000 in action.
Update 3/12/2024:
December already, this year has
flown! I have been on the air every day but I have been a bit lazy and I have
not updated here. Conditions have been very poor the last 2 day, mostly due to
2 huge CME events, today things seem a bit better that is good news.
Yesterday did produce the QSL's from D4C, Cape Verde for 10,
20 and 40m, it is a new one for me on 40m so that is great. Two more
"important" QSL's to go then I will have all the new ones worked in CQWW CW
2023.
I have been trying the last 2 days to work a station in Wyoming,
USA but so far no luck due to the CME's, maybe we nab try again tomorrow. Last
night at 1900Z we tried but nothing, the higher bands were all dead quiet,
while tuning around I did come across one station calling CQ, ZS7ANF,
Antarctica. He was easy to work and since here were no other stations calling
him we could have a nice chat and not just the normal signal exchange, nice! I
do not think it is a new QRP DXCC but I need to check.
I did briefly
listen on the bands this afternoon to see if conditions were better and to my
surprise I heard 5H3MB, Tanzania on 12m with a strong signal. It is a new one
on 12m so I am glad I made the effort to listen even though I did not expect
much.
5H3MB shack, always nice to know what the setup on
the other side looks like.
Now I am hoping for
better conditions this week, it will be a bit cooler than last week, Friday it
was 46C here, so I will hopefully have more energy to sit in front of the
radio.
Update 30/11/2023:
The DX bands have not been great
the last few days, at least not when I have been on air. Yes, there are
stations to work but they are often weak and mostly from active countries so
no "rare DX" to chase. Other than my evening CW chat the only time I have made
more than 1 or to contacts in a session was during the CWT test session this
morning.
Even during the CWT test session 40m that normally works quite
well at 03h00 only opened about 20 minutes into the contest and just about
closed 30 minutes later. 40m also behaved strangely last night, normally by
7pm local time it is open for local contacts it only really opened up 45
minutes later.
Talking about CWOps test sessions, I am enjoying these
sessions even if they are only producing from 25 to 30 QSO's in the hour most
of the time. I see I have so far, in my first month, worked 135 different
CWOps members, chasing more will be fun!
135 different CWOps members worked in my first
month.
On the subject of awards, I finally got around to importing my CQWW CW log
into my regular log, this allowed me to see what was new, see the result
below, the effort and drama with the hectic QRM was worth it!
PS5CO - Surinam - 20m - QSL received
PJ2T -
Curacao = 20m - QSL received
CE2LR - Chile = 20m - QSL
received
4K6FO - Azerbaijan - 10m - QSL received
D4C - Cape Verde - 10m, 20m and 40m - No QSL yet
KP4AA
- Puerto Rico - 40m - No QSL yet
9M8YY - Eastern Malaysia
- 20m - No QSL yet
So 7 new CW QRP DXCC slots was not too bad, I seldom
add that many in a month or more!
Update 28/11/2023:
I did sent in my log for the CQWW CW contest
yesterday. I am not expecting a great result but according to logs posted on
3830scores.com I should end up in the top third worldwide and with a bit of
luck top ten in Africa. In South Africa I might just win my class, we will
see!
So far I have not heard the QRM again, I can just hope it won't
surprise me again during the next contest!
The good news is that the
QSL's are streaming in for the contest, so far I have received about 85
confirmations that include 3 new CW QRP "band-slots", better than expected!
The new DXCC band slots so far are:
CE2LR - Chile - 20m
PJ2T -
Curacao - 20m
4K6FO - Azerbaijan - 10m
Other QSL's that are special
but not new ones for me include the following countries:
Kenya, Nepal,
Latvia, Rodrigues Isle (10, 15 and 20m) and Serbia plus a lot of the more
common ones.
The one QSL I am still hoping for is Wyoming, I did work
quite a few US stations mostly on 20m and 40m so there is hope! There are also
a few of the more obscure islands that I worked that I am hoping will still
send QSL confirmations.
Update 27/11/2023:
The day after the CQWW CW contest. The
contest had highs and lows, you can read my full report
HERE.
A quick summery would be that it went ok on the first day but on the
second day, from about 11h00 UTC I suddenly had huge QRM right across the
bands coming from the North. It was so bad that I gave up. The sad thing is
that the QRM is still there this morning, yesterday it was worst on 10m but it
has now moved down to 40m to the point where I can't even hear strong local
stations.
This source of interference must be found as it makes
amateur radio totally unusable at my QTH at the moment. It is something that
was switched on as it appeared full strength suddenly with no warning..
Update 24/11/2023:
The day before the CQWW CW! I have
not made a final decision on if I am going to compete or just try to work some
nice DX stations. I think the final decision will only be made tomorrow
morning after I have made some contacts. I was quite keen to make this as
serious effort, my first since 2015 but a few things have not worked out as
planned. I wanted to compete in the "all band" category, more stressful
due to the long hours and less chance of being competitive but my motivation
is to make it possible to work some new DXCC band slots.
In the past I
have mostly chosen single band as it allows you to rest a bit when the band is
closed. I was planning on putting up a 80m antenna, I have none at the moment,
as well as to raise my 2 40m "phased" dipoles, they are only about 8m high at
the moment. My hex beam also needs attention as the retaining screw that
prevents rotation relative to the rotator is loose/stripped (stupid design!)
so the antenna moves around in the wind and you cannot trust your direction
indictor in the rotator controller.
Well, due to various reasons,
mostly the extremely hot weather and high winds we have had recently, non of
these things happened, so no 80m, terrible 40m antenna and a hex beam that
points where ever the wind pushes it.
The last few days have produced
some good DX, conditions were not great with low signal strengths but all the
contest stations with their superb CW operators are active from obscure
locations setting up and testing equipment, This makes for some interesting
DX!
Notable stations worked in the last few days:
3B8/4O3A -
Mauritius on 15m CW
as well as a bunch of Caribbean islands and other
Indian ocean islands.
I have also noticed that my OX3XR - Greenland QSL
has arrived, good news.
Hopefully my next entry here will be a report
on the 2023 CQWW CW contest.
Update 21/11/2023:
I had a look at the XW4DX log this
morning and my contact is there, good news! Since they sounded really lonely
yesterday I also worked them with my ZS6DX/2 call and that contact is there as
well. Good news!
It is extremely hot and windy here again today with
high static so I am not expecting much during the day but maybe the late
afternoon will produce a few surprises again.
I did notice an
advertisement for a "Wolf RS-998 SDR" radio on the internet today. I searched
a bit and it does look like an interesting new radio, similar to my R928+ in
some ways but with many new features like a larger screen, internal tuner, VHF
and UHF added and 100W output!
From photos and dimensions it looks
quite compact so it might well be a great radio for field station and hiking
when, due to less than perfect antennas, you might need more power than QRP.
Now I just need to find one, they can be ordered online but from places
like Aliexpress, the problem then becomes shipping as they often use normal,
non courier shipping and with our dysfunctional postal services here in South
Africa chances are you will never see the radio. I need to find a supplier
that offers courier shipment as an option.
Wolf RS-998, 1-750MHz 100W transceiver
Update 20/11/2023:
I did not spend much time in the
shack this weekend, other than my normal CW chat to a friend in the evening
and a morning chat on 40m I was not on the air. I did check band conditions a
few times but mostly only weak signals.
Late afternoon I did scan
across the bands but again only noise, we had hectic winds today so the static
was bad! I switched off and left the shack turning my interest to other
things.
About 15 minutes after I scanned the bands I got a message from
a friend that XW4DX, Laos was on the air on 15m CW with a decent signal. I
switched on and yes, could hear them quite well! It took about 4 calls but
they heard me, good news! Not a new one but a new QRP CW contact on 15m,
thanks Andy - ZS3ADY, I owe you one!
Laos DX expedition worked!
While I was working XW4DX I received a message from another friend that 4W8X
was on the air, 20m SSB. Well, I decided it was worth a try to work them, a
frantic search produced a microphone for the IC-7600. I decided that since it
was SSB I would be wasting my time with 5W so I tried with 10W (most amateurs
accept 10W SSB as "QRP"). It took a few calls but within minutes they heard me
and the call was completed! Thanks Jeets - ZS6JKN, I owe you one as well!
Great to have ham friends who think of you! I feel the almost lost enthusiasm
for DXing has come right back!
Now I just hope I am in the log this
time!
Stunning view overlooking Timor-Leste.
Evening Update, I just had a look at the online 4W8X log, my 20m SSB contact is there but even more amazing is the fact that suddenly my 20m CW contact is there as well! I can only think that they had some issue with a log upload that they have now sorted out.
Timor-Leste log, finally!
It just shows you must never be discouraged by a few setbacks.
Update 19/11/2023:
I had a look at the 4W8X online log
again, there has been updates since I last looked but my call is still not
there.
Update 18/11/2023:
Band conditions have been up and down a
bit recently, some days there are great openings and then suddenly there is
nothing but noise!
After a long chase I managed to work 4W8X,
Timor-Leste this afternoon on 20m. I have seen them spotted on the cluster a
few times but I have heard nothing more than a weak signal in the noise up
till now. I did try over the last few days to work them on 10m and 15m but no
luck, not surprising as I am sure they are running high power and even with
that I can hardly hear them, my 5W has no chance.
So my surprise was
great when I tuned across 20m this afternoon and heard them S7! It only took 3
calls to work them with a solid copy on my call! Now I am waiting for the
update on the online log to see if I am in the log.
I noticed a while
ago that I was only getting about 65W maximum from my iC-7600, I did not
really worry about it since I only run 5W from it but this afternoon I wanted
to chat to a friend on SSB where more power was needed, we did manage the QSO
but I again noticed what appeared to be low power.
A quick test on CW
key down confirmed only 65-70W max on all bands. M first thought was that
maybe my external meter, a Diawa was not correct so I unplugged the coax (from
my hex beam) from the IC-7600 and plugged it into the IC-7300. Bad news was
that the IC-7300 produced a solid 100W into the same antenna and measured with
the same meter. A test with the IC-7610 produced around 110W so fingers were
pointing at the IC-7600.
I downloaded the service manual and found the
adjustment for "Max power", seemed easy. I also decided that since
something was not right I would do the whole driver bias, final bias and drive
level setup first.
Just before opening the radio I decided to do one
more test. When I acquired the radio it came with an Icom PS-125 power supply
with integrated power cord. I checked the voltage from the power supply and it
seemed fine but I decided to test the IC-7600 with the IC-7300 power cord and
power supply, one of my trusty Diawa 60A units.
To my surprise, and
delight the radio suddenly produced over 100W on all bands! Seems like the
problem is the power supply, I changed the power cord and it made no
difference. I looked up the specifications for the PS-125 power supply, max
current is 20A, not good since the radio needs 23A! I wonder how Icom can sell
this radio and power supply as a combination?
Anyway, problem solved,
will use the power supply for radios that need less current! I am glad the
IC-7600 is fine!
Evening update, after the "high" today after finally
working 4W8X and finding out that the IC-7600 was fine I was quite
disappointed to see that I am NOT in the 4W8X log! The log shows it was
updated after my QSO so it should be there. I really cannot understand how
that happened, they definitely had my call correct! I will check again
tomorrow morning, maybe they newest update is not online yet.
Rather
disappointing to say the least, maybe it is time for a bit of a break from
amateur radio?
Update 16/11/2023:
The late afternoon CWT test
yesterday did not produce many contacts, I actually gave up after about 15
minutes and 4 contacts. I could hear almost no stations and as it was 3pm
local time the shack was still very hot. Fortunately this morning's 5 to 6am
(local) session was a lot better with 40m being open to the USA and Canada. I
managed to work 35 stations in the hour, not a great total but I think it was
great for QRP, I am sure it was my best score yet on 40m running QRP.
Unfortunately still now Wyoming!
As an interesting side I was outside
this morning and quite by chance I noticed a strange bend in one of my feed
lines. It turned out to be the new LMR400 feed line I installed recently for
my hex beam. The "kink" turned out to be a cut in the feed line! The coax was
almost cut through completely and the strands of shielding that remained was
shorting out with the core that was cut through completely! This would explain
why I could hardly hear any stations on the higher HF bands yesterday! With me
only running 5W the radio did not even complain, the internal tuner simply
compensated I suppose!
I can only assume this happened yesterday
morning when I had someone working in the garden. Only option was to replace
the feed line, no real way to join it without inducing losses, something you
need to avoid at all costs when you run QRP! It is all sorted out so now I can
look for DX again, unfortunately by the time I had made up a new cable the
second CWT period of the day was history so no contacts for me.
I
noticed a new QSL I received from Bulgaria today, nothing unusual or special,
I have plenty QSL's from Bulgaria but what was interesting was the date! It is
for a contact I made in 2000, 23 years ago!
This QSL confirmation took only 23 years to reach
me.
I have been updating my logbook today, importing all the separate contest ADIF and other ADIF files, once it was done I ran a report on outstanding DXCC entities I need, see the result below.
Wanted DXCC entities.
I am not so sure I trust the list completely, I know for a fact that I have
worked Z6, Kosovo, I found the call in my log. I am also quite sure I have
worked at least 2 of the other "outstanding" DXCC entities. I think I need to
export the whole logbook and import in into another logbook program, I am sure
I am going to get different results!
On the equipment front I have been
looking out for Black Friday specials on radios, so far nothing of interest
but I am hoping!
Update
14/11/2023:
This morning I was a bit lazy to go
to the shack early to look for DX on 40m but eventually did, I am so glad I
did go! I heard the TJ9MD station in Cameroon again on 40m, but unlike
yesterday he came back to me almost immediately! Patience pays when you re
DX'ing, especially at 5W.
After working TJ9MD I tuned around a bit on
40m, I did not expect much as the sun was up quite high already so 40m was
closed for DX. Big was my surprise when I heard KL7SB, Alaska, on 40m. I
managed to work him without any problems. Alaska on 40m is not a new one for
me but it does show that DX can show up on any band at unusual times. It is
always worth listening.
It was extremely hot today, the temperature
peaked around 42-43C so I did not spend much time in the shack as it is the
warmest room in the house. I have started the process of installing
air-conditioning in the hobby room, about time!
I did get back on the
air early evening for my usual CW chat on 40m. I was on the air a few minutes
early to I tuned around a bit, that time of the day, just before 7pm local
time, the bands were not that active, but I did hear a pileup on 20m.
Listening down soon resulted in me identifying the station that was causing
the pileup as V62S, Micronesia. Since it would be a new one for me on 20m I
immediately turned my antenna in his direction and started listening to the
pileup to try and figure out where he was listening.
My main problem
was time, I only had about 8 minutes before my sked and I hate being late!
Fortunately the operator on the V62S side was great and he heard me quickly,
nice one bagged!
I have now worked V62S, the operator is heading to
V62P next, hope I can work him there s well!
Update 13/11/2023:
I spent a frustrating 90 minutes
this morning trying to work TJ9MD, Cameroon, on 40m. Initially his signal was
loud but he could not hear me. I can only assume that he had a noise issue
because he kept on calling CQ, lots of stations came back to him but he did
not hear them. This would have been a new one for me on 40m, but that is the
way DX'ing is, sometimes you land the fish and sometimes the fish swims away.
Oh well, maybe I will hear him again on 40m!
The bands have been
reasonable most of the time, especially 10m has been great. Unfortunately I
have not heard any new DXCC entities on 10m the last few days. I did manage to
work a new one on 12m, OX3XR, Greenland was S1 on my side but he replied to me
quickly, great operator! I hope he is on LoTW as I need a QSL card from him.
OX3XR, nice QSL card! I remember how colorful
houses in Greenland are, good memories!
I am looking forward to the CWT test sessions this coming week, always fun
plus there is a chance I will find the elusive Wyoming station. So far I have
resisted asking on the CWOps group is there is someone in Wyoming for a sked
but eventually that might be the only solution.
Update 11/11/2023:
I was pleasantly surprised to see
that my TO8FH, Mayotte, QSL's have arrived via LoTW, a lot quicker than I
expected!
I managed to work them on 6 bands! I also worked them a few
"extra" times on a few bands, not because I needed the contacts but because I
heard them calling a few times without any replies so it was nice to have a
bit of a "rag-chew", or at least longer contact with them. At least they knew
they were getting out! The 6 bands I worked them on were all new band slots
and Mayotte was also an all time new QRP DXCC entity for me.
TO8FH QSL confirmations, the QSL's with the "tick"
are the new band-slots.
Another notable station I worked was TJ9MD in
Cameroon, I did work them earlier but my QSO did not appear on their
searchable log on Clublog so I worked them again on 10m, strangely when I
looked for my call in their log later both contacts were there, oh well, at
least I know it is in the bag now!
For my local evening CW QSO I
decided to change radios again. I have had a brand new Yaesu FT-950 in a box
for years, acquired it as part of a larger deal and never really used it other
than to test it. Well, all I can say is I have forgotten how nice this
generation of Yaesu radios were! 40m can be really noisy here, most of the
time I use my QRM Eliminator but with the FT-950 I have not felt the need for
the Eliminator, the IPO function is simply amazing! Last night the noise
dropped from S7 to below S1 with the push of a button.
The sound from
the receiver is also very "full" and "smooth" with none of the high frequency
"noise" that you can hear on most of the modern radios. This noise can be
quite fatiguing when listening for long periods.
The FT-950 is such a
pleasure to use I think the next radio I will put into operation will be the
FT-2000D, would be nice to compare the 2 radios.
Yaesu FT-950 in action.
I am looking forward to the CQWW CW contest at the
end of the month, still no firm plans or strategy but I will be on the air
even if it just to work a few scarce stations!
It is 11/11 today, I
just want to take a moment to think about all the soldiers over the ages who
died to give us the freedom we have today, I am also especially thinking of
friends and family from my generation who paid the ultimate price during the
war we fought on the Namibian border, I clearly remember the horror of war up
there, we went from boys to men very quickly, around 1987 I got a taste of
that first hand, I/we will never forget...
We remember.
Update 9/11/2023:
I have been quite active on the air with
daily DX chasing as well as my regular chat on 40m in the evening.
Unfortunately I have not had much time to update this page!
The 40m
band has been great lately staying open late into the evening with both local
and DX stations that can be worked. This morning at 0300Z I spent an hour on
40m working stations in the weekly CWT test hour. With the band in good
condition I managed to work 29 US stations with 5W and a dipole antenna during
the hour, really satisfying! Unfortunately none of them were in Wyoming so I
am still looking for Wyoming on CW.
I did hear a loud SSB station from
Wyoming later but when asked he does not do CW so still no luck. I think I
need to put out a request for a Wyoming QSO on the CWOps reflector, just maybe
that will produce results.
DX'ing has been good, notable contacts
include:
A25R, Botswana, on a few bands including 40m, one I still
needed.
YO8AD, Yemen, on 40m for an all time new one (QRP)
I got a
lead on an Icom IC-7851 but it turns out the radio has an intermittent issue
that Icom has not been able to sort out it I decided to give it a pass.
Talking about equipment, I am considering importing a new "flagship" radio
to be used as my main DX and contest radio. I am considering importing as the
local suppliers carry no stock and they are quite a bit more expensive than a
direct import. Support is also not an issue, there is no-one locally who can
fix (or who I would trust to fix) a modern top-end radio anyway so if there is
an issue even a locally bought one would need to be sent back to the USA or
Japan. I can do that myself so I am not worried.
Now I am looking for a
nice "special", did someone say "black Friday"?
Update 7/11/2023:
I spent quite a bit of time today
re-doing the setup of the R928+ radio, it is amazing how complicated these
little SDR radios can be if you want to get the most out of them, at least the
setup and alignment can be done from the menus, no need for signal generators,
oscilloscopes and other equipment like with conventional radios!
So far
I have done the basic hardware setup and the CW side, not the SSB side, might
do that sometime but it is not an priority as the radio will seldom or ever
see a microphone!
The bands were dead most of the day but did open up
late afternoon. I heard a large pile-up from 28.020 up, a bit of listening
soon showed that the pile-up was caused by TJ9MD Cameroon. I fortunately
managed to work them, I need to check but I am pretty sure it is a new QRP
DXCC entity on 10m.
Nice catch, TJ9MD, Cameroon.
While chasing the DX I also managed to work a few local friends, I love the fact that with CW it is quite easy to work 2 stations at the same time!
Working 2 stations on differed bands at the same
time.
My evening CW rag chew session went well again after the poor band conditions
we had yesterday. There was also a new station that joined us, hope he will
join again in the future!
Tomorrow it is time for the weekly CWT tests
again, I will be looking for Wyoming again!
Update 6/11/2023:
I was thinking about the situation
with the R928+ (see 5/11/2023 post) and I decided to see if I could fix the
problem.
Ideally I could just replace the switch, but I an not sure
where I could find a little surface mount switch like that, it needs to be
exactly the same else the rubber button that presses on it wont work. Then it
dawned on me it is the M1 button, a button you can setup as a custom button
and a button I never use!
So why not simply disconnect it and not use
it? Challenge accepted, heat up the soldering iron!
With the radio disassembled you can see the S9(M1)
button/switch that is causing the problem.
I soon had the radio open, I carefully de-soldered the offending surface mount
switch, you need a fine-tipped soldering iron and good eyes not to damage
anything when you do this!
So a quick test before re-assembling the
radio, oh no, still the same error! I checked the switch with a multi meter
and it worked 100%, not good news. I next removed the top PCB and had a look
at the circuit below. I could see nothing wrong but one a few of the solder
joints looked less than perfect. I traced the tracks coming from the switch,
they pass through the PCB, one goes to ground and the other runs across the PCB
to a surface mount CPU.
Here I found something interesting. The solder
joints o the CPU are tiny, not much wider than a hair but I could see right
where the switch trace was connected there was a tiny piece of material,
looked like a bit of solder, that looked like it was potentially creating a
short!
I carefully removed the bit of solder, before re-assembling the
PCB I also re-soldered the few solder joints I did not like.
After carefully assembling the radio again, there are quite a few connectors
you need to seat correctly, I applied power and switched the radio on again,
this time it booted correctly! Fantastic!
The R928+ running again! You can see on the
left-hand bottom side that the M1 switch is still missing.
Since a test showed that there was nothing wrong with the switch I decided to re-install it.
M1 switch re-installed.
I re-assembled the radio and it is working perfectly again, the M1 button is also working! I can only guess that the almost microscopy piece of solder that caused the trouble has always been inside the radio but only recently moved to a spot where it could cause an issue.
PCB and switch re-installed, radio is still
working.
Everything re-assembled and working.
I am really glad I managed to "rescue" the radio, I would have missed it. Ok,
so now I can start planning an overnight hike again, oh the nostalgia that
would bring! I just need to buy or build a small CW paddle, will most like
simply 3D print one.
Update 5/11/2023:
With us finally getting some decent weather the
last few days I have not been on air that much, it is fun to do a bit of
hiking and photography again. I did manage a bit of on-air time here and
there, with the bands being open most of the time I enjoy a quick scan every
now and then to look for interesting stations to work.
With the better
weather my thoughts have also turned to some SOTA/POTA operation or simply
taking a QRP radio on a hike. I remember reading an article in the CQ magazine
when I was still at school about a guy who took a QRP radio with him when
hiking and camping, his description of sitting next to the fire at night
making contacts with stations around the world on 5W or less was one of the
things that got me hooked on amateur radio and QRP/CW originally!
So I
think it will be fun to go camping in the wild with a radio again. With this
in mind I connected up my little R928+ QRP rig to make a few contacts using a
simple wire antenna, the plan was to make sure it works well before taking it
on a trip.
To my shock the moment I switched on the R928+ it went into
a diagnostic screen saying the "M1" key was pressed. This is a subroutine in
firmware that you can use when you build the radio to check that all the
controls work, you press any button and switch on, it will then go into the
diagnostic subroutine and you can press any key, the radio will display the
key pressed on the screen. Now this is great but there is no way to bypass the
routine if the radio thinks a key is pressed at switch on!
Looks like
the M1 key is stuck rendering the radio useless! I did loo to see if the key
is stuck, even opened up the radio but they key is not physically stuck, bad
news!
R928+ with the message showing the M1 key is stuck
I am quite sad about this, I love the little radio
and will miss it! Maybe I can find another one? If not I will be using my
Yaesu FT-817 again I suppose!
Update 2/11/2023:
I have been quite busy lately so I have
not been updating this page recently. I did manage to find some time to get on
the air, with good conditions I have managed to work a few interesting
stations, always fun!
Notable recent contacts include:
7Q6M,
Malawi on 10m, the station will be on air for 6 months but it is casual
operation, maybe I can work him on other bands!
W1AW/0, ARRL HQ station on
40m
GU4FOC, Guernsey on 12m for a new one on 12m
I have also worked
a few CWT sessions recently, the normal 40m opening during the early morning
session produced a bunch of US stations but still not the much wanted Wyoming
contact. The afternoon session coincided with a 10m opening to Europe so for a
change I could work some CWOps members outside the USA.
The Flex 5000A
is back on the shelve, it is a superb radio on SSB with great filters and a
nice user interface but it is really not a usable CW radio. Both Flex
innovations and the developer of the software simply refuse to admit there is
an issue, they have a real "head in the sand" attitude so when you ask
questions they walk circles around the issue. Oh well, think I will sell it as
it does not fit in with the rest of my collection, it is just taking up space!
Shame on you Flex Innovations!
I am still having my 1 hour plus CW
QSO's in the evening on 40m as well as the odd long chat to other stations,
fun plus good practice!
Update 30/10/2023:
I ended up only making a few contacts during the CQ
WW SSB contest the weekend. It was due to a combination of not feeling well,
less than perfect band conditions and it being SSB, not a good thing when your
voice is not happy!
I did work a bit of DX on the weekend. First
notable contact was the A25R expedition in Botswana. I did not really expect
to work them with 5W while their antennas were pointing somewhere else, they
had substantial pile-ups but I did manage to sneak in a quick contact on 20m
early in the morning before the pile-up became too loud. It was quite easy
once I figured out the way they were working stations up and down the band.
A25R o 20m before the band opened to the rest of
the world.
A second nice surprise was working T2C, Tuvalu,
on 17m CW, a new band slot! They were almost in my noise but still came back
to me after only two calls from my side.
T2C expedition members.
I was happy to see that I have received 2 QSL's for
Eastern Malaysia recently on 12m and 17m, both new band slots.
Another
pleasant surprise was to receive a certificate for our local "Spring day
SOTA", I managed to work 3 local SOTA stations on the designated day but did
not expect anything, so thanks Adele and Sid, it was a pleasant surprise!
SOTA (Summits On The Air) certificate.
I have been using the Flex-5000A the last few days.
I must say it is much improved with the latest software update, it now seems
to work perfectly on SSB but on CW there are still two issues that has caused
me to put it back up on the shelve. The first problem is the bug in the
software that does not allow you to set the volume of the CW side tone when
you are working split. The moment you activate the split option the CW
side-tone volume goes to maximum, not pleasant especially if you are using
headphones!
I did report this to the developer of the software but so
far no reaction, hopefully he is working on it!
The second issue is
still latency. It seems to be fine when you start but I have noticed if you
have a long QSO or if you call many times like you would when trying to work a
DX pile-up the latency slowly gets worse to the point where it is no longer
acceptable. This seems to happen quicker if you are running high speed CW. The
only way to get the latency back down is to stop the software, exit and then
re-run the software. This clears it up for a while. The fact that you need to
re-stat the software and not the PC points to an issue with latency and/or
buffers in the software and NOT to an issue with the PC and Firewire
connection as the developer seems to think when I mentioned this. This problem
makes the Flex-5000A not really suitable for CW. I will wait a while to see
what happens but if the problems are not solved I will sell the radio to SSB
operator who can enjoy the great receiver and filters!
Update 27/10/2023:
I am feeling better today, after
all the medicine I have been taking I should feel better, at least I feel like
doing something other than sleeping for a change!
I noticed that there
was a new version of PowerSDR, the software I use to run the Flex-5000A radio
available. A while ago I played quite extensively with the Flex-5000A and with
a lot of playing around with the many settings available I got it to the point
where it was working well on SSB. Unfortunately even my best efforts still
gave me too much latency on CW plus the software would hang/crash every now
and then if you were not careful when changing parameters or even basic
settings.
I downloaded and installed the newest PowerSDR software. It
started ok but I immediately noticed that there was no waterfall display. I
tried all the normal sensitivity settings but the waterfall remained black.
The normal panadaptor was working well. A search on the internet produced a
few cases where other users has the same issue. The suggestion was to reload
the software.
Rather than a complete re-install that would delete all
my settings I tried to re-install using the "Repair" option and it worked! I
think one of the files or modules that runs the FFT routines for the waterfall
display most likely did not update correctly the first time.
So with it
now working I tried CW again. There was still quite a bit of latency but at
least it no longer chopped of characters when you started sending, a good
start. I had a look at the RX buffer settings as I know this can have a large
effect on the latency and you need a smaller buffer on CW than on SSB, after
trying in the past to lower it from the normal 2048 byte default I had reset
it to 2048 bytes as lower values caused the software to simply crash. So I
tried to reduce it again to 1024 bytes for CW only.
This time it did
not crash the software AND the latency dropped to perfectly acceptable levels!
Great news, I just hope it stays like this as sometimes background activity on
windows can cause things to change.
I also noticed that when you now
make changes to settings and when you apply the settings the radio is paused
first, the settings are saved and then the radio resumes, takes less than a
second but it has stopped the hangs/crashes I had before! In his documentation
the person updating PowerSDR did mention that he did this to improve
stability. Well it works, thanks KE9NS!
Flex-5000A, does not look like much but once you
start using the software you will be amazed!
So with the radio now working better I looked around for some stations to
work. It was still a bit early for the bands to open but I did manage to work
a few DX stations on 15m, 12m and 10m. One interesting station was E2YOTA from
Thailand, there were also quite a few eastern European stations on 12m. I
managed to work all stations I heard without any problems, as in the past I
was amazed at how quiet the Flex receiver was, a pleasure to listen to!
E2YOTA, Youth On The Air special event station from
Thailand.
Some CW activity on 15m, the filters on the Flex is
really amazing!
Also take note of the DX Spots displayed above the spectrum
display.
The radio and software behaved itself perfectly, with the updated software and
settings the Flex-5000A is now definitely usable on CW. With it's superb
filters I think it will be a welcome addition to the DX side of operations, I
just hope it stays like this, I do not quite trust it yet.
I think I
will use it for while on CW and see, if it behaves for a few days and also a
few long CW rag-chews I might just change my mind on the range of Flex SDR
radios, time will tell. Maybe I will buy a Flex radio again in the future?
Time will tell.
Update 26/10/2023: I have not done
an update here for almost a week, this is mostly due to not being well so I
did not spend much time in the shack. I have not even switched on a radio the
last 2 days. I am feeling a bit better today so hopefully I will be on the air
this weekend.
Only QSO's the last week has been my 40m evening
chat, also listening for DX on the second RX, IC-7610
It is CQ WW SSB this weekend, normally I would
not compete but I would look around for interesting stations. I might do the
same this year but unless my voice recovers a lot before the weekend I will
most likely only hang out on the WARC bands and try to work some CW DX.
I am looking forward to CQ WW CW end of next month, with a good chance
that conditions will be great I am sure the bands will be packed with
interesting stations to work, maybe I can even add one or more DXCC entities
to my QRP CW totals.
Update 20/10/2023:
I have not worked any rare DX the
last few days, the band conditions were average, not exceptional. I did hear
the ZD9W expedition again but they were still to low to work with 5W, I am
pretty sure I would have struggled with 1KW as well as the pile-up was rather
unruly and between the QSB and the "tuner-uppers" I could only hear them for
short periods.
I did spend an hour on one of the four weekly CWT
sessions. As per usual I worked a bunch of US stations, most of them great
operators other than the one who insisted calling me ZS1C even after I tried
to correct him 4 times!
The one surprise during the CWT session was a
contact with XQ6CF, Chile, on 40m, a nice one as working Chile on 40 does not
happen often!
XQ6CF station
Unfortunately XQ6CF only QSL's direct ($2) and not via LoTW or any other
electronic QSL service, the problem with that is not the cost it is the fact
that the QSL will have to go via our local postal system so chances are you
will never see it! Fortunately I already have a QSL from another station in
Chile for 40m CW.
The weekend is almost here so I am hoping for a bit
more DX activity. I do have a birthday lunch to attend on Sunday but that
should not really interfere with a bit of DX'ing, now we just need decent
conditions, the sunspot number has been in the 50's this week so not ideal.
Update 18/10/2023:
I managed to get time to connect
the FL-2100Z to my 40m station yesterday. I am running the amplifier at
reduced voltage (1500V) since it produces 400W on 40m at that voltage and that
is more than enough for what I use it for, if needed I can flick a switch and
the plate voltage goes up to 2200V.
The amplifier still runs a bit warm but I
do now that is the way it is, I am simply not used to these valve amplifiers
that generate so much heat anymore. Maybe I must look at an extra, external
fan to keep things cooler like the one I installed on my Heathkit SB-200. That
amplifier used to run even hotter than the FL-2100Z!
Yaesu FL-2100Z amplifier ready for action.
DX conditions have been good the last few days,
with quite a few DX'peditions in rare locations there is always something to
try and work.
Notable contacts added to the logbook include:
OY1CT - Faroe Isle - 10 CW
T2C - Tuvalu -
30M CW
SV5AZK - Dodecanese isle - 12M CW
D2UY
- Angola - 12M CW
WP3A - Puerto Rico - 12M CW
I
have worked OY1CT on quite a few bands in the past, he is normally on 12m so
it was a pleasant surprise to hear and work him on 10m.
OY1CT, very active and a great CW operator!
T2C was a nice surprise, I was looking for TO8FH on 30m but could hear nothing
on the band other than a very weak signal in the noise. Eventually I could
make out the call and it was T2C, Tuvalu! Even though he was so weak I just
had to try.
Well, it took at least 30 minutes, maybe more, sometimes
he dropped right into the noise so I had to stop calling but eventually he
came back with "Z??", a few more repeats of my call and we completed the QSO.
I assume he was running at least 100W, most likely more so if he was so weak
on my side my 5W must also have been very weak!
T2C, I have now worked them on 2 bands but it was
not easy!
Another surprise was D2UY, Angola on 12m, we are a bit close to Angola for 12m so I did not expect to hear him but I am not complaining!
D2UY, Angola, in his shack.
With the DX
conditions improving it looks like we are going to have lots of fun over the
next few years. I am also looking forward to CQWW CW end of November, I can
just imagine how busy the bands will be. I have not decided if I am going to
try to compete or just look for interesting stations but either way it will be
fun!
Update 17/10/2023:
I was quite busy yesterday so I did not
spend much time in the shack but I did mange to work a bit of DX late
afternoon and I also had my regular CW sked on 40m.
I did not work
anything special, the TO8FH signal was strong on all bands other than where I
need him, seems like they do not spend much time on 30m. 6m was also open late
afternoon but I only heard activity on FT8 and it was the usual mix of
Southern European stations so I did not bother to work any stations, FT8 is
not only boring it seems too easy, you click and the computer does the rest.
You can even automate the whole thing (and I know some people do) so you do
not even need to be in the shack to "work DX", no thanks!
These 2
contacts did stand out in the log:
E70Y - Marin
Pavlovic - Bosnia and Herzegovina on 10m CW. not many stations on the air from
this country!
FR5FC - Reunion Isle - BENARD PATRICK - on
10m SSB
E70Y, Marin Pavlovic
I actually worked FR5FC on SSB (yes, I do own a microphone!)
running 5W, he was 59+30db on my side and gave me a 58-59 report. What made it
notable was that we actually had a nice chat and not just the normal signal
report exchange. Interestingly he was also running an IC-7600 like me but he
was outputting 400W against my 5W.
I was nicely surprised to see that
the FO/F6BCW QSL has arrived and it is not only a new one on 10m but it is an
all-time new one on QRP, I have worked a FO station before with QRP but never
received a QSL.
FO/F6BCW, French Polynesia QSL
So far the bands have been quiet today, maybe
things will improve later. I did manage to have a nice QSO with a ZS1 station
I have not worked before, always great to hear some new local CW operators.
With little activity on the bands I decided to give my old Yaesu FL-2100Z
amplifier a bit of a service as I want to use it for the local morning and
afternoon SSB nets. I switched it on a while ago but it seemed to run quite
hot with little airflow so I had a suspicion that the fans needed cleaning and
oiling.
It turned out that the amplifier was nice and clean inside, it
has hardly been used in the 25 years I have had it but the problem was the old
oil in the fan bearings, the fans were hardly turning. I removed the fans and
cleaned the bearings with solvent before oiling them again. Now the fans are
running nicely and they now move quite a bit of air. I will connect the
amplifier to a radio and use it this afternoon if I have time to get on air.
I might not get time though as I still need to do a few things to prepare
for a hike and a photo shoot tomorrow, lets see what happens....
Cleaning and re-oiling the Yaesu FL-2100Z fans.
Update 15/10/2023:
The number of solar spots were a
bit down today, only 85, but even though signals were a bit weaker there was
still plenty DX to be worked.
Here are a few of the more interesting
stations I managed to work today:
FO/F6BCW French
Polynesia on 10m, I need to check but I think is might be a new one on QRP!
4U1A United Nations Amateur Radio Contest
DX Club on 10m
EE7RW Special event on 10m and 17m
EE7RW special event station commemorating the life
of EA7RW.
4U1A
station location at the UN
4U1A station.
I could hear TO8FH on all bands other than 30m again. It seems that they only work 30m certain times of the day and unfortunately those times do not coincide with good propagation on 30m in that direction. But I will keep a lookout for them, should be easy to work them if they are on the air at the right time.
Listening to a pile-up on 12m, was a Greenland
station but his signal was really weak and his CW was terrible!
I decided to split my station into three sections
today, I will have a radio with antennas (dipoles) dedicated to 80m, 40m and
30m. Since I will also use this setup for local SSB chats a linear amplifier
will also be connected.
The second setup will be dedicated to
DX'ing on 20m to 10m using the hex beam antenna. There will be no amplifier
connected here as it will be QRP only.
The third setup will be
dedicated to 6m using my 6 element 6m yagi, I will most likely also connect
one of my Henri 6N2 amplifiers here if I feel it is needed, right now I will
be running only 200W from the Yaesu FTdx-5000MP. I might add 8m to this setup
as well I just need to either buy or build a decent antenna.
There will
also be a dedicated satellite and VHF/UHF station.
This setup will
allow me to monitor other bands when I am busy working DX on one, hopefully
this will result in less missed opportunities and more DX contacts in the log!
Update 14/10/2023:
DX conditions have been good the last
couple of days and it is still getting better! I am still only hunting for new
DXCC entities or at least interesting stations. As conditions improve the
pile-ups are getting bigger but it is also becoming easier to work the
stations with 5W. The next few years should be quite exciting on the HF bands!
Notable recent captures include:
TO8FH Mayotte on
10m, 12m and 17m, still looking for 30m
T2C - Tuvalu on
17m, was quite surprised to hear them here as I have not been able to hear
them on any other band. They replied after my first 5W call!
W8S
- Swains Isl. on 17m. Also the first band I could hear them on.
Bands I have worked TO8FH on, only 30m remaining unless I put up a
80m antenna!
T2C
DX'pedition to Tuvalu.
After a long period of not adding much to my
QRP DXCC totals it is great to see them climbing again!
I have been
using the IC-7300 for DX'ing and chatting the last 10 days or so. I decided I
need to give the radio a decent chance by getting to know it well and I must
say I do like the radio. I think it might well be one of the, if not best
radios as far as the price/performance ratio goes. The one radio that could
give it competition could be the Yaesu FTdx-710, it is a bit cheaper and it
has a substantially better RX but I cannot vouch for "usability" until I have
used one. It sure is on my list of radios to look out for
Update 12/10/2023:
I have been having lots of fun with
amateur radio recently. Band conditions have improved so I am making regular
DX contacts mostly searching for rare stations and expeditions.
Recent
notable captures include:
TO8FH - Mayotte on 20m and 40m
5W0LM -
Samoa on 20m
As I mentioned a few days ago I was nominated to become a
member of the CWOps group, a group dedicated to CW. After nomination enough
members must confirm recent contacts with you at 25wpm or faster. I received
the good news yesterday that I have now qualified! I am now a proud member of
this exclusive club, my membership number is 3420.
CWOps membership certificate.
I have been taking part in the 4 one hour CWOps cw test sessions every week, lots of fun to work stations at high speed, all the stations have operators who are really great at CW, a pleasure to have contacts like these! I am still hoping all these contacts with mostly US stations will produce that elusive contact with a Wyoming station.
Lots of CW activity on 20m during CWT session.
Recently I have
seen these strange signals on quite a few bands, wonder what it is?
We have had a few 6m TEP openings to Europe recently, something that
happens this time of the year. What I did find interesting was that my
transmission was received by Dick, ZS6BUN about 860km from me. This distance
on 6m is a bit unusual and was mostly likely caused by sporadic E, he received
me at +4db so the signal was quite strong. Unfortunately he did not reply,
most likely his station was in monitor mode only so there was no QSO.
6m signal report from ZS6BUN
Encouraged by the 6m activity I have now assembled my long boom 6m yagi, have
not used it for more than a decade! Now I must just get it high up in the air,
that is another challenge!
Update 10/10/2023:
DX conditions have been up and down
the last few days, when the higher bands are open they are great but then
suddenly there will be nothing!
Over the last few days I did manage to
catch some notable DX, here are a few of the stations that I have worked for
new CW QRP band slots, these are the ones that have already confirmed via
LoTW.
V31DL - Belize
A61R - UAE
9V1ZW - Singapore
9A7AA -
Nepal on a few bands
EL2BG - Liberia
ET3AA - Ethiopia
3C3CA -
Equatorial Guinea on a few bands
I also heard ZD9W (Tristan da Cunha &
Gough) on 12m but his signal was in and out of the noise. Strangely I could
hear him best with my antenna pointing south, not the direction that should be
best. The signal also had a strange "flutter" so I think we had some unusual
propagation at work. I did try to work him but his pile-up was huge so between
his weak signal, my 5W, all the stations running high power and also a few
tuning up right on top of him I had little chance. I do not need ZD9 for a new
country but it would have been fun!
ZD9W pileup on 12m, I have not seen/heard this many
CW stations for a while!
I have been making my semi regular sked on 40m in the evening. It is
interesting to note that 40m now seem to open for DX every morning and evening
after a long period with little activity. I managed to work quite a few DX
stations including a bunch of US stations in the morning. I am still looking
for Wyoming on CW running QRP so I m working more US stations than usual. In
the afternoon the DX that can be heard is usually the unruly mob from
Indonesia so I don't even try.
The 40m band has also been quite active
locally during early evening, also quite unusual, normally it is only CW that
is usable locally on 40m during the evening due to the weak signals but
recently I have seen/heard quite a few SSB QSO's as well.
Here I am busy with my evening sked on 7.025 but you can see quite a few SSB
QSO's in progress higher up the band.
I have still received no news on the 2.4GHz pre-amplifier for my satellite
station, actually even worse than that my last 3 messages to the supplier on
other equipment has not been answered/ignored so I am now looking for a new
supplier. Seems like I would have to unfortunately import the equipment
direct. So much for "support the local small business".
I am looking
forward to the 4 CWOps mini contests this week, love working the stations with
great CW operators at a decent speed and since many of them are from the USA
maybe, just maybe I will snag Wyoming this week, there is always hope!
Update 6/10/2023:
I have been rather busy the last
few days so did not get much time to update here. The good news is that some
of the "busy" was working DX!
The bands have been a lot better the last
few days with 10 and 12m open quite late into the evening. Signals are often
weak but workable. I often call CQ a few times, even if I do not get a reply
as it often happens during a working day I then have a look at the Reverse
Beacon network to see where I was heard and how strong my signal was. This
gives me a good indication of where to beam and also what DX'peditions I can
expect to work.
In general I seldom call CQ as I am more interested in
"rare DX" than just working volumes of calls from the countries with lots of
amateurs.
Results from a CQ call on 12m, band is open!
A few notable stations
worked the last few days include 5X3K (Uganda) and S01WS (Western Sahara),
both new band-slots. There are also a few other DX'peditions on the air at the
moment so with the better conditions the hunt is on!
I was recently
asked if I would like to become a member of the CWOps group (cwops.org).
This is a group that caters for more advanced CW operators, they try to
promote CW in general and specifically better and faster CW. They also run a
CW academy where you can improve your CW. To join you first need to be
nominated by a current member who needs to state why he/she thinks you qualify
to become a member. Once that is done you need 3 members to support your
nomination by specifying that they have worked you at least twice in the last
12 months at 25wpm or faster.
I have been nominated but the "problem"
is that since the majority of the members are from the USA, and I don't really
work US stations unless in a competition, I do not think I have the required
contacts to become a full member. Fortunately the CWOps group run 4 one hour
CW "contest" sessions a week where you can make contacts with members. These 4
timeslots are spread over Wednesday and Thursday every week. I have so far
managed to be active during 3 of those sessions. Conditions were terrible
during once session, it was simply the wrong time of the day, mid morning, for
the band to be open.
The early evening session was quite productive on
20m and so was the early morning session on 40m. I have not heard that many CW
signals on 40m for a long time! The signals on 20m were reasonably strong but
the 40m signals were quite weak. I did manage to work about 35 CWOps members
during those sessions with my 5W. Now I need to do it again next week to
hopefully get contacts with some of the same stations so that they can then
support my nomination.
It is fun chasing some contacts again plus,
with a bit of luck, I might just end up working a station in Wyoming, the one
US state I still need for WAS CW QRP. I am having fun and that is always a
good thing!
Lots of CW activity on 40m
Not much news on the
equipment side. I did get a lead on a IC-7800 but I must admit after doing a
bit of homework on the radio I am not that sure I really want the (rather
expensive) radio in my collection. Main issues are dim screens, something
fixed in the later IC-7850/1 model and also many reports of blow finals, some
of them many times! Since there is almost no technical support locally for
Icom radios either of those problems would make the radio worthless.
Since the receiver has a rather average performance I am trying to
decide if it is worthwhile adding it to the collection and maybe not using it,
I need to decide soon......
If I could get an IC-7851 it would be a lot
better but at the moment, with our bad exchange rate they are horrendously
expensive! A new Yaesu FTdx-101MP would not only be cheaper it is a far
superior radio as far as performance goes.
Update 4/10/2023: I managed
to work some decent DX yesterday late afternoon and early evening. 10 and 12m
were wide open. Amongst the interesting stations worked were 5X3K (Uganda) on
12m CW and 9N7AA (Nepal) on 10 and 12m CW. Both these new ones were easy to
work with 5W despite the fact that they were working split with large pile-ups
and I was at the back of their antennas. Having a "full/real" second receiver
complete with it's own VFO knob on the FT-1000D helped so did the spectrum
display zoomed in that allowed me to see where the station was they last
worked.
I did call CQ (with 5W) on 10m and it was interesting to see
that I was heard in Europe and North America, did not try to turn my antennas
east or west to see in those directions, if the band opens again today I will
try that.
Reverse beacon results showing a few stations that
heard my 5W CW CQ call.
May there be many more openings on the higher bands
this solar cycle!
Update 1/10/2023: I decided
to add a spectrum display to my trusty FT-1000D, since the FT-1000D has an
external IF output (73.62MHz) this was quite easy. Using a RTL SDR dongle and
the superb SDR Console software I only needed to make up a cable with a RCA
plug between the dongle and the radio.
The results are great! You can
see a huge section of the band or zoom right in. You can also control the
radio directly from SDR Console, using the CAT connection and Omni rig
software, this allows you to click on a signal displayed on the screen
and the radio will QSY there. You also have the option to listen to the signal
directly on the computer where you can change modes and use the DSP filters
and noise blankers provided! This gives the radio features that competes with
the newest top end radios at a better price and build quality. I think I will
use this as my "main radio" for a while to see if there are any issues that
might make it less perfect than what it appears to be! It would be easy to do
this with other similar radios, I intend to do it with a few radios in my
collection.
Listening to a SSB signal on a rather noisy 40m
band using the FT-1000D and SDR Console software.
Update 30/9/2023: Unfortunately it turns
out that I was right about the fact that the TX pre-amplifier I received from
the supplier for my QO-100 station is in fact not the correct one. The output
is very low, more like what you would expect from a receive pre-amplifier. The
result is that you do not have enough power to drive the final amplifier to a
decent level. I did discuss this with the supplier but he simply said no, it
is the correct one. I have now received a message from him saying he is
getting better pre-amplifiers in that will provide more drive, oh well, won't
say "I told you so!"
So for now the QO-100 station is on hold.
DX has been quiet, there are some stations but nothing interesting, I hope it
will get better soon. There is a 5X DX'pedition starting I think today, since
I need Uganda on a few bands for my QRP CW DXCC I will be listening for them.
Update 27/9/2023: With some better
weather I managed to get some work done on my QO-100 Satellite station today.
After trying one more time to get the 120cm dish going I gave up and removed
it (not fun!) and replaced it with the little 70cm dish. I used the same LNB
and cabling.
My first attempt to get it aligned did not go well, same
results as with the larger dish! Could not believe it! I decided to see if
there was another issue. I did ask my supplier if the LNB he supplied was
standard or modified but he never replied (guess the items I have in my
shopping cart on his web page will stay right there!)
Anyway, I decided
to give and old DSTV LNB I had lying around a go. Once it was on the dish I
could actually see very weak signals! I quick trip up the ladder armed with a
laptop and a spanner was all that was needed, finally decent signals from
QO-100! To say I was happy would be a mayor understatement!
What a fantastic sight! Signals from QO-100!
The LNB was drifting quite a bit but fortunately
the SDR Console software allows you to lock on the beacon, once I had that
configured the frequency was rock solid.
Next task was to setup the
transmit side. I did not expect much due to a few things. Firstly there was
the dish that is a lot smaller than the one used in the original "power
needed" computations. Next there was the suspect pre-amplifier and to crown it
all the transmit antenna is only a small, linear polarized yagi antenna, not
circular polarized as it should be for QO-100.
Test showed that I could
just see my transmission on the QO-100 transponder. At least the signal was
strong enough that I could calibrate the TX/RX frequency so that I can
transmit on the frequency I am listening on. I might just have enough power
(no idea how much but most likely around 1W) to make a CW contact, will try
tomorrow if I have time.
So how to improve my signal into the bird?
There are a few options. I can try the larger dish again, but I am reluctant
due to it's mounting requirements especially taking the high winds we often
have into consideration. Next I could (and I should) replace the TX Yagi with
a decent helical antenna. I would have to build my own as there are non
available locally. They are not that difficult to build if you have a 3D
printer (I do have one) but my problem is that at this stage I gave no way to
measure the SWR on 24GHz. If I get it wrong I could damage my (expensive)
amplifier.
I think I need to acquire a VNA, it will be useful to build
antennas at the higher frequencies and will also be usable on my HF antennas.
Another option would be to increase my transmitted power, firstly I could
(and again I should) get a decent pre-amplifier that outputs at least 200mW,
not the measly 12mW I am getting now according to the specs of the one I have
now. A second option would be to run my amplifier on 24V. It can run on 12-24V
but will only produce it's rated power at 24V.
I think I will take as
many of the steps above as I can and see where I end up. I did listen to a few
QSO's CW and SSB, reception and signal strengths are fine on the small dish.
A CW signal received on 10GHz, a first in my shack,
the signal has travelled around 70 000km to get to my receiver!
No DX'ing today, I was too busy, tomorrow also
does not look good as I will spend most of the day on a 300km shopping trip, oh
well, sometimes you have to do other things as well....
Update 25/9/2023:
Not much activity
on the dx bands, well maybe there was activity but not many strong signals. We
had lots of rain, very strong winds, over 80km/h and lightning for 2 days so
the static levels were horrible! Even if there were weak signals I would not
have heard them!
Due to the weather I have also not made much progress
on the QO-100 station, during a brief break in the weather I did attempt a
quick adjustment of the dish, just guessing and yes, it did make a slight
improvement but not much. I did notice something that could be a problem, when
I was finished and went to remove the ladder the wind had increased in
strength again, maybe gusting around 20-23km/h. There was quite a bit of
movement in the dish, enough to surely cause a problem.
I think my
mounting arrangement for the dish is simply not sturdy enough, the bracket,
that I did reinforce a bit, was used for a 70cm DSTV dish in the past. I
really need a more sturdy mount but there is nothing available locally. I will
try to order something but I think I will give the 120cm dish one more try, if
I cannot get it aimed accurately and consistently I will take it down and
replace it with the 70cm dish.
I know people are making contacts from
EU with dishes as small as 35cm so I should be able to make contacts with the
70cm dish from a position where the satellite is higher above the horizon (and
thus closer) than in Europe. Lets see what the weather does over the next few
days. Unfortunately I have a day trip to make this week for some shopping and
then I most likely need to go to the yacht, a 1000km each way trip, for a week
or so. Would love to get the station working before the interruption!
I
have been using the IC-7300 again for the last few days, mostly to get to know
it better before taking it to the yacht. I am enjoying the little radio but I
do find one thing irritating. When looking for DX I would often jump around
bands and modes to see where there is action, easy to do on most radios, you
simply press the desired band button once and you are on the band, a second
press of the button will move me between the CW and SSB segments of the band.
Very convenient.
To do the same on the IC-7300 I need to press the MHz
portion of the frequency on the display (make sure you tap accurately!), then
I need to tap the correct band on the display. This will take me to the band,
if I want to move between the different segments on the band without spinning
the VFO a lot I need to repeat the tapping exercise. It takes at least 3 times
as long!
I do like touch screens, they make life easy in many
applications but they are not a solution to everything.
For my evening
CW chat I decided I needed a change so I connected up the trusty old FT-1000D.
My first impression was again how great the receiver sounds, QRM/QRN simply
seems less disturbing and signals jump out from the noise. The modern SDR's
are great but old school radios do have advantages!
Having a CW QSO while also listening to a bulletin
on the FT-1000D, love the full second receiver!
Update 23/9/2023: Not much to report today
other than a bit of progress on my QO-100 station.
After initial
alignment using a compass and inclination app on my phone I connected
everything up and started looking for the QO-100 signals. It was a bit of a
"hunt in the dark" as there were many variables. I had to get direction
(azimuth) and elevation within 1 degree and then I had to search for the
signal. The problem was where to find the signal from the down converter.
Depending on who you speak to or where you read the info there were 3 options.
Around 950MHz (according to the official specs of the LNB) or either around
750MHz or 739MHz according to the internet.
The "around" bit is due to
tolerances in reference oscillators, not that accurate at the high
frequencies. Once you have the reference beacon you can calibrate your system
but you first need to find it.
My first attempt produced no signals on
any of the potential spots. I realigned the dish, thinking maybe it moved a
bit when I attached all the cables. It was a bit off but still no signals.
When I checked it again and it was off again in direction I became suspicious.
A few test quickly showed where the problem was, it was not the dish
moving it was inconsistency on the compass app! I tried 3 different phones
getting different results, the one app was so bad it was sometimes 90 degrees
off! The best app I tried on the apple phone was still not consistent with up
to 6 degree variations between attempts on something a solid as a brick wall.
So a plan B was needed. I checked the wall of the house against Google
Earth, interestingly my "north facing" house was almost 18 degrees off from
north, actually it is aligned with the streets in my town but the whole town
is at an angle, and it is not even in the direction of magnetic deviation so
that cannot be used as an excuse!
Anyway, it is difficult to get the
exact variance of the "north facing" wall and true north but I managed to make
a rough calculation and point the dish where I guessed north is. Searching for
the signal again I finally found weak signals around 739.550MHz. Unfortunately
by then it started raining so I had to abandon my efforts but at least I have
now eliminated a lot of the guess work.
Once the rain clears
(prediction is for the rain to persist for 2 more days!) I will take a laptop
outside up the ladder (about 5m high) and adjust the dish in real time for
best signal.
It is really time to get this station going, there is
still a question mark over the transmit pre-amplifier so my next problem could
well be producing enough RF to get into the satellite, oh well, we will see.
The DX bands and especially 10m was open till early evening today, there
was a RTTY contest (CQ WW RTTY) going so all the bands were crowded but it was
fun.
Talking about crowded bands, I am sad to say the behavior of some
of the local hams leave a lot to be desired, they will simply go and park on a
frequency, regardless if there is DX activity there, run maximum power and
simply talk over the DX. If you should dare to point out to them that the
frequency is in use you get blasted. Even worse they have no problem sitting
chatting on SSB in the CW portion of the band or right on top of a beacon. I
must stress it is not everyone, but there are a few.....
Update 22/9/2023: As a change I
decided to connect up my old FT-1000D for my CW sked last night, have not used
the old lady for a while! My first impression was how quiet it was but the
signals were still strong, there is much to be said for older top-end radios!
As it turned out my sked was cancelled at the last moment, since I was
already in the shack with the radio on I decided to tune around a bit, glad I
did! I managed to catch, amongst others, EL2BG (Liberia) on 12m as well as
E750ESP (Radio club "Stjepan Polje" - Bosnia-Herzegovina) on 30m, both new
band-slots. Should do this more often!
I managed to get the satellite
station dish mounted this morning and roughly aligned with the QO-100
satellite as well. I have now measured, cut and soldered all the cables as
well other than the TX cable that still needs one connector. I found a nice
12V to 5V converter, used to be a power supply for a GPS so I will use that to
supply the 5V needed by the Pluto Plus 2 SDR and the 2.4GHz pre-amplifier. My
2.4GHz amplifier can be run on 12-24V so I think I will initially try it on
12V, I should only need 5W but if it proves to low I do have a 12-24V
converter, used to be a mobile charge adaptor for a laptop, that can be used
to boost the output.
Finding all these bits and pieces in my "scrap"
store just shows that you should never dump anything!
I should be able
to start testing the satellite station tomorrow. First I need to get the
receiver to hear the signal from QO-100, hopefully the dish alignment is close
enough that I can get some kind of signal. Once I can see the 3 beacons on the
waterfall I can fine-tune the dish and the LNB skew to get a better signal.
Next would be frequency calibration and locking the frequency to the
center beacon. Once that is done TX testing can start, I need to get the TX
setup to the point where I can get a decent signal into the satellite. Then
the TX frequency must be aligned to the RX frequency.
We do have
extreme weather conditions predicted for the next 3 days, up too 100km/h wind
gusts, hope the dish mounting bracket survives!
When I looked at
Logbook of The World today I was pleasantly surprised to see a QSL from 9N7AA
(Nepal), I was worried he might not QSL, thanks!
9N7AA confirmation, new one on 12m CW QRP for me.
Update 21/9/2023: I tried to
upload a video yesterday but it did not work, the server reported "Format not
supported", oh well, I might still upload it to YouTube and post the link
here. The only problem with that is that I will have to do more editing, to
maintain the "rating" of my YouTube channel the videos need to be of a certain
quality. What I wanted to show was how well the QRM Eliminator works and also
a clip showing a CW contact on the IC-7600.
I did manage to make a few
DX contacts yesterday but in general the conditions were still very poor. Late
afternoon things improved a bit but by that time I was busy on a local net. My
evening CW sked also went well with a few more people joining.
I did
not make any progress with my QO-100 station yesterday, it was windy again and
I was rather busy.
This morning there was little wind so I started
early with the project to get the dish mounted. I managed to get it into
place, with no help, but that did not really help! Once mounted I started
aiming it, it needs to aim 2.7 deg east of north with an elevation of 51.2
degrees, and that is where things went wrong! I can only get up to about 47
deg elevation before that back of the dish touches the rain gutter! So back to
the drawing board. I have 2 options, get a mounting bracket that sits a bit
further from the wall, but none are available locally and even if I order
online the longest one I can find will still be marginal.
The second
option is to modify the bracket I have so that the dish sits about 100mm
higher. Fortunately I have the materials (pipe) required to do that so that is
the way I will go. Unfortunately the wind came up again so maybe tomorrow
morning.
I did make up the RX and TX feed lines and I mounted the LNB
and the 2.4GHz transmit antenna on the dish before getting it into place. I
noticed that it will be rather difficult to do it once the dish is in place,
at least that is now done.
Slowly but surely we are getting there....
While listening around the DX bands today I came across a strong signal on
12m, it was 9N7AA, Nepal, I quickly worked him (on CW) for a new one on 12m. I
do hope he QSL's, I notice that I have worked him on 15m and 20m in 2000 and
he never QSL'ed.
The IC-7600 is working well and I am enjoying using it
both on SSB and CW, I think this one might just remain at the "operating"
position for a while.
Update 19/9/2023:
As I suspected the issue with the
IC-7600 delivery was simply tracking as it arrived early this morning!
A quick check confirmed that there was no transport damage, everything looked
good and as reported the radio is in a good condition. Once I had it running I
noticed it was running ancient firmware, version 1.01! Lots of nice features,
like a waterfall display and more filter options, were added in later versions
so my first task was to upgrade to the latest (V2.0) before doing anything
else.
Once that was done it was time to setup the radio and make a few
contacts. Setting it up was easy, the setup is somewhere between the
IC-756Pro3 and the IC-7610. Unfortunately by the time I had all that sorted
out there was a solar flare that wiped out the bands completely! Oh well,
maybe things will get better later in the day or tonight.
IC-7600 up and running with the updated firmware.
Different screen configuration with a larger spectrum scope and smaller meter
and frequency display.
One thing I did notice
while setting up the radio is that for some obscure reason only Icom will know
you cannot key the radio in CW mode via the USB connection. It is not a major
issue but now you need an extra cable, it would have been so easy to implement
this feature in software like they have done on the other radios that have a
USB interface.
The radio sounds good on RX and the filters and noise
reduction seem to work well but I will only really know once the bands improve
and I can make a few contacts.
The wind was blowing again today so no
real progress on the QO-100 station or the dish installation, I need to get
the dish sorted out before I can finalize all the cables and get the station
running.
Update 18/9/2023:
I spent most of the day working on
the QO-100 station. The mounting bracket for the dish is also installed but I
could not install the dish. It is a bit large to get it to the top single
handedly and get it mounted on the bracket all while balancing on a tall
ladder! The fact that the wind came up and was gusting up to 50km/h did not
help either!
I would either need help to get it up or I need to devise
a way to hoist it and keep it there while I then maneuver it into place. Once
that is done I need to align it with the satellite, it is not going to be easy
being high and with very little space to get behind the dish and make
measurements and adjustments. Not going to be fun!
Still waiting for
the IC-7600, if the tracking is accurate it has been sitting in one place for
4 days, if there is no action by tomorrow I will call the courier company, it
might just be the tracking that stopped, it has happened before, suddenly you
just get the delivery.
Late afternoon produced some DX on 10m and a
good chat on 40m, conditions seemed to be slightly better. Interestingly the
40m band now opens very late in the afternoon (after 16:30 local) for local
contacts and about 30 minutes later it also opens for DX! Had my usual CW sked
as well at 19:00 local (17h00 UTC) and conditions were good enough to run 5W
for easy copy.
Update 17/9/2023:
I was up and in the shack quite
early this morning to try and catch some DX. I found some activity on 40m and
20m. There was a "salmon run" contest running in the USA so I made quite a few
contacts including the "bonus/control" station of W7DX. Was fun to work a bit
of CW DX, signals were not strong, maybe around S2-3 but no problem working
the station on 5W from the IC-7300 into a dipole for 40m and hex beam at about
8m for 20m.
I am making progress on the assembly of my QO-100 ground
station. I have now done all the soldering and cable assembly with the
exception of the final connections to the dish. I will only do that one the
dish is installed and everything is where it should be, that way I can make
sure the cables are exactly the right length, at these high frequencies losses
are high in the cables so they should only be as long as absolutely needed. I
still need to make up the power harness as well, also waiting to complete the
installation first.
I do need to decide what I am going to do for the
5V power supply, the Pluto Plus 2 needs 5V, up to 3A and the little 2.4GHz
pre-amplifier also needs 5V, what amperage I have no idea as it is not
mentioned anywhere. Will check the current draw once it is running, should not
be more than 1A I think. The Pluto will get power via the USB cable but it
does have a second USB connector for additional power so I want to connect
that as well.
All the software is setup and the Pluto is
working well, I tested the receive side with 145MHz and 30MHz transmissions. I
have now completed the assembly of the 2.4GHz transmit antenna that will feed
the dish. I connected this antenna to the Pluto and used it to TX tones on
2.4GHz (drive set to 0 gain so no idea how much power but very little). Since
the Pluto is full duplex I could monitor the signal on the RX side and it
sounds good and looks clean on the scope.
I still need to test the CW
TX but since I will be using a tone injected on a SSB signal I am sure it will
be fine. To generate the tone I will use the CWType program. It allows you to
connect a key or paddle to a serial port, works well. It can either key a
transmitter through a serial port (real or virtual for a SDR) and/or sent the
tones to a sound device. By using a virtual sound cable you can then use the
tone output as input on the SDR software to transmit the CW. It works on the
Flex so it should work the same on the Pluto.
The 1.2M dish is now also
assembled and I have the mounting hardware ready and the location has been
decided. All I need are 4 rawl bolts, will hopefully be able to get them
tomorrow morning from the local hardware store.
Almost ready to begin
the bit I am not looking forward too, aligning the dish! But it needs to be
done before the fun can start.
I was hoping for some more DX late
afternoon but conditions were not great. I did end up having a few nice CW
QSO's with locals, sometimes it is nice to have a good chat not just a signal
report exchange.
Hopefully I can make some good progress on the QO-100
station plus the IC-7600 might just arrive.
Update 16/9/2023:
I received a call early this
morning from the local courier agent asking if I can please come and pick up a
parcel that would not fit in his car, I was there in a flash!
The
parcel was my QO-100 satellite station equipment. The component that made it
so large it would not fit in his car was the 1.2m dish, fortunately it did fit
in my car!
I had a quick look and everything seems to be there with no
shipping damage. I am still concerned that I was supplied with the wrong
pre-amplifier but the supplier insists that it is the correct one, we will
soon see!
There are a few small things missing, some like 2 power
supplies because he did not have stock and a few other things like cables and
connectors because they were forgotten. No big problem, I have power supplies,
spare coax cable (for the LNB) and connectors for the LNB cable. I received 1
power injector, all he had in stock but I need two, again no problem as I can
supply the pre-amplifier direct with the needed 5V as it is going to be close
enough to a power supply.
I loaded the Pluto plus 2 drivers and
installed the SDR Console software on my shack computer. Once I connected the
Pluto plus 2, via a USB cable, the software detected the Pluto and it is
receiving. I will test transmitting later when I have an antenna. The Pluto
can also be connected to the computer with an Ethernet cable, will try that
later but I think I will run it connected with a USB cable as the whole
"station" will be mounted outside just below the dish and that is less than 2m
away from my shack computer.
I am writing a separate blog on assembling
the station and using it, you can find it
HERE, there is
also be a link from my main page.
The Pluto Plus 2 SDR transceiver, 2 separate 70MHZ
to 6GHz transceivers in a very small box.
Now I am still waiting
for the IC-7600, hopefully it will be here Monday, at least I have something
new to play with this weekend!
Update 15/9/2023:
The DX bands were not great today
but there were a few stations around. I managed to make a few contacts but
nothing special. One call that did attract my attention was OH73ELK. I looked
it up and it is a Finnish holiday home (you can rent it) on a forest island in
a lake! Looks like a wonderful place for a holiday with some DX'ing added.
They have quite an impressive antenna array that visitors can use.
I am
still using the IC-7300 in the shack and will most likely use it till the
IC-7600 arrives. It is working well and I am really glad that I decided to
finally get one. Hopefully I can complete my mini review soon.
Looks
like my QO-100 satellite station equipment can arrive any moment, I am really
looking forward to getting it running. Interestingly many people on the forums
are saying that it is difficult to do CW using a SDR on QO-100. I do believe I
have a solution (based on what I did to get CW running on the Flex-5000A
without high latency). I hope it works, if it does I will share the details.
The IC-7600 will most likely only be here on Monday but that is ok as it
gives me more time to test and get to know the IC-7300.
I did receive
the roll of LMR-400 coax cable I ordered today, I am still waiting for the
connectors but as soon as they arrive I will be replacing all the old RG-213
cable in my station.
I have a CW sked later tonight with an old friend,
I am just hoping my antenna will still be up by that time, we are having a
huge wind storm today with winds up to 100km/h, so far it is ok but the way it
is blown around something could break any moment.
Late evening update:
Well my CW sked did not work out, most likely due to load shedding on the
other side. I listened a bit up and down the 40m band and I was amazed at all
the strong signals! The band was open not only locally but there was also DX
all over the place. Had a nice chat to a few guys and received great
unsolicited audio reports, looks like the IC-7300 is a great all-round radio!
Update 14/9/2023:
The bands were not great for DX'ing
most of today but I did manage to work a few CW stations on 20m early evening.
It was fun to use the IC-7300 on CW running only 5W. I have not tested the
receiver under crowded conditions yet but it seems to perform well.
One option that I am missing from my "larger" (more expensive...) radios is
the dual watch (Icom) or dual receiver (Yaesu) option. I think it will be more
difficult to work a DX station running split, yes, it can be done but you will
either have to guess where to transmit or keep on pressing a button to listen
to your TX frequency. Having said that it needs to be remembered that other
radios in this price class also do not have that option, I am just spoiled.
While on the subject of the IC-7300, I am busy writing a little "mini"
review on it, mostly just about what I like, and what not, about the radio. I
opened it up today to have a look at the quality of the components and general
quality of things like the soldering. I can just say I am impressed! I will
post a link to the review as soon as it is finished, I just want to use the
radio under more crowed conditions first, hopefully this weekend will produce
more activity.
I received confirmation this afternoon that the IC-7600
has been shipped, should have it early next week.
Talking about
shipping, I ordered a roll of LMR-400 coax cable and it arrived today. I need
it to run new coax up the mast of the yacht but I also want to replace all the
coax at my home station. Most if not all of it is RG-213 and at least 30 years
old. I recently replaced a few connectors and I must say I was shocked to see
how corroded (blackened) the shielding is, over the years the coax has been
exposed to a lot of heat and moisture. It can only improve my station!
While looking at the tracking information I noticed that the equipment for my
QO-100 ground station is also close now, might even get it before or during
the weekend.
While DX'ing and chatting to locals today I used the QRM
eliminator again as especially 40m was really noisy. It is amazing how well it
works! Look at the IC-7300 screen capture below to see the difference between
the QRM Eliminator being on and off!
QRM eliminator off for the top half of the
waterfall and on for the bottom half, huge difference!
Update 13/9/2013:
I received good news this morning,
we (myself and the supplier) managed to configure a complete QO-100 system
from what was available in stock at the supplier! The only missing items are a
2.4GHz TX antenna that I can build and a power supply that I do not really
need as I have similar supplies.
The equipment was shipped this morning
so I should have it early next week, going to be fun setting up this station,
many new things to learn.
The Icom IC-7300 that I acquired yesterday is
in the shack after I agreed with the seller to meet him half way rather than
ship it. A nice drive and now I do not have to worry about shipping damage!
Icom IC-7300 up and running!
Size
comparison between the IC-7300 and my trusty IC-756Pro2
First impressions are good. The radio is really compact, more so than I
thought and that is great. It will be perfect for the yacht and also as a
field station. The ability to interface with a computer via the USB port is
great, it makes CW keying from contest software like N1MM easy and with the
included Win4IcomSuite software remote operation is also an option.
The
noise blanker and DSP noise reduction seems quite effective, will try the
radio on my afternoon SSB net, should be a good test. At the moment I need to
choose between using an amplifier or the QRM Eliminator till I make up a
second keying cable. Icom have changed the plugs on the accessory ports so my
normal Icom cables won't work. Shame on you Icom!
I only had it running
for a few minutes before I hear some decent CW signals from South America on
10m. Was a real pleasure to work some DX on the new radio! I think I might
just (really) like this compact little radio, we have already started
"bonding"!
Update early evening: I used the IC-7300 on our
late afternoon net and it performed well. Even though I could not use the QRM
Eliminator due to the plug issue it coped well with the noise, careful use of
NR and Notch filers allowed me to hear everyone, quite impressive! I also
received good audio reports, and the group can be brutal if your audio is not
good! The radio ran cold, I am not sure if the fan ever switched on, if it did
it was so quiet I could not hear it.
In other equipment news, it looks like my collection might
grow even more, I found a pristine IC-7600 to add to my collection, it will
complete the whole IC-756/76xx range!
Enough radios for now.... (Hmm,
really?)
Update 12/9/2023:
I had my regular chat on 40m SSB
yesterday afternoon, as usual, due to the noisy band, I was running 400W so
that especially the stations in ZS6 could hear me without issues. A bit later
I also had my now regular CW chat with my friend Andy (ZS6ADY). What was
interesting was that with CW I was running only 5W and got a 5NN report. It
is amazing how much more efficient CW is than SSB.
I have been doing a
lot of reading and watched a few YouTube videos on the QO-100 satellite. I
also spoke to a local supplier to see what is available. Fortunately it looks
like I will be able to get most if not all the components from him.
I
still need to finalize the list with him but I have decided on a full SDR
station. Initially I was against that because none of the SDR solutions really
offer CW as an option. Some research and a few experiments with the SDR
software I plan to use has convinced me that I will be able to get a decent CW
signal from the SDR using software keying, a nice challenge!
Here are
the components I am going to acquire for my station.
Main radio: Pluto
Plus 2 SDR, this a dual RX/TX radio that covers from 70MHz to 6GHz out of the
box. This is a very versatile radio and I can see that I will use it for a few
other things as well!
Antenna will be a 1.2m dish. One of the
components not available is the 2.4GHz feed antenna for the dish but I will
build my own, most likely a 3D printed helical antenna.
The SDR will
output RF into a small pre-amplifier, the output from the pre-amplifier will
then feed a 20W 2.4GHz amplifier, from there the signal goes to a 2.4GHz helix
antenna mounted at the focal point of the dish.
On the RX side the dish will focus the
10GHz signal on a low noise, high stability LNB that will down convert the
signal to around 700MHz. This signal will then be received by the Pluto Plus 2
SDR.
There are also a few small things needed like a "power injector"
to provide power to the LNB via the coax cable, a 5V and a 28V power supplies,
a heat-sink plus fan for the amplifier plus a bunch of coax and connectors.
I am planning on running SDR Console software as main software.
Hopefully everything is in stock so that I can start the project soon.
Late afternoon update: Unfortunately a few needed items are not in stock and
it will take about 3 weeks to get them, so it does not look like I would be
"on the birds" as soon as I hoped. Oh well, such is life!
On a
different note, this morning I was offered a pristine Icom IC-7300 at a great
price. The radio also includes a license for the Icom remote software that is
also compatible with my IC-7610. I have always kind of "ignored" the IC-7300
as a "well priced but average performing radio" and I suppose that is true,
but maybe I was simply comparing it to top end equipment at many times the
price. For normal use, rag-chewing and DX'ing it is actually a very nice radio
and also compact. With the controls and menus very similar to my IC-7610
getting used to it should be quick.
So I decided to take the radio, I
am not sure if it will end up in my shack as an "everyday rag chew" radio, the
competition for that position is stiff, or maybe I will end up using it on my
yacht? Time will tell but for now I hope to have some fun with it!
Band
conditions on 40m was not great this afternoon so I ended up not reporting in
with the usual net. I could hear some stations but not all and it is not fun
if it is a struggle to hear everyone. My later CW session also did not work
out, not sure if it was conditions or if the other stations was simply not
there.
Update 11/9/2023:
I have been looking for a new
challenge in amateur radio for a while, I love DX'ing and chatting to friends
as well as restoring/fixing older equipment and I will continue doing that but
what I need to stay enthusiastic and active is something different.
One
possibility is to get involved with satellite communications again (did play
with satellites many years ago), it is technical and fun plus you are not so
restricted by band conditions. Often I have time during the day or evening but
then the bands are dead so my interest turns to other hobbies. With satellite
communication you do not have that issue, your only limit is that you have to
wait for a satellite to come over the horizon but even that has changed!
The Es`hail 2 (QO-100) is a geo-stationary satellite, that means that it
is visible 24 hours a day plus you do not have to track it as it does not
move relative to your position! It uses a 2.4GHz up link and a 10GHz downlink. Since I am not equipped
for either of those frequencies in the shack I would need additional equipment
for the shack but that is half the fun! There are no "brand name" radios
available that covers those frequencies so the way to go is normally an
up-converter (usually from 432MHz, 144MHz or 28MHz) for transmit and a down converter
or SDR receiver "dongle" that covers 10GHz or the 700MHz that is
output by a LNB. Home-brew or at least matching of
different modules is normally the way to go and I love the challenge!
I
would also most likely need a 2.4GHz RF amplifier (10-30W) and a pre-amplifier
for 10GHz. A dish antenna would be needed as well but that I do have as it is
the same as what I have been using for my long distance FPV video and RC radio
links.
The challenge is to now to source the needed bits and pieces,
hopefully local to reduce waiting time. I am already excited!
I do need
to make a few decisions, how will I drive the up-converter? From a "satellite"
ready radio like my Yaesu FT-847? But a satellite ready radio is not really
needed as you do not have a fast moving satellite so there is no need to
compensate for Doppler effect. Easier might will be to use a radio with a good
spectrum display like the IC-7610 or Flex-5000A so that you can "see" other
stations in the satellite's pass-band. Fun times ahead! I think if I stick to
an up (and maybe down) converter that uses 28MHz I have many different radios
to select from and to play with.
The satellite I am most interested in as it offers
24/7 contacts and a nice technical challenge
QO-100 "Footprint", lots of DX to work!
Other satellites will also be fun and I think I will start with them while I
am waiting for the QO-100 equipment, see you on the "birds"!
I will
report back here as I make decisions and acquire equipment.
Update 10/9/2023:
I have had time to
experiment a bit more with the QRM Eliminator and I am really impressed. It
works well for strong carriers but also for high noise floor levels due to
random noise on the band. I can often hear stations that were below the noise
level after adjustment of the device.
I must say at one point I was
not impressed with this unit, the first one I received failed after a bit of
use, appeared to be an issue with the switching circuit but it was replaced by
the supplier, this second unit worked ok but it had an intermittent relay,
after when going back from TX to RX there would be no signal getting to the
radio. A few TX/RX cycles and the signal would re-appear. I replaced the
offending relay and then all was well. Many of these "Made in China" products
suffer from low quality components and little if any quality control but with
a bit of work they can be made to work well.
I think one of the reasons it
works so well is that it "eliminates" the noise before it enters the radio so
the radio does not have to deal with strong unwanted signals that de-senses the front
end of the radio. It eliminates the noise by moving the phase of the
interference a bit as received from the AUX antenna and then mixing that signal
with the signal received from the main antenna. The two noise signals that are
out of phase then cancel each other leaving just the wanted signal to enter
the receiver.
The only equivalent would be the pre-select filters
available on some Yaesu radios and that does not use the phase shift they
simply use band-pass filters and tuned circuits. I like it so much I have
decided to acquire a second unit to be installed permanently on my yacht where
QRM is a real problem.
QRM Eliminator now working well. The first unit I
had was faulty and this one had a bad relay that I replaced.
I have now been using the little Daiwa manual
tuner to tune mostly my 40m antenna that was cut for the CW portion of the
band to the SSB portion. Normally I would just use the internal tuner on the
radio for that but if you want to run an amplifier that is not feasible. The
unit has been performing well, that is after I sorted out the intermittent
IN/OUT switch on it. It is rated at 2.5KW PEP (It does not have a PEP meter
but will measure average power up to 2KW), I am not so sure about that but it
is quite happy up to our legal limit of 1KW. The build quality is far better
than the MFJ tuner I used in the past!
Daiwa CNW-518 tuner.
The inside
of the tuner, well made but I am not convinced those switch contacts will
handle 2.5KW PEP! Not going to try!
I was keen to try some DX'ing today, even got up early but the bands were real
quiet. Not feeling to great today, not sure what it is so I think I will spend
the day reading, maybe I will have more energy later in the day.
Update 9/9/2023:
I had a look at the QRM Eliminator
(by DK9NL) and the good news is that it does switch the "AUX" antenna to
ground when in the TX mode. So it should be safe to use it with an amplifier
and antennas that are on the same mast.
Will give it a try this
afternoon with the net!
QRM Eliminator circuit, on the right hand side you
can see the relay (K2 contact 2) that switches the AUX antenna to ground when you transmit.
Update on the QRM Eliminator: The good news is that
it worked really well and allowed me to have a decent net session! It does
take careful adjustment and yes, I do need to use a decent "AUX" antenna
(I used a second 40m dipole) but
when setup correctly the carrier as well as general band noise simply
disappears! Great news! With the radio not desensitized by the noise the
actual signals are up 2 to 3 S points, really makes a difference especially on
the lower noisy bands
I did notice strange behavior when I use it in
CW mode, when transmitting the relays in the QRM Eliminator "chatters" at high
speed, I need to investigate if this is due to RFI or more likely a QSK
setting on the radio, hope I can sort it out.
Ok, now later in the day
I can report that it looks like the issue with the QRM Eliminator's relays
going crazy was caused by a very long cable between the radio and the unit to
switch the Eliminator from RX to TX. I used a long cable because when I
connected the unit the first time the cable was on the workbench. I have now
changed it to a shorter cable and no more issues. I can only assume that I got
RF into the system switching the relays randomly. It only seemed to happen at
25W and above.
10m was open early afternoon so I managed to work some
DX, there was a CW contest going so it was fun to work a few EU stations,
signals were S3 to S7 and even with 5W I could work most stations on the first
call, hopefully this is a sign of things to come this summer!
Now I
want to get by 6 element 6m yagi up, with 10m this good chances are we will
get some 6m openings towards the north.
Special Update 8/9/2023:
Just a further, separate note for today!
I have been
asked why I keep a running log/blog of my activities here, well, there are
many reasons. Quite a few people read what I post here, I can see it from the
page hits and also from the number of emails I receive with comments,
questions and notes of thanks.
But there is another reason I post
here, it is for my own benefit to sometimes read what I have been up to years
ago, just like people will do with a personal diary. Often when I go back and
look for information on something I did in the past I am inspired to do new
radio related things, it has been a "kick start" for me more than once after
an extended period of inactivity.
Update 8/9/2023:
The DX bands are still not great. I
do hear some stations on 15m in the evening, mostly SSB, but so far no
interesting stations that I really want to work.
While playing around
yesterday connecting the FL-7000 amplifier with various radios I noticed
something strange. When I connect my IC-756Pro3 to the amplifier and I connect
the ALC line as well the radio behaves strangely when keyed on CW (And FM/AM
as well). When keyed the radio will take up to 1 second before producing
power, this makes this combination absolutely useless for CW! It does not seem
to do it on SSB but I need to investigate to be sure.
If I disconnect
the ALC line it is fine but then you need to run very low drive, and thus get
low output, around 200W max else the amplifier will complain and trip. I think
the problem is most likely a high power spike from the radio when first keyed
causing the amplifier to "throttle" the output back.
I tested 5 other
radios including the IC-756Pro2 and original IC-756 and none had this issue.
More investigation is needed!
The high noise levels of the last 2 days
are persisting, it is spread evenly over the bands so I am convinced it is
man-made. I will connect my "QRM Eliminator" again to see if that helps as it
helped with this in the past. I think I also need to take a walk around
my area with a HF receiver to see if I can find the source of the noise that
suddenly appeared again. The little R928+ would be perfect for that, it has an
internal battery and the spectrum display will show what is happening.
Just look at the noise! Almost S9! Trying to listen
to my local 40m net.
Also on the CW portion of the band. Captured with the "screen shot" feature on
the IC-7610.
Closer
look at the noise "bands", these bands are wide enough to completely block a
weak signal, not
even the great IC-7610 filters can help!
My 40m afternoon net was a bust again yesterday, same S9+15 carrier again
right on the net frequency! I played around a bit with my QRM Eliminator and
it works well, can get rid of the QRM but I have to use a 40m dipole as a
"second" antenna to get the QRM signal strong enough to phase cancel. That in
itself is not a problem, I have a second dipole but it is very close to the
main antenna so my concern is if I run 400-500W as I need to do to make sure
everyone on the net can hear me chances are the signal will be so strong in
the QRM Eliminator that it will blow the unprotected circuit.
I need to
see if I can setup a relay in the QRM Eliminator that will ground the second
antenna when the unit goes into TX mode, next project.....
At least I
had a nice, more than 45 minute, CW QSO with my friend Andy (ZS6ADY) later in
the evening, when conditions are not ideal CW always wins!
Hoping for better conditions, and less noise, tonight so that I can work some
DX!
Update 7/9/2023:
I had no luck with my 40m net late
yesterday afternoon, a S9+15 carrier was right on the net frequency. I tried
to use a notch filter to remove the signal and it worked but the signal was so
wide that nothing was left of the signals that I wanted to hear, oh well,
maybe I will have better luck today.
Later in the evening my CW sked
did not happen either, the band was closed locally, I could hear DX stations
on 40m but they were weak, I did manage to make a few QSO's, there was some CW
contest running.
Icom IC-7610 on a rather noisy band.
Look at
all the carriers on the SSB segment of 40m
I upgraded the
firmware on my IC-7610 to the latest version, an easy process and very quick.
I have not really played with the new features, they seem to be mostly spectrum scope
related, will try them later so I think I will use the IC-7610 for a while. I
have had it for a few years already but I have hardly used it, a bit of a
waste.
Update 6/9/2023:
While working on and testing the
Transworld T-1000 amplifier I was looking through a collection of
inter-connect cables searching for the cable that connects the T-1000 with a
transmitter to allow automatic band changes on the amplifier. I found a cable
marked "FT-1000/990 to FL-7000" reminding me of the FL-7000 amplifier that I
fixed a few years ago after a lightning induced problem. After fixing it and a
few tests I put it in storage. I decided it was time to take the FL-7000 out
and play with it a bit especially as I am playing with the FT-1000D and FT-990
at the moment.
Distracted again! Oh well, I am having fun.....
These two radios have now been use mostly on 40m for my rag-chewing nets and I
thought the FL-7000 would be a nice addition to the set.
After
retrieving the amplifier and giving it a quick clean I connected all the
cables needed and fired it up along with the FT-990. Everything worked
perfectly! It also worked perfectly with the FT-1000D so it was used for my
40m afternoon net. I love this amplifier, quiet and clean power when you need
it. It is "only" 500W but the difference between 500W and 1KW is only half a S
point so no issue. The lower power consumption is also nice as I run
everything from an invertor and batteries, at night if I run something like a
TL-922 the "wasted" energy used by the filaments even when you are not
transmitting adds up.
Yaesu FT-1000D on top of the FL-7000 amplifier, a
classic combination!
I also want to try the
amplifier with my Icom radios, the automatic band changing won't work but
doing it from the front panel of the amplifier is not a problem been doing it
for years on other amplifiers!
The internal tuner o the FL-7000 is also
useful. The first time you tune an antenna on a band it can be quite slow, it
can take between 30 an 60 seconds but next time you change to that band it
will remember the setting and it will only take a second or two. So I no
longer need a manual external tuner when using my "CW tuned" antennas on the
SSB portions of the bands.
Today's "dusty toys", from the top Yaesu FT-1000MP
mkV, FT-990 and FT-2000
Update 5/9/2023:
Conditions were really bad today
with a major magnetic storm on the go, oh well, maybe tomorrow! I did have a
nice chat with my normal net this afternoon, always interesting discussions
going on!
I decided to take my Transworld T1000 amplifier out of
storage today. I have not used it in over 20 years! It was fine when I put it
in storage but when I fired it up today it appears like there are some issues.
The input SWR is around 2:1 but it seems to change with time ,first it is
relatively low then spikes up high and then slowly drifts down again. Because
of the high input SWR the radio reduces power to protect itself but then
slowly increases power again as the SWR improves, this causes the output to
wildly fluctuate.
The amplifier is producing output but the max of 400W
that I saw is far from the rated 1KW with 100% duty cycle. I have a suspicion
there might be a problem with the input power splitter (or even the output
power combiner). I can see some of the resistors on the combiner has been
exposed to a lot of heat. I will investigate further when I have time and the
energy to move the 46kg amplifier around.
Update 4/9/2023:
I did manage to work some DX
stations today, all CW but signals were not that strong with the exception of
some South American stations on 10m. I need to point my antenna in that
direction more often.
I was using the Flex-5000A and it behaved itself
well, most of the time anyway. It did lock up once while I was sending CW. It
just suddenly stopped with no signal going out or anything happening on the
screen. After 2-3 seconds it continued like nothing happened, it had buffered
what I had sent and simply continued where it stopped! Rather confusing for me
and the station on the other side!
This is rather concerning, just as I
started to trust it dropped me again. The CPU utilization when it happened was
not high so I do not think anything else was running but it is still a
possibility. I need to investigate further I suppose.
If it was not for
the wonderful RX and nice user interface this radio would have been gone
already, might still get rid of it if I cannot trust it. It seems fine on SSB
but CW is more my thing so I most likely won't keep a radio that is not good
for CW.
I could look at the newer Flex models but it would be an
(expensive) step backwards in many ways as the Software on the 5000A that has
been developed and enhanced by someone outside of Flex and is far advanced
compared to the software now supplied by Flex. Some of those "extra" features
are exactly what attracts me to the radio. Unfortunately the 5000A software
won't run on the newer models.
Update 3/9/2023:
Early morning I started looking for
local field stations but also for a bit of DX on 40m, hopefully I will have
something to report later!
Update: Turned out I was not on air much
today other than the normal Sunday bulletins and a bit of DX. I ended up
watching the F1 GP at Monza and had some family time after that, maybe
tomorrow will be more productive am the radio side.
Update 2/9/2023:
The SARL Field day contest started
at 10am local time today. I had no plans to enter the contest but decided it
will be fun to setup a portable station and make some contacts. I did consider
setting up a station in the foothills of a local mountain range but the
weather is not great here and it really gets cold at night so I changed to
plans to a "garden station", it is actually a class in the competition!
I decided to use the little R928+ SDR radio as the plan was to enter as a
QRP station. I have just redone all the settings on the radio after some audio
problems, it now seems fine. I also built a "field" dipole quickly just 40m
for now (15m will also work) as I know that 90% of the contest QSO's are on
40m.
I only operated about 1 hour in the contest today but I did manage
to make quite a few contacts. I did find one "interchange" funny. I heard a
club station call CQ so I replied to him with my call. He came back
immediately with "frequency in use" so I though maybe someone else called over
me. I waited a few call cycles, I could hear no other stations before replying
to him again with only my call. He replied AGAIN with "frequency in use" so I
waited again for a while, when it happened the third time I said to him "all I
want to do is give you a point" to which he replied "but the frequency is in
use"! I just kept quiet. He called again and someone else replied but the
"club station" told the guy the frequency was in use. I am not sure if the
operator was drunk, confused or something else but I decide to move on.....
Soon after that I had a quick listen on 15m and ended up working a few
nice CW DX stations, the little field antenna is working well!
R928+ ready for the field station.
I might work a few more DX stations tonight and some field stations tomorrow
morning if conditions are ok, 40m dropped out late afternoon.
Later in
the evening I did make a few DX contacts from the shack with the Flex. I am
now quite happy with the way it runs on both SSB and CW. The RX/waterfall
still locks up every now and then but it rests itself within a second or so, I
think it is caused by a process running on my freshly setup laptop that seems
to be malware even though it comes from the Micro$oft distribution of Windows
10, somehow I am not surprised. The High CPU load leading to the "lock" only
seems to happen if you just leave it running without any interaction for a
while, at least the whole program and the laptop is no longer crashing every
time. The file that runs can be deleted but it keeps replicating in different
folders.
I will investigate this and solve it one way or the other, M$
you still suck!
I really wish the SDR software could be run on a Linux
system, none of this would be happening.....
Update 31/8/2023:
Last night I went briefly into the
shack to just have a quick listen on the bands. Since I last used the
IC-756Pro2 I fired that up and then changed antennas to the hex-beam on the
recently acquired Daiwa tuner, I then took the tuner off-line is it is not
needed on the hex-beam. A quick scan on 20-10 meters showed quiet bands with
almost no signals.
It was so quiet that I though I had the wrong
antenna selected on the tuner or the radio but a quick check confirmed my
selections were correct. I was just about to switch off but decided I will
switch the radio and tuner/antenna back to 40m for my early morning net today.
I started with putting the tuner back on-line, as I touched to online/off-line
button the noise on the radio, still on 20m suddenly jumped for a second
before disappearing again!
A bit of investigation soon showed that the
online/off-line switch seldom if ever makes decent contact in the off-line
position! You have to wiggle it and hold it just right for the connection to
be made decently. I wonder how many times I recently listened across the
higher bands only to switch off disgusted with the lack of signals because the
new (to me) tuner that was bought as "in a great condition" had a basic
problem like this? In the "online" position the switch is fine, that is why I
never noticed it on 40m.
Time to open the tuner and see if it can be
fixed....
Ok, update a few hours later. I have opened up the tuner, I
can see I am not the first person to do so, some of the screws are not even
the original ones and all screws have been taken out many times, and maybe
with the wrong screw drivers so it looks like this is not a new problem.
Unfortunately the switch that switches the tuner in/out of circuit is a sealed
unit and by the looks of it maybe a custom part. So it is not easy to clean
the contacts, actually just about impossible! I did soak the switch with
contact cleaner and operated it many times to try and clean the contacts. Then
I re-assembled the tuner I also did it in such a way that there is a bit more
pressure on the switch in the one position.
Testing it shows that the
switch now works 100% but i have to admit I do not trust it and I think
eventually it will fail again so I will be on the lookout for a replacement,
even if it is a different switch and I have to do some modifications.
Over the last 30 odd years I have made many deals with local guys and I must
say most of the time I have been very happy, but, and this is a sad but, it
seems like times are changing. If I look at the last 4 pieces of equipment I
acquired one was exactly as described by the seller, actually in a better
shape than I expected but the other 3 items all had "undeclared" issues. Some
of them were from the same guy though so I suppose the problem might not be
that general?
I have also had a few other items offered to me recently
that were initially described as "in great condition" or "just about perfect"
but as I asked questions and asked for photos it became apparent they were far
from great. One radio even turned out to be non working!
Such is life,
have to be more careful I suppose.
With some spare time I decide to
tackle the Icom IC-728 again that I have had for years but even after a few
tries I could not get it sorted out. Way back when I got it I was told it had
low output power and potentially other issues so it was just about free as it
came along with a larger deal there was never a real incentive to fix it I
suppose.
I managed to sort out the output power relatively easily but
once I had a running I noticed that the frequency would suddenly jump about
700Hz. I went through the frequency calibration procedure in the service
manual but it did not really help. Eventually the frequency jump became
permanent and it was more than what the adjustments allowed. So the radio went
back into storage for a few years.
Recently I have been chatting to a
fellow ham who was also working on a IC-728 so I decided to try again.
Well, looks like I managed to solve the issue today. It was a bad preset cap
in the reference oscillator, there were also a few suspect solder joints on
the PCB so I "re-flowed" them as well. After sorting that out I could get it
on frequency again and it now seems stable. I will use it for my afternoon net
today, if it behaves during that, with long QSO's and lots of heat generated,
I think it will be fine. I might have to re-align the RX to make sure the
USB/LSB carrier balance is right but for now LSB is fine so I will try it.
Icom IC-728 complete with AT-160 auto tuner on the
workbench, seems to be fine now!
I am not sure what I am going to do with the IC-728
as it does not really fit in with my "Older top end radios" collection and I
really do not need another small/simple radio. Maybe there is someone who can
use it better than I would because once I put it in storage again it will stay
there.
Next I need to tackle the IC-738 but I am not looking forward to
unsoldering all those 100's of pins to replace the LCD backlight.
I am
hoping that with the tuner switch now fixed I will hear a few DX stations
later today on the higher bands, I really hope so!
Update 30/8/2023:
The DX bands are still quiet with
only weak signals to be heard, most of the time it is not even worth trying to
work these weak stations with 5W. Since antennas are seldom pointed towards
"Dark" Africa it is even more difficult.
I did spend some time working
on my old TS-930S today, it seems like the PLL issue (it was unlocking when
hot) is now solved. I still have the problem with the broken mode switch. I am
getting a "spares" TS-940 soon (Thanks William!) so maybe I can use a switch
from that, time will tell.
Had a nice chat on 40m again today with
some friends, I now seldom miss a day, nice to talk to some technical people.
Today I felt like a change, have played around with the Flex-5000A enough for
a while so I fired up my old Icom IC-756Pro2. It is still a nice radio and it
drives my Metron MA1000 amplifier nicely. I think I will use it for a few days
before moving on to the next radio, maybe it is time for the FTdx-5000MP
again? Have not used it for a while, the FT-2000D has also been neglected.
Chatting on a noisy 40m band with the IC-756 Pro 2
(It does need a good clean!).
Tomorrow I really need to build an antenna I can use portable since I am still
considering setting up a field station this weekend, the easiest might well be
just a fan dipole for 80, 40 and 20m. So far the weather has been nice but
there is still a cold front approaching that will be here Friday afternoon.
Hopefully it does not get too cold as spending a night camping in the cold is
not my idea of fun! Will make the final call Friday.
Update 28/8/2023:
Not much DX activity today but that
is usual during the week, some people have to work!
The Flex-5000A is
now behaving itself, I have been playing around a bit with the RX buffers,
latency and process priority as well as the virtual audio cable setting to try
and get the delay that has been bothering me on CW down to a minimum and I
think I might have succeeded. The delay is now a LOT less and might well no
longer be an issue, I will wait for the next pile-up before finally passing
judgment but it looks good.
During our afternoon chat there was some
horrible interference, I was not the only one to hear it so I am not sure it
was local. It did give me the opportunity to play around with the filters and
specifically the "Tracking Notch Filter". What a fantastic feature! It worked
well enough that I could now hear stations that I could not hear at all before
running the filter! I am really happy with the performance of the Flex
receiver and these filters (you can setup as many as you want) really puts it
in a different class.
Here you can see a single Tracking Notch Filter
used to get rid of the strong signal on top of the frequency I am trying to
listen too, it really works well!
Here you can see two
Tracking Notch Filters either side of my pass-band cleaning up the signal I am
trying to listen too. Since these are IF filters they prevent the interference
from "pumping" the AGC de-sensitizing the receiver.
These filters and the normal noise blanker and NR filter really makes
operating on a noisy band for more feasible and less frustrating. You can
adjust how wide every filter is as well as how "deep" each notch is.
Update 27/8/2023:
Contest Sunday, today it is the CW
leg of the SARL HF contest. Unfortunately the same silly rules apply where the
3 bands you can use are run at separate times PLUS there is a 30 minute gap
between bands, found it very frustrating in the SSB portion. It not only
causes confusion but the "gaps" are a waste of time. With so few local
competitors the whole contest should be run for only an hour or two with all
bands at the same time, just like any "real" contest in the world, come on
SARL....
There was some activity on the higher HF bands today, I
managed to make CW contacts on 10 and 15m during a contest (not even sure what
contest it was as there is more than one running at the same time today. The
strongest signals were only around S2-S3 but workable, looks like conditions
are improving. I also saw the E51D (North Cook Isl.) pile-up again but I could
not hear the DX'pedition. they are either running low power and/or pointing
away from me, not even a whisper short or long path. Oh well...
I can see the E51D pile-up but cannot hear E51D, notice the DX
spots at the top of the band display.
Lots of weak DX
stations on 15m but also lots of noise, managed to work a few.
I am enjoying working DX on the Flex but on CW there is still a noticeable
delay on receiving CW making it difficult to get timing right to TX at the
right time in a pile-up. I also think it will be a problem in a contest, I
think the Flex is great for casual DX'ing and rag-chewing but I can't see
myself using it for a contest or chasing rare DX, would also not be great on
the receiving side of a DX pile-up. So it looks like I still need something
like a FTdx-101MP to optimize my station.
Had a few local contacts as
well, as usual on a Sunday do we have lots of nets and bulletins in the
morning, lots of strong signals today but a few were VERY wide! You can hear
that the operators are driving their radios and amplifiers way beyond
linearity, just look at the spectrum display below!
VERY wide signal with lots of splatter!
I want to build a fan dipole for 40m and maybe 20m and 80m as well to use for
portable work. This is in preparation for MAYBE setting up a field station
next weekend. If the weather is nice Saturday morning I want to be able to
grab my equipment and head to the mountains. The will tell if this is going to
happen. If the nights are still very cold I might just do a Saturday stint
(from 10am local time till early evening and not sleep over.
Update 26/8/2023:
Today was the perfect day to play
with radios! Lots of wind and cold outside!
The Flex-5000A behaved
itself perfectly today, no issues. I was pointed to a YouTube video on how to
setup the Flex audio by Matt - ZS1O, really interesting, you need to setup
each stage in the audio chain before you move to the next making sure no stage
has levels above 0 db and that you do not have any ALC clipping, it takes a
while the first time but the results are worth it! I am now getting good audio
reports. Once you have done the setup and you are happy with the results you
can save the profile so you do have to do it again. You can also have as many
profiles as you like with different settings for contesting, DX'ing and
rag-chewing as well as different microphone.
My confidence has been
restored in Flex, hopefully I can work some good DX on it this coming summer!
Lots of weak DX stations on 15m, some contest! Very
few strong enough to work with 5W though...
After some DX I heard a few guys on 40m that I know so had I nice chat on a
rather noisy band, this is where the Flex shines! I again received good audio
reports.
What I do think I need is a nice desk mike.
Hoping for
some more radio activity tomorrow, really looking forward to some CW QRP
DX'ing soon. Next weekend it is the local HF field day, I am considering
putting up a station on the mountain not far from home but the weather
predictions shows that it is going to be rather cold. Will keep an eye on it
and only make a decision later in the week.
Update 25/8/023:
I am happy to report that I have
finally managed to sort out the issues with the Flex-5000A!
I ended up
loading a clean copy of Windows 10 Pro onto a laptop with no other software
than what is needed for the Flex-5000A plus a logbook program. This laptop
does have a Firewire port on the motherboard, according to the Flex
documentation this port with a Ricoh chipset is not supported but I decide to
give it a try and it works, far better than the card supplied with the radio. Not only does it work but no more computer crashes
even when the software crashes.
And yes I can still get the software to
crash if you "apply" changes and click "OK" without waiting for it to finish,
that is simply a bug in the software that I will report to the developer.
The software also stopped working once when I left it alone for a while but it
might have been the screen saver, I clicked stop and then start again and all
was well. While using it, and I used it a LOT today it never crashed so that
is progress.
On CW it is fine, love it! Now I just need to setup the
SSB audio as the default setting produces no output with my microphone and if
I use the DX or Compress setups the audio is horrible. But I am sure it is just
a case of setting the audio mixer and making sure the compression is not too
high and I do not over drive the radio, will sort it out this weekend.
I really hope the bands will be reasonable this weekend and
we will have some activity, I could hear some stations today but most were
very weak. Our weather prediction for the weekend is cold and windy so I think
I will be spending lots of time in my cozy shack!
Update 24/8/20237:
The Flex-5000A is giving me a hard
time, every time I think I have it sorted it crashes again. This morning I
tried it on 40m SSB and it crashed the moment I went into TX, a few test
showed this happened only on 40m and this time the crash also locked out the
radio so that had to be reset as well.
This sounded a lot like RFI
getting into the radio so I added clip-on ferrites on both end of the Firewire
cable, that immediately solved the problem.
So I looked around and
heard some DX on 12m, first QSO was almost perfect but right at the end the
software and computer locked up again. So, what now? I changed the config so
that the software now runs in "Safe 2" mode supposedly the most robust mode
but with more latency. After that I made a few contacts and all was well! I
did try this in the past but it did not help.
I shut down and went to
do a few other things, later I came back, started up everything and clicked
the "Start" button on the software, well it ran for about 4 seconds and
crashed again! So next I loaded the "legacy" Firewire drivers and tried again.
All went well for more than a hour till I shut down and later restarted again,
CRASH!! I played around a bit and it does help if I wait about 30 seconds
after starting the software before clicking start.
This seems to work
most of the time and once it runs for about a minute it seems stable, manage
to make quite a few contacts but I do not trust it.
I think next I will
try and find a different brand FireWire card for the laptop, the one I have,
"VIA", is "not recommended" by the guy who has been improving the software,
now I just need to find a card that uses the TI chipset, according to him that
is best.
If that does not work? Well I think that will be the end of my
"relationship" with Flex, maybe I should try an Anan? Or just wait till one of
the big 3 produces a radio like this....
Working some DX after many reboots....
Update 23/8/2023:
The Flex software crashed again a
few times today, crashing the laptop as well. It always happens a few seconds
after you open the software and click "start", it will run and then suddenly
lock up the computer after 5-10 seconds. I did notice that if you start the
software and leave it for a while, maybe 30 seconds to a minute before you
click "start" it seems to behave but I still need to confirm that.
Sloppy programming indeed, I think I must look for some of the original
PowerSDR software by Flex, not the third party modified software that is now
available. This instability is really killing what is a really nice radio.
I pulled out my old homebrew amplifier from storage today and cleaned it.
I checked everything I could and the fired it up. Seems to be working well
other than the fact that it was never designed with a tuned input stage, back
when it was designed radios with valve finals that used pi-matching networks
were what was used to the radio could be matched to the amplifier.
I
can use the internal tuner in a modern radio but it is not ideal, maybe I must
get my old Yaesu FT-901DM running again, it should match nicely to the
amplifier. The only problem might be that the 6146B valves in the final of the
FT-901DM are quite old and did not produce much power the last time I
checked and I do not think I have spares. Will try it tomorrow, maybe it
produces enough power to drive the amplifier to a decent output level.
The amplifier uses a single 4-250A or 4-400A valve. The power supply is based
on a transformer from an old microwave oven, the combination of the valve and
the power supply is good for 400-500W output. Would be perfect and fun to use
on the local nets.
A bit dusty but still working!
If I do decide to use the amplifier I think I need to add a small fan below
the tube, it does have a fan blowing across the tube as recommended by Eimac,
it is supposed to be cooled from the bottom as well, the socket makes
provision for that. Other than that I think the casing (made from sheet metal)
also deserves new paint as the old paint is really ugly and faded.
I
could hear a few DX stations today but signals were weak, on 12m I worked 4K4K
but strangely he kept sending my call as ZS2MMO even after I repeated my call
many times during our extended QSO, not sure I will get a confirmation of this
one! Might be a new one on 12m if he did correct my call after I sent my call
5 times slowly as we finished the QSO.
Update 22/8/2023:
I tried for a hour to work E51D,
North Cook Isl. on 20m this afternoon with no luck, his signal was extremely
weak and the pile-up huge, eventually he faded into the noise, oh well, maybe
tonight or tomorrow? DX'ing with QRP is not easy, but that makes it so much
fun!
I used the Flex-5000A and I have to admit some of the features
makes DX'ing and working a pile-up easy! Being able to see the pile-up and
then move you TX frequency, visible on screen, makes life easy. I also tried
the integrated spotting option, you get a list of calls in a window, if you
click on anyone the radio will QSY there and put you into the correct mode.
I also tried running CW Skimmer along with the PowerSDR software, on CW
Simmer you can then see the calling station with his call sign but more
importantly you can see stations in the pile-up with their calls, makes it
easy to see where the DX station is listening. If you click on a call on CW
Skimmer PowerSDR will also QSY to that frequency making use of the CAT
connection.
E51D pile-up. Grey band on top is where I listen
and yellow line to the right is where I will TX.
Here you can see the spotted call sign at the top
of the screen (YD2UWF)
I had another nice session on 40m chatting with a
bunch of regulars this afternoon, most fascinating subjects with lots of
technical talk, thanks guys! Today I was running the FT-1000D with the Kenwood
FL-922 amplifier as I wanted to run higher power than usual to make sure a few
of the ZS5 stations with weak signals could hear me, the extra power (was
outputting about 40W from the radio resulting in around 650-700W from the
amplifier, just loafing along) made a huge difference. It was great to use the
amplifier again after years of just sitting there. Think I will use it for a
few days while I clean the other TL-922 and then swap them around.
Later in the evening I was browsing around the bands and came across a booming
signal on 20m, turned out it was a A25 (Botswana) station. He was working by
numbers and 5 up. Unfortunately he is not a very good operator (putting it
mildly), long periods of silence, then he calls for everyone to stay quiet
(without saying who he wants to talk to!!) and eventually he works one station
and then the cycle starts again, he works 2 or 3 per number (sometimes just 1)
and then moves on, extremely inefficient........
Update 21/8/2023:
I setup a different computer for
the Flex-5000A today going from a 4 core Intel i3 to a 4 core Intel i7. It did
improve things with lower CPU usage, now I can run other programs at the same
time without fearing a crash. I still had a few issues, after an upgrade to
the latest version of the software the software could suddenly not see the
radio. So I uninstalled all the software and reinstalled, then it was working
and I had no further issues while working a stations on 10 and 12m.
I
think it is a stunning radio and the software has great features and is easy
to use but the whole system is let down a bit by the instability of the
software, not sure I will trust it in a contest or to work that rare DX
station, maybe I will feel different if I use it for a while and it behaves.
Anyway, after messing around with the Flex I spent some time re-arranging
my shack, cleaning up the cable mess and setting up the new operating
positions. I only had time to do part of it but the rag-chew side is done for
now anyway.
Rag-chew setup, Yaesu FT-1000D with Yaesu FL-7000
amplifier
Late afternoon I reported in at my normal afternoon
40m net, had a nice discussion with the guys and the radio setup got good
reports and was a joy to use, the FT-1000D has great sound and even running
200W for long overs never caused it to heat up the fan never even turned on,
no need for the amplifier when the conditions are reasonable.
Update 20/8/2023:
The light house weekend was fun,
managed to work quite a few of them but the bands were far better on Saturday
than on Sunday. A few of the guys were activating the same light house under
different personal calls, a bit confusing but it did make for more contacts.
I worked some DX this morning with the Flex-5000A on CW but I was not
happy, at higher speeds, from around 25wpm and up when you transmit the radio
would often miss the first dot/dash or truncate it. Playing around with the
buffers again caused a crash. I now know that when you make a setup change and
click "apply" you have to wait for it to say "saving complete" before you
click OK or anything else, if you do not wait the program will crash every
time!
Eventually I made the DSP RX buffers smaller, this, along with
setting the SDR software process priority higher seem to cure the CW issue, I
worked quite a few stations on 10m and 12m after that with no further issues,
or crashes, there is hope!
While listening around the bands I picked up
a very faint signal on 6m inside the beacon band. The spectrum scope is
actually amazing on this radio, you can actually see a signal before you can
hear it unlike the spectrum scopes on some of the other brands where I can
hear and work stations I cannot see on the scope. As the signal slowly waxed
and waned I could almost make out the call, but not quite. I had a look in the
beacon list it could be either OX3VHF or YU1AVQ but I think I heard a V in the
call more than once so my money is on OX3VHF, the direction of the strongest
signal confirms that. The signal soon disappeared but I did take a screenshot
of it, see below.
The only thing that makes me not feel 100% confident
is that the official beacon frequency is slightly above where I heard it but
it was close. It was definitely a beacon.
Maybe OX3VHF? Not sure.
As our summer gets closer and the TEP season starts I will make a point of
monitoring 6m more often.
I have now setup my dedicated "rag-chew"
station, for now it is a Yaesu FT-1000D (Love the radio!) paired with a Yaesu
FL-7000 amplifier. Will use it like this for a while but then maybe rotate
other radios and amplifiers into the position. Tomorrow I want to re-setup my
DX/Contest station, still not sure what radios will feature.
Update 19/8/2023:
As much as I am enjoying the
Flex-5000A it is also very frustrating. I switched it on today to work a few
light houses. Everything seemed fine till I tried to change frequency and the
software crashed. Rebooted the laptop and tried again same result. Tried a few
options but same result, I was NOT impressed.
I do know that crashes like that is normally
caused by an interrupt clash on the Firewire card. When I initially installed
it I checked and it was the only device on IRQ 20. I decided to check again
and now suddenly it is on IRQ 17, same as the network card and the internal
sound card! Since you cannot move the IRQ of the Firewire card I disabled the
network card, anyway not using it as I run a wireless network. The sound card was not
that easy as I need it to route the sound from the radio, I ended up moving it
to a "soft" interrupt so now the Firewire card is the only device on IRQ 17.
All was well or so I thought. Then I noticed the radio outputs power when
in tune mode or CW mode but not in SSB. I am running the microphone connected
directly to the radio so it does not use any sound device on the laptop. PTT
still worked but no audio, when I switched on "monitor" I could hear the
sound so the microphone was active but no RF going out, very strange....
After a LOT of messing around I got fed-up and reset all
the settings on the Flex software to defaults. After a reboot the microphone
worked again! Ok, I had to reconfigure all the ports, the virtual cables,
virtual CAT control and sound output again. Grrrrrr!! But all was not well
yet, now suddenly I could not change the volume using the slider on the
screen! More messing around till I finally solved that.
I think the
problem started with Microsoft (I HATE MICROSOFT!) deciding for some obscure
reason to re-assign the interrupts (With PCI on a PC this happens when you
move a card from one slot to another but there is only one slot on a laptop). At least the software now seems more
stable (it still crashed later with a programming error, no error trapping?
Sloppy programming...).
I can only assume that the IRQ change happened a while ago as I did
not have issues for a while after the install but then it started sometime
yesterday. I will now keep an eye on the IRQ used by the Firewire Express
card.
I have to admit that while all this was going on I looked
longingly at my "normal" radios, just plug in the antenna and switch on and it
will work! But I am not one to give up, will try my best to get this Flex to
be as reliable as my other radios, I would miss the RX if I decided to "dump"
it.
After all that I did manage to make a few contacts, hopefully I can
make a few more later today when I have time.
Update, managed to work
quite a few more lighthouse stations on 40m as well as a few CW stations on 15
and 20m, the Flex behaved itself and the great RX allowed me to work a few
very weak CW stations, so far so good.
Lots of activity on 40m SSB during the Light house
weekend.
2 Receiver "slices" running at same time.
Update 18/8/2023:
Just a quick update on the
Flex-5000A. I have now used it for quite a few QSO's and the feedback problem
via the audio system is solved. I think the issue I had with the PC speakers
had nothing to do with the Flex, it was the "Made in China" speakers. I now
route the audio via the laptop speakers via a virtual audio cable and it works
perfectly.
The software also seems to be more stable after I played a
bit with the buffers and process priority. I have only had one more crash and
that was while I messed around in the menus quite a bit. A long, more than 80
minute long QSO was fine even though I played around with the filters,
bandwidth and other features while in the QSO. Audio reports were again great
even with the speech processor on.
The laptop I am using has a LOT of
software on it, not ideal as it could cause timing issues, I have a spare
laptop that I want to do a clean windows install on and then install just the
Flex software.
Interestingly the TX seems nice and clean with no spikes
on keying, unlike some of my other (Icom) radios, this allows me to drive
solid state amplifiers like the Metron 1000, FL-7000 or Transworld T-1000 to a
higher level without the amplifier's protection circuits tripping the circuit
breaker when you key the mike.
Not much DX today but I did hear reports
of long path openings towards the east early afternoon when I was not in the
shack.
I did manage to work RI0FS (SHIKOTAN Is.) last night on 20 CW
QRP with the Flex. He was right in the noise but the RX on the Flex is
amazing! I am getting to love the point click and QSY operation of the Flex,
split operation with a pile-up is also easy. The Zero Beat function also works
really well, I love it!
Talking about the RX in the Flex, I have been
having problems with huge 50Hz QRM on mostly 40 and 80 but also on the higher
bands some days. sometimes it is so bad that all I can do is switch off and go
do something else. I have tried a "QRM Eliminator" and it works to some degree
but after the second one died I gave up. Anyway, the Flex solves the problem
COPLETELY! With S9 noise you click the NB or NB2 button and the noise
disappears completely! Suddenly the spectrum is clean and you can actually
hear (and see) weak stations again! For this one feature I will keep the Flex
and it will become my main radio. None of my other radios, even the ones with
the most modern DSP can do this so efficiently. Well done Flex!
I am
using a software keyer at the moment that is connected to the radio via a
virtual com cable, it work well but there is a slight delay from when you
start keying till when it actually starts keying, nothing major BUT it messes
up your timing a bit if you want to send your call at exactly the right moment
in a pile-up. I think I could get used to it but it might well be easier to
just use my normal keyer and connect it directly to the radio, will try it
tomorrow.
Update late afternoon: I have now connected my normal keyer
directly to the radio and the delay is gone, feels a lot smoother, so I just
need a few stations I can work.
I have also removed my old FC-901 tuner
(good for up to 500W) and replaced it with the Diawa tuner that can handle up
to 2.5KW PEP, no more fears of over stressing the tuner when I play with
amplifiers. I mostly use the tuner to tune my antennas that are optimized for
the CW portions of the bands in the SSB portions. The tuner works really well
with smooth tuning capacitors and quality switches.
This weekend it is
the "Light houses on the air" event, I have a few friends who are going to
activate light houses so I am hoping to work quite a few stations!
Update 17/8/2023:
After a detour or two the Flex-5000A is finally here! It arrived in a good
condition with no transport damage. I had it connected and running in no time
at all. The software installation was easy, no issues. I managed to get CW
running and had a nice contact with Paul ZS1NN. The only problem I had during
the contact was that while I was sending I noticed that the TX stopped
transmitting at some point and a "Timeout" message appeared on the screen. I
managed to get it going again but after the QSO I had a look in the manual but
a search for "timeout" produced nothing.
I ended up going through the
menus and found a "TX timeout" that was set to 150 seconds! Really? Fine for
DX'ing or contesting on CW I suppose but useless for rag chewing! Well, it is
now disabled!
At some point I also noticed an echo on the received
signal, need to try and find out what is causing it!
On SSB I had an
immediate problem with feedback through the external speakers, the Flex-5000A
does not have an internal speaker and Flex recommends you connect "amplified
PC speakers" to the radio, just what I did but the speakers were picking up a
lot of RF. I tried to install Ferrite chokes on the power and audio leads but
it made no difference.
I ended up disconnecting the speakers and
routing the audio, via a virtual cable, to the sound card and speakers on the
laptop, that seemed to cure the issue but I still need to make a longer SSB
QSO at high power to be sure.
The spectrum display is fantastic, better
than any of my other radios and the same can be said for the DSP filters and
noise reduction.
The bands are in a terrible shape today but I am
hoping it will get better soon, would love to make a few good contacts with
this radio.
There she is, does not get much simpler (uglier?) than this!
Great user
interface! Look at all the noise on 40m!
A few strong SSB
signals on 40m
I still have lots to experiment with on this radio
ad lots to learn! First I need to try and optimize the buffers to see if I can
get rid of the annoying echo I got briefly on CW.
Update: I have not
encountered the echo again, maybe I have solved the problem, time will tell. I
did make a few long SSB contacts and everyone gave me good signal and audio
reports. At the moment I am just using the first hand mike I could find, an
old Yaesu unit but it seems to work well. I am also using a headset at the
moment and I must admit I am enjoying it, the headset is really comfortable,
should be as I have worn it for thousands of hours while flying. Maybe I can
get the microphone to work as well, would be great for SSB contesting.
I am still not happy with the stability of the software as I have had a few
crashes mostly when scrolling across the band really fast and twice when
change mode from FM to SSB. It has been totally stable while in QSO so that
helps.
I have noticed that the radio is quite happy to output around
140W and even at that power level it runs cool though I would normally never
run it that high. My few long SSB QSO's were done running about 14W into my
Metron T1000 amplifier gives me 400-450W perfect for a very noisy 40m so that
the other stations do not have to struggle to hear me.
You can see a
few more photos of the inside of the radio in the equipment section (Station
information), click HERE.
Since today also
happens to be my birthday I suppose it is only fair that I have a new toy to
play with!
Update 16/8/2023:
I normally log onto LoTW in the
morning while having my first cup of coffee, it is nice to start the day with
new QSL's! Well, this morning did not disappoint, 3 new QSL's for Ethiopia,
(ET3AA) one of them, 17m, is a new band-slot! Slowly the QRP totals are
growing.
There are still lots of contacts for unconfirmed
entities that I have uploaded to LoTW so there is always the hope of something
new even if I have not worked something new recently.
With the bands
particularly bad today I decided to tackle an irritating problem I have had
with my FT-1000MP mkV for a while. Every now and then the (bar graph) S meter
would just go all the way to the right and stay there regardless of signal
strength, after a while it would suddenly be normal again. Everything else was
working fine so this did not effect how the radio worked, it was only a
problem if you wanted to give a signal report!
I had a good look at the
service manual and found two potentiometers that had an effect on the S meter.
I opened the radio and found them on the relevant PCB. As soon as I touched
the "max S meter defection" one the problem went away so I cleaned both with
switch cleaner and moved them around a bit. They now seem stable to I
re-calibrated the S meter according to the procedure in the service manual.
Now the FT-1000MP mkV was perfect again!
With even more time on my
hands (it was a less than pleasant day outside) I made up a cable to connect
the IF-out of the FT-1000D to a little RTL SRD dongle. Running HDSDR (also
tried SDR#) on the PC
and setting the frequency to the IF frequency of the radio (73.620MHz) I soon
had a nice pan adaptor running! Now I can see signals, and go to them with a
mouse-click on the old FT-1000D just like I can on my more modern radios!
HDSDR display of the IF signal from the FT-1000D,
not much happening on the band!
IF display with
SDR#, only a few FT8 signals on 15m
On a different note. I have 4 laptop computers that
I use in my "hobby room", this includes the one I use at my radio station, the
others are used for microscopy, astro photography and 3D printing. They are
now all getting a bit old but their configurations (all 4 core i3/i7 CPUs with
8GB RAM) are still good enough for what I use them for as they never run out
of CPU power or memory. Even their disks (320GB) are not full as they are not
really used to store data, that is all done on external drives. What has been
a source of frustration is how slow they boot and how long some programs take
to open.
A local online dealer had a special on SSD drives last week so
I ordered a few. I have now cloned all the original drives and transferred the
images to the new SSD drives so I do not have to reload or re-configure any of
the stacks of programs I have on them. The result is amazing! They all feel
like brand new computers, I am sure they will be fine for many years of duty
in the hobby room again, best thing I have done in a long time!
My
Flex-5000A is still traveling around the country after some confusion at the
courier company, at least it is heading back in my direction again, should
have it in a day or two, at least the computer I want to use with it is now a
LOT faster!
Update 15/8/2023:
The Yaesu FT-1000D arrived safely
yesterday. It is in great condition with no shipping damage, always a concern
especially with a 21kg radio! A few quick tests show that everything seems to
work I have not had a chance to test it on CW but the filters sound great.
Yaesu FT-1000D joining the museum collection, isn't
she pretty!
I love the way her RX sounds, even bad QRM sounds better on her. I have
received great SSB audio reports on her so now to test her on CW, the bands
seem a lot better than on the weekend so hopefully it will remain like that
for a few days so that I can make a few contacts.
The radio has a very
convenient "IF Out" plug on the back so I am keen to connect a SDR dongle to
it to ass a spectrum display, just need to make up a cable.
Tomorrow I
hope to get some time to re-arrange my shack to make a bit to make more space
at the operating position. Hopefully the Flex-5000A will also arrive soon but
looking at the tracking it seems like the courier company does not have a map
as they have now sent it to completely the wrong town, idiots, third time they
have made this mistake.
Update 14/8/2023:
Well the weekend is history and the
WAEU contest was a "bust" as they say. Less than perfect conditions, terrible
QRM and restrictive rules messed it up for me. Interestingly late Sunday
afternoon I switched on the radio to see if the interference was still there
and yes it was, but while I was jumping between bands it suddenly dropped
away, came back a few times and then got weak and was gone, really strange!
I made use of the now VERY quiet bands and worked a few stations, not
going to send in my log but it was fun. Unfortunately a few hours later the
QRM was back it can only be something that switches on and off most likely at
my neighbor as he had lots of electrical and electronic tools, need to go and
have a chat with him....
We had a local digital contest Sunday
afternoon, it also included 6m so a few of us decided to give 6m a go and
maybe make a contact or 2. Unfortunately after 3 hours of staring at a FT8
screen all I ever saw were a few bursts none of them long enough to decode so
I suppose it was most likely meteor scatter?
Trying to make some FT8 contacts on 6m.
On a different subject, got a message last night from the local courier
agent, they
receive a "heavy" package for me, as far as I can see
looking at tracking it must be my FT-1000D. Happy times! Will go and pick it
up later this morning. The Flex-5000A (and Daiwa tuner) should be here
tomorrow or the day after. I will post photos as the equipment arrives.
Update 12/8/2023:
Contest weekend! Well, not so
much... I was up early this morning to work some stations on 80m and 40m.
Unfortunately after 4 hours of "operations" I have exactly zero, yes ZERO
contacts! Why? Well, conditions were not too bad, I could hear plenty stations
on 40m, unfortunately all the stations I could hear were outside Europe so I
could not work them. VERY FRUSTRATING!
I have not made a final call on
this contest, maybe I will try to work some EU stations later when I can hear
them but I have decided not to send in my log as a silent protest to the
rules. I think it would be far better for contests like these to allow
everyone to work everyone. To still make it an EU focused contest you simply make
the EU-Outside EU contacts count more than the other contacts.
There
is nothing worse than hearing a station you really want to work and you cannot
work him because of some rule. Think I will stick to the CQ WW contests, I can
now remember why I have never competed in this Worked all Europe contest.
On a different note, I have received "bad" audio reports a few times
recently on my FT-1000P mkV, people saying my voice sounds very high pitched,
so I decided to have a look, turned out it was a menu setting shifting the
carrier on SSB, not sure why or when I set that! Seems like the audio is now
fine. The FT-1000MP mkV menu system can be quite cryptic, I actually had to
read the manual to figure out what to change. Interestingly the model that
replaced it, the FT-2000's menu system is far easier to use, it even has a
"menu" button to access it, on the mkV you need to press "Fast and ENT" to get
into the menu!
Update late afternoon: Now I cannot hear any stations,
noise on all bands is now around S9, either I have a new source of local QRM
or more likely there has been another solar flare like earlier in the week.
Ok, so not much HF today, maybe some hope after sunset. I did put up a 2m/70cm
yagi to see if there is any semi local activity or even repeaters to get into
but I have not really tried it yet. I actually want to try some satellite
operation again as well. The plan is to setup a small VHF/UHF operating
position in my "hobby room" close to the main operating position, think I will
get stuck into that today.
Ok, final update, it is now evening. I did
manage to work a few stations earlier but with S9 noise on all bands it was
not fun. It is now long after sunset but the noise is still there. Well, I can
just hope that this noise will disappear sometime as it will kill HF for me
completely. I need to try and find out if it is local but it seems like it as
no one else is complaining. When we moved into this QTH 3 1/2 years ago it was
dead quiet, something has drastically changed.....
Update 11/8/2023:
I was hoping that the Flex-5000A
would be here already, unfortunately it was only shipped yesterday due to
strikes and disruptions by the taxi industry in Cape Town.
The Flex
comes with a Firewire card that plugs into a laptop and from what I understand
it is a 6 pin to 6 pin cable. The laptop I intend to use to run the Flex-5000A
does have a slot that should accommodate this card (no details on if it is a
PC-II or Express card) but the laptop also has an internal Firewire controller
with a 4 pin port. Fortunately I found a 4 pin to 6 pin Firewire cable in my
collection,
actually a few of them! They came with my Canon EOS
1 series cameras and were intended for tethered shooting. Never used them but
now I am glad I have them!
On the subject of new equipment, I received
confirmation that the Yaesu FT-1000D I have acquired was shipped yesterday
afternoon as well so I should have it sometime next week, at least I can track
it, looks like both the new "toys" might get here at the same time. I have
always wanted a FT-1000D, it will get a special spot in my collection! The
FT-1000D, FT-1000MP mkV and the FT-990 makes a nice set! I also
have a lead on a FT-920 but negotiations are at an early stage so it is too
early to get excited, negotiations are progressing a bit slow.
With all the additions to the Yaesu collection I
a hoping to find a few other radios as well, I had a "confirmed" deal on a
nice Kenwood TS-950SDX but the seller changed his mind at the last moment. I
know where to find another sample but it is cosmetically not great, has a huge
external 220V to 120V transformer and it is a bit expensive for it's
condition. I am also still looking for an Icom IC-775DSP and IC-781 but both
seem to be scarce.
Still not 100% sure about the "Worked all Europe"
contest this weekend, it sounds like it could be fun but I have not competed
for a very long time in a long duration contest like this so I am not sure if
I have the energy or stamina to do this. Combine that with the "no QRP class"
and complicated exchange rules I am a bit reluctant, will most likely only
make the final decision early Saturday morning depending on what the bands and
levels of activity sound like.
On the local front I can report that I have been calling into a local net on
40m just about every afternoon recently. The number of people on the net
varies but it is normally around 5 to 10 with some interesting technical and
other discussions between the guys, nice to hear what others are up to, it is
really nice to have some contact with other hams, something I have missed
after leaving the big city and the local radio clubs in the city.
Update 10/8/2023:
Yesterday while re-arranging radios
in the shack and comparing receivers I heard a 3C3 station calling on 15m, I
worked him and forgot about the contact. Before shutting down for the evening
I uploaded my log to LoTW as I do every day that I make contacts.
A bit
later I logged on at LoTW and to my great surprise the QSL was already there,
but even better was the fact that it was an all time new one on QRP, I cannot
believe I have either never worked Equatorial Guinea before or I have never
received a QSL card before! I need to go check my full log but it was a rather
pleasant surprise.
Update 9/8/2023:
I managed to work a few SOTA peaks
this morning on 40m and 20m, unfortunately DX conditions are not great, maybe
it will improve later today, it is a cloudy, wet and cold day here so perfect
to spend on the air!
I am still using the FT-990, mostly for SSB
contacts, it is now working well, I have forgotten what a nice and solid radio
it is with a quiet receiver, I now need to either find a permanent place for
it in the shack, tempting, or move it back into storage. My main problem is
space at the primary operating position, very little space!
Another
complication that will most likely force the FT-990 back into storage is the
fact that I have at least 2, maybe even 3 "new" radios that will join the
collection in the next few days. Till then I will have a bit of fun with the
FT-990.
FT-990 in the Classic Yaesu stack, FT-2000 below
and FT-1000MP mkV above it.
I worked a few contacts last weekend during the
local SARL SSB contest, it ended up only being a few contacts because of the
strange rules. You start the contest on 20m at 14:00 till 14:30. From 14:30
till 15:00 there is a 30 minute break before you can move to 40m from 15:00
till 1600, then another gap and then 80m for 30 minutes. Well, during the
first gap I got bored and worked a few DX stations, never went back to the
"contest".
When I asked why the strange rules (others asked as well) I
was told it was suggested by a "well know contester", I know who it is but I
have not heard him in a contest for years, especially a local contest. First
time I have seen rules like this! Anyway, "whatever" as they say, will stick
to DX contests.
Talking about contests, this coming weekend it is the
Europe DX CW contest, sounds like fun so I am planning to compete. How serious
I am not sure yet, would depend on conditions but I would love to make it a
semi-serious effort, have not done that for years! I have not decided on
equipment to use, unfortunately there is no QRP class, only low power (100W)
and high power. I might well run 5W and enter the low power section, at least
if I work something new I can log it as a QRP contact for my QRP CW DXCC
totals.
Update 8/8/2023:
I have been slowly going through my
radios in "hospital", all the radios with issues that prevent me from using
them. Yesterday I took the Yaesu FT-990 from the store room and took it to the
shack. I have to admit I was a bit reluctant to start on it as I have spent
quite a few hours of it in the past only to end up right where I started.
The problem with the radio started a few years ago (about 5?) when I was
listening to a CW station, I decided to reply only to find out that I had no
CW key connected, no problem, unplugged a key from another radio and plugged
it into the FT-990 (jack at the back, not front panel). As I plugged it in,
the radio was on, the radio died immediately. I unplugged the key, switched
the radio off and on again but it was dead, only the light in the S meter came
on.
To make a long story short, firstly I did not managed to work the
station I heard but far more serious was the dead radio, even though the
FT-990 was in my museum collection I still really enjoyed using it. I opened
up the radio and managed to narrow the problem down to no 5V on the 5V rail. I
found the workshop manual and ordered replacement parts for the 5V regulator.
A week or 2 later I installed the parts and switched on the radio full of
confidence, well it did switch on, the display came on, then dimmed and
disappeared again. 5V regulator blown again! I looked for a short but could
not find anything so the radio went into long term storage to be fixed
sometime in the future.
Roll forward to today, I did have one more
regulator in my stock but I was not going to blow it again. After a lot of
searching around I found the culprit, the CW key jack had a short shorting the
5V rail to ground. I fixed it and replaced the regulator again. This time it
switched on and stayed on but the digital readout was running and none of the
controls worked.
I have to admit at this point the radio very nearly
went back into storage but I remembered reading somewhere that if the radio
does not start correctly you need to do a "hard reset". I did that and
suddenly the radio was back to normal! I made a few QSO's and even a long
rag-chew session, all seems well! Really happy I managed to get the old lady
going again!
Yaesu FT-990, fixed after 5 years!
In other, none related news it seems like I have
made a deal on a nice Yaesu FT-1000D for my collection! With a bit of luck it
will be shipped later this week! Now for the other "deal" being negotiated,
hope I can share some more good news soon!
Looks like I need to make
space in the shack for a few new toys....
Update 6/8/2023:
I added a "new" rig to my
collection today, something a bit different! I have acquired a Flex-5000A SDR
radio, should be here by the end of the week. Hope I can get it working with
the Fire wire port on my Shack laptop else with the provided PCIExpress card
that will fit into the laptop.
I have started reading the manual (yes,
rather unusual for me!) as well as downloading software. It looks like it will
be something that will keep me busy for a while, lots of options and software
to play with. If I like it I might well be looking for something like a
Flex-6700 soon, time will tell.
I will post some photos of the
Flex-5000A and report on my results with it as soon as it is here and I have
played with it a bit.
Really enjoying a bit of "rag chewing" lately, I
was "QRP CW only" for so long I have forgotten how much fun it can be to just
chat to fellow hams. I have already had some nice technical discussions and I
am sure more will follow. Since I am now sometimes running higher power into
less than ideal antennas (and on the SSB portions of the bands, my antennas
are all tuned for best results on the CW segments) I have also acquired
a Diawa 1KW tuner, always wanted one since it is such a nicely made piece of
equipment but I never had use for it.
I also have 2 other more
conventional "classic" radios lined up for my collection but the deals have
not been concluded yet, will report when they are "done deals"! The one I have
been looking for . a long time, had one way back but sold it and always
regretted it. Exciting times!
Update 5/8/2023:
I have recently started making a
few SSB contacts, mostly local, fun to talk to like minded people again! Being
out of the city and no longer ember of a club (nothing locally) I miss
technical discussions, well even more fun to have them on the air! Since
conditions are not always perfect I have even dusted off an amplifier or two,
good excuse to play with amplifiers again!
I am slowly working through
my amplifier collection, so far I have just used the Metron 1000, the Yaesu
FL-2100Z and the Collins 30L1, more will follow soon.
Update 4/8/2023:
I had a pleasant surprise when I
logged into LoTW and saw that I have finally received the QSL's for by Bouvet
(3Y0J) , contacts! Always nice to add a new confirmed DXCC entity to my QRP
tally!
Conditions have been reasonable and getting better lately, I am sure we are
going to have fun this summer!
Update 1/8/2023:
I have been quite active recently,
both on the air and playing with equipment. I recently acquired a small
amplifier to use with my field/SOTA/POTA station. I normally run the QRP R928+
or my old FT-817 in the field and the 5W work well on CW but sometimes it is
just not enough for SSB and for SOTA/POTA SSB is important here in South
Africa.
The amplifier is a small unit from China, reasonably well made
and at least it has band pass filters. With 5W in it produces an easy 75-85W
depending on band, as it is rated for up to 120W it runs nice and cool at
those power levels. It is about the same size at the FT-817 and quite light, a
nice addition to the ham backpack!
Update 30/7/2023:
I just returned from 8 days on the
yacht getting a few things done to prepare it for the next trip. I took a
FT-890 and a G5RV antenna along this time. With the center of the antenna bout
20m above the deck and the legs tied to the bow and stern in an inverted V
configuration the tuner on the FT-890 could tune it to all bands from 80-10m.
In my limited "free" time I made quite a few local and even DX QSOs,
the antenna works surprisingly well! The only negative was the extreme amount
of QRM in the Durban harbor, at least that will improve once I lease that
dirty place....
Update 6/7/2023:
The bands have been really bad the
last few days, I can hear almost no DX, just a very weak station every now and
then, very frustrating when you have the time and motivation to spend some
time on the air! The best I have managed have been a few local chats on 40m,
also fun I suppose! I have also managed to work a few SOTA peaks, think I will
try harder to work them in the future. There is another activation tomorrow so
hoping conditions are not too bad.
If the weather predictions are right
we are heading towards a very cold weekend so I will most likely spend most of
it in the shack, I am just hoping there will be a few stations to contact!
Might also be a good idea to fire up a few of my amplifiers to heat up the
shack a bit.
Local CW activity has also dropped, sad but I suppose when
there are so few people active it happens because people do not want to
contact the same handful of stations every day.
Hoping that as we move
towards summer things will improve, time will tell.
Update 3/7/2023:
The IC-756 Pro 3 arrived today, a
bit quicker than what I expected but I am not complaining.
It was well
packed, in it's original box plus another box so there was no damage. I had it
connected and running in no time at all. Everything seems to be fine so I made
a few direct comparisons between the Pro 2 and the Pro 3. The Pro 3 does seem
to have a quieter receiver and better filters but the band conditions were
really bad so I did not have the opportunity to test them under crowded
conditions. maybe I will write a little article comparing them and also
comparing them with the IC-7610.
Icom IC-756 Pro 3 at the top and IC-76 Pro
2 at the bottom.
So now my IC-756 collection is complete again. Maybe I now need to add an
IC-7600? I would love to add an IC-775 as well but I have not seen or heard
any of those locally.
As mentioned above band conditions have been
quite bad, for DX anyway, did not hear a single CW signal on any band today
just some locals chatting on 40 and 80m. Hopefully things will improve soon.
Update 1/7/2023:
It has been a while since I have posted here, it is not that I have not been
on the air, most day I have the radio on for at least a few hours it is more a
case of being too busy and never getting around to posting! Band conditions
have been up and down, some days decent signals all the way up to 10m and then
suddenly nothing, just a few locals guys chatting on 40m with the odd semi
local QSO on 20m.
I have been concentrating mostly on 17m and 12m and I
have managed to add a few new QRP contacts on those bands. I still do not have
a decent station installed on the yacht but I will be driving to her (and thus
I can take more equipment) towards the second half of July, the plan is to
then at least install a semi permanent setup including winmail facility on
her. I still do not have a radio for her that I am really happy with, I have
been hoping to find something locally but nothing yet.
Talking about
equipment. About 2 years ago I sold my Icom IC-756 Pro3 to someone who was
desperate for a radio. I immediately regretted it as I now no longer have the
full IC-756 range of radios in my collection plus I really enjoyed using the
radio. In many ways I still prefer the older radios with more controls on the
face plus somehow the older analogue radios simply sound better to me than the
newer SDR radios, yes, I know, a very personal thing and for serious
contesting I still use the more modern radios but for everyday operating
radios like the IC-756 Pro3 and my much loved FT-1000MP mkV is still king!
Anyway, I recently saw a Pro3 advertised but I was just too slow, it was
sold by the time I tried to buy it. The seller did say he has a second one
that might be for sale soon as well. The good news is that he contacted me
this week saying it is available and I immediately bought it. Now I have to
wait for the courier to deliver it, hopefully next week. Need to make space
for it in the shack!
Update 6/6/2023:
I have managed to make time for a
few contacts recently. Mostly CW, including a nice few hours having fun during
the CQWW WPX CW contest! Nothing new worked but still fun. I did manage to add
Kenya on 17m CW as well after the contest, a new one on the band!
I am
still searching for the perfect radio to install in the yacht, unfortunately
there is very little available locally, seems like I will have to import.
I have recently started making a few SSB contacts again as well, mostly to
chat to old friends, also planning on starting to report into the maritime
nets soon.
Update 18/5/2023:
It has been a while since I posted
here! Well, firstly I have not been very active, I do switch on the radio most
mornings but seldom make contacts unless I hear a "rare" DX station. The
second reason is that I have been rather busy, first looking for a new yacht.
I found one and bought it, now I need to do some work on it so that I can sail
it from Durban to Knysna where I can spend some time getting to know it and
upgrading some systems.
I also want to make a few changes to the layout
on the inside. Firstly I want to build in a few more cupboards, redo some of
the woodwork and install a new stove. More importantly I want to convert one
of the cabins into a study/shack. At the moment the space is wasted, there are
3 other double cabins and we will never have that many people onboard.
I still need to decide what I am going to do for a HF antenna, when I
stayed on the yacht for a few days recently I just put up an EFLW, seemed to
work well with the one end up about 22m and the other side on the deck.
Running the R928+ I had good results. I will install a radio permanently as
soon as the "shack" is ready! Look out for ZS2M/mm or ZS6DX/mm soon!
SV Katti, Roberts 53
Update 16/2/2023:
OQRS has now been opened for the 3Y0J
expedition. While looking at the QSL manager's web page I noticed that there
is an option to request a log check for "missing" or "busted" calls.
So I though I have nothing to loose and requested a check for my missing
30m contact. You supply your call, date, time, mode and band and the log is
then checked to see if there is a call similar to yours in that time slot, a
nice feature as it is easy to make a typing mistake and get one character
wrong in the log.
I was pleasantly surprised to get an email fro the
QSL manager confirming my contact and that it was fixed in the log! Thanks
Charles (M0OXO)!
So now I am happy with my results, I did miss 12m and
10m, never heard them on those bands. I did see spots for them on 10m and 12m
but though it was a pirate as the frequencies published by the "pilot"
stations did not include those bands at those times. My mistake, it was the
real station, the pilot stations were simply not up to date, lesson learned,
"work them first and worry later".
Here are my results for this
expedition.
So now we wait for the next DX'pedition, I really enjoyed this one despite the
frustrations! I will pay more attention to planned expeditions in the future,
I see there are quite a few semi rare stations on the air at the moment,
combine that with decent propagation at the moment and it is the ideal
opportunity to fill some "band-slots"
Update 12/2/2023:
With the Bouvet expedition just about done they
have managed to upload the SSB and CW logs to Clublog. Sadly I see my 30m
contact is not in the log!
Since I clearly heard my call, signals were
good, and I got a confirmation I can only think that either my call was logged
incorrectly or I worked a pirate. There were lots of pirates around but I do
not think I worked one, the signal strength and direction was consistent with
the real 3Y0J. It is unfortunate as I heard them again after that but did not
work them again wanting "to give smaller stations a chance" as well as
requested by the team. Not that I can think my 5W and low 2 element antenna
would be a thread to any decent station....
I understand they have
limitations especially with an internet connection but if they managed to
upload logs sooner things like this would not have happened, also many
stations would not have felt the need to make "insurance" contacts exactly to
prevent something like this.
Anyway, it is what it is.....
Update 8/2/2023:
Bouvet, 3Y0J still featuring in
this shack! They are still only on 15, 17 and 30m, those I have worked on CW.
There is a chance that they will put up a 20m antenna after the storm they are
having now, maybe Friday? I would love to work them on 20m as well.
Anyway, saw on the DX cluster that they were on 21.105 FT8. Decided to listen
there, OMW, what a complete circus! I cannot believe some of these FT8
operators...... I must say this is curing me from any thoughts of FT8, the
better I get to know it the less I like it...
Screenshot of spots on the cluster, really sad....
The comments on the cluster and behavior in general is quite disgusting. I
must say in the 27 years that I have been on the air things have really
slipped backwards. DX pile-up used to be well behaved with great operators and
courtesy on both sides, now it is really bad.
A bit later they moved to
21.225 SSB. Not normally my thing but I decided to listen. I could hear them
well, around S7 with no QRM, wish there were more stations to out south, nice
and quite from that direction! I found my (always missing) microphone and
decided to try my luck.
I almost fell of my chair when he replied to me
on my second call! Ok, so now 15m SSB is also in the log.
The Hex Beam
is really working well, it seems a lot quieter than my A4S with signals as
strong or sometimes stronger. The front/side and front/back ratios are
noticeably better than the A4S as well. I can only hope that the construction
will stand the test of time.
Update 7/2/2023:
I was awake really early this
morning, was far too hot to sleep comfortably so I headed to the shack just
after 4am local time.
A quick scan of the bands produced mostly silence
other than the 3Y0J pile-up on 30m, I think every single ham on the air was
trying to work them! I could just hear them above the noise so I spent
time trying to figure out the operator's preferred way of scanning a pile-up.
By the time it was breakfast time they were even weaker so I had breakfast
and then I had to head out to drop a vehicle off for a service. Once all that
was done I headed directly back to the shack, I was really getting excited as
I could now hear them clearly, that is when some idiot/lid was not
transmitting simplex, tuning up or calling "up right on top of them!
I decide to try and work them, the pile-up was huge and unruly, but it was
worth a shot. There was also slow QSB, every now and then they would drop
below the noise and a bit later peak again. I tried to call only when they
peaked. After about an hour of this, to my great joy, they replied and I was
in the log!
Not bad for 5W and a dipole at 8m.
A few chores and
a few hours later I listened out for them again. This time I found them on
17m. I turned my hex beam in their direction and the signal was really strong!
This time it took only 2 calls to work them! All the effort getting the hex
beam setup and lifted was worthwhile for this contact!
At the moment
they are only working 12-30m and it looks like they only have a vertical
antenna and maybe a dipole. I will keep an eye on the situation, would love to
work them on more bands!
I need to go and check but I believe this is
DXCC entity number 328 or 329 on QRP, can't remember if FT8WW was also a new
one.
Update late afternoon: After more that an hour of sending my call
and trying to predict where they are listening I finally managed to work 3Y0J
on 15m! What I have found is that with the great front-to-back ratio of the
hex beam I hear very little on the back of the beam, normally that is great
but with Bouvet so far South most of the world, and especially Japan is at the
back of the bean so I cannot hear the pile up!
Since I normally try to
find the station they are working in the pileup and then TX close to him,
above or below depending on the observed direction the operator is moving, I
now cannot do this, rather frustrating! Just shows you there is always a
compromise.
Anyway, been a really good day, managed to work 3Y0J on 3
bands!
Update 6/2/2023:
I was in the shack early this
morning again. Did not hear much on 40m but there were a few stations on 30m,
worked 27 before it was time for other things, nothing special, mostly US
stations with the odd EU call every now and then.
Could not upload logs
to LoTW this morning, we have had internet issues since yesterday afternoon,
apparently it will be fixed today, then I can upload this update as well as
the latest log file.
My normal afternoon session only produced a few
weak signals on 10m, listened around for a while but heard nothing exciting so
I switched off, maybe later this evening I will listen on 30 and 40m.
Update 5/2/2023: The good news is that
TZ4AM, Mali, already QSL'ed for yesterday's contact!
today did not produce
much, in the morning 40m was filled with contest stations but most were US
stations only calling NA...
In the afternoon the bands were very noisy,
think there was so semi local thunder storms. I did make a few contacts but
nothing special. For the first time in a long time I even made a few contacts
on 17m, I seldom hear anything there.
Update 4/2/2023: I was in the shack just before dawn this
morning. I could hear lots of stations on 40m, most of them FOC (Fists only
Club) contest stations. I worked a few of them just for fun, since they were
mostly US stations I was hoping that one of them would be from Wyoming, the
only state still needed for my WAS CW QRP award.
One notable non
contest station I worked was V31XX, Belize, for a new one on 40m CW QRP, hope
he QSL's!
Later I spent some time connecting up some of the older
radios in my collection while listening to the local AWA (Antique Wireless
Association) net. Always some interesting discussions! While I was busy with
this, one of my cats, Kazzi (Not the same of as the one who caused the "QRC"
yesterday, that was Pieta) decided he wanted to chat as well, you can see him
below with the microphone and the vintage but still nice Icom IC-756 behind
him.
12m Netted a new one TZ4AM (Mali) on CW QRP, was a bit of a struggle as he was
working EU and US stations so I was most likely on the back of his beam but
that is something we get used to here at the tip of Africa, antennas are VERY
seldom pointed our way.
Some bad news on 3Y0J, looks like they are
struggling to setup the station due to bad weather and specifically high
winds. Latest news is that they are back on the boat waiting for better
weather. They are making plans for a more limited operation so sadly it will
be a lot more difficult to work them. I still live in hope....
Update 3/2/2023: Band conditions were a bit better today.
I made a few contacts this afternoon on 15, 12 and 10m, mostly to see what
conditions are like. Nothing special worked, most notable was a A75 and an
AP2. I also had a long chat with a US station (N1MX) but unfortunately towards
the end of the QSO I experienced "QRC", What is "QRC"? QRC is interference
caused by a cat! Or maybe in this case it was CAT control?
While I was
DX'ing one of my cats were sleeping on my lap. Halfway through the last QSO she
woke up and started demanding attention. Every time I reached for the CW
paddle she would bump my hand away! I though I had it under control but no,
she is far too clever, unable to reach the key she changed focus to the radio
and managed to move the VFO far away from where it was! So sorry Mike (N1MX),
I could not close the QSO like I wanted...
I see the 3Y0J team are on
Bouvet island setting up camp and the station, hopefully they will be on the
air soon!
The weekend is here and I am planning on spending some time
in the shack, it will be far too hot to do anything outside anyway!
Update 2/2/2023: I made a few contacts yesterday after
the storm passed. Seems like the antenna work a lot better now that it is even
higher up. There is also considerably less noise than on my dipole antennas.
I was busy this morning so did not get time to play with the radio but
this afternoon at about 15:00 UTC I did get some time. The bands seemed quiet
other than 12m that had some activity. I did a quick SWR check and then
started hunting around. I did not take long to work a few stations including
LY2PX and OY1CT I received 579 reports from both. I noticed that I could not
see much movement on my external SWR/Power meter. When I investigated I was
surprised to find that the radio was still set at around 1W output, this was
from when I did SWR checks!
This little radio keep on surprising me!
So it does look like the antenna is
working! Now I feel I am ready for 3Y0J (Bouvet island).
On a DX note,
a while ago I published a list of DXCC entities I still need, this was
generated by Clublog. On the list was the republic of Kosovo. I did find that
strange at the time but hey, if Clublog says so. Anyway, was looking at my
logbook today and decided to search for Z6 (Kosovo) contacts, well I found 2!
So, sorry Clublog, you suck! This is not the first time that I found that
Clublog is not accurate, and they even sometimes just decide a contact you
made is not valid and remove your credit for it for the DXCC standings. And
this is often for QSO's that I already have LoTW confirmation? Sorry, I think
the ARRL LoTW is a far more robust and trustworthy system. Time to delete my
logs from Clublog.
Update 1/2/2023:
February already!
Things have
been quiet on the amateur radio front with only the odd QSO every few days
while I was checking propagation. I have been looking forward to the Bouvet
island expedition this month. I need them for an all time new one, will be
trying to get into the log running QRP so that is going to be fun! They
arrived at the island yesterday so weather permitting they should be on the
air in the next few days.
Keeping the above in mind I really had too
make a plan to get my Hex Beam up a bit higher. With a bit of help I managed
to raise it up to about 7.5m with the top element, 20m, sitting at about 8m. I
could immediately hear the difference! The bands were not great earlier and as
I write this we are experiencing a thunder storm (hope the antenna/mast
holds!) but I am hoping to make a few contacts later today once the lightning
is done.
The Hex Beam with a stormy sky behind it.
Update 18/1/2023: Yesterday conditions were really bad,
during the day I heard almost nothing and even after sunset when 30 an 40m
normally open there was just static with a few faint stations in the
background. Maybe conditions improved later but we had a hectic thunderstorm
around 18h00 local so I unplugged the antennas and never went back to the
shack. I reconnected everything around 4:30 this morning but the bands were
still very noisy as there was still lightning to be seen in the distance.
I did assemble a fan dipole for 10, 12, 15 and 20m during the day
yesterday. I wanted to put up the fan dipole to use as a reference to see how
well the hex beam works. After laying out the coax I decided it was too hot to
continue work so I postponed it till this morning.
Today I decided to
do a bit of antenna work early while it was still cool. I soldered up the
temporary connections on the 30/40m fan dipole, since it works so well I
wanted to make sure it keeps on working so well.
Once that was done I
put up the 10/12/15/20m fan dipole. It was quite a tedious job as you have 8
legs to secure in differed positions! I just managed to get it done before the
sun appeared and I had to rush inside. A quick check with the antenna analyzer
showed that resonance was exactly where I wanted on 15 and 20m but on 10 and
12m it was too high in the band. I know my calculations and measurements were
fine so I can only think it is because of the angle of the legs on those
bands. The way the fan spreads out the legs are not 180deg from each other,
more like 140 degrees.
I will still decide if I will try to fix it,
maybe adding some wire would do it.
First tests showed that the hex
beam was far better, even at 2.5m high it outperforms the 8m high fan dipole
by at least 3S points plus a lot lower noise. Taking this into account I might
not bother to fix the fan dipole. Maybe the next time I take down the dipoles
I will convert the fan dipole to 80 and 160m?
While I was playing with
the antennas I heard TN8K on 12m CW. It was quite easy to work him despite
some QRM coming that time of the day from my neighbor's solar array. Listening
up the band I heard a decent SSB signal. I had to quickly find a microphone!
Once I had the microphone connected and the radio setup correctly I had a nice
chat with Andre C5YK in Gabon. I have not checked but I am pretty sure it is a
new one on 12m SSB and maybe even on 12m!
I think I will leave the
microphone connected and listen on the SSB portions of the bands more often.
Not all good DX work CW!
Update 16/1/2023:
Despite the bad conditions on all the
HF bands during the day yesterday 30m did open up after sunset and I spent
many hours working DX. I have not done a full log check yet but I have already
received QSL's confirming 5 new DXCC entities on 30m. Was fun!
Unfortunately after sunrise today the bands slowly died again. I am not sure
why as the predictions showed "Good" conditions during the day on 10-20m.
Maybe there was a solar storm.
Below you can see my totals as they
stand today.
I am really hoping that conditions would soon improve during the day. We are
having really hot weather at the moment and I seldom go outside during the day
so I have lots of time on my hands, would have been great if I could DX a bit.
Oh well, maybe tomorrow....
Update 15/1/2023:
The
bands were really bad today. I only managed a few contacts early in the
morning before sunrise. The rest of they day I never heard a DX signal above
S1 so QRP contacts were not possible.
I spent a bit of time today
merging my logs and uploading them to LoTW and Clublog. I also updated and
merged my local logs into the two logbook programs I use, Logger32 and Winlog.
The updates gave me a more complete picture of where my DXCC standings are
and where I should concentrate my time.
DXCC standings on 15/01/2023.
From the above it is clear that I need to concentrate on the WARC bands and 40/80m. Maybe 160m sometime in the future but before I go to all that static I will work on the other bands first! The lower the band the more difficult it becomes with QRP power levels.
My "Wanted" list, the DXCC entities I have not
worked.
Seeing the list of DXCC entities I still need to
work I can see that it will take some time, most of them would need an
expedition, patience will be needed.....
Update #2 14/1/2023:
Turns
out the bands were quite bad today, during the daytime anyway. I could hear
signals on 15, 12 and 10m but mostly just above the noise. The only station of
note I worked was TN8K on 10m after working him on 30m last night. I could
hear the FT8WW pile-up but never heard FT8WW.
Oh well, can't always
have great conditions! Still hoping for some good conditions on 30m after
sunset.
Update 14/1/2023:
30m did
open last night and it was great!
A few days ago I decide to take down
my old G5RV as I was no longer using it since I now have the Hex Beam. On the
same mast I have a 40m dipole. Once I had it down I decided, just for fun, to
cut the G5RV legs to the correct length for a 30m dipole. It was a very rough
measurement and I just connected the legs onto the 40mm dipole feed line
"fan-dipole" style.
I did not expect much but a quick check with the
antenna analyzer showed that it resonated perfectly at the bottom end of the
band, I think some good luck was involved!
Well, this "quick and dirty"
dipole proved itself last night! I could work just about everything I could
hear! 56 Contacts in around an hour including TN8K for a new one on 30m as
well as a D2 station! I am sure this antenna will help me to get those 30m
totals up!
Talking about totals, for the first time in years I uploaded
my logs to Clublog. I have all my QSO's on Clublog, not just the QRP contacts
like I do on LoTW. Below you can see my all time totals, QRP and QRO as they
stand today.
As far as the DXCC entities I have not worked I see that with the exception of
one, Kosovo, they are all uninhabited islands.
Lets see what today produces, early this morning
30m was wide open again but mostly to the USA, will try again after sunset
today.
Update 13/1/2023:
Friday
the 13'th, funny, never bother with things like this but this morning I headed
to the shack before sunrise to try and work a few stations on 30 and 40m.
Fired everything up only to discover that my logging laptop refuses to boot.
Made few contacts but I was distracted, I needed to figure out what was wrong
with the laptop and more importantly if I needed to setup all the software
again. The ham software was not my biggest worry, the same laptop also serves
as my Astrophotography laptop and it has a LOT of integrated and complex
software running on it that controls my telescope and everything that goes
with it.
Figured out the hard-drive failed, took me half the day to
sort it out, anyway, the laptop now has a new disk and I managed to image the
old drive and transfer all the software and setups to the new one. Well, on
the positive side, the laptop now boots a lot faster!
I have received
the QSL confirmation for DXCC 100 on 12m! Turned out it was Northern Ireland!
Now I need to work on 17, 30 and 40m! Looks like 30m is opening up as I write
this just before sunset so time to head to the shack!
Update 11/1/2023: The last 2
days have been quite productive. I have been concentrating on 12m as it is a
band I have neglected in the past but I also worked a few new ones on other
bands including Australia (VK) on 40m CW QRP and Lebanon on 15m.
My Hex
Beam is still low, I wanted to lift it early yesterday morning, while it was
still cool but I noticed that a few of the ropes/cords that keep it tight had
slipped. The way they are attached (actually just slipped over) the end of the
spreaders is not very secure. I fixed them by leaning the antenna over and
getting on a ladder but for long term security I think I will add zip-ties
over them. I did do that to 2 of the spreaders so while waiting for the
weather to cool down I will monitor them.
Other than this little
problem the antenna is working well and seems quite robust, I have dropped it
on it's side from about 3m (ladder moved on the lawn and I almost fell) and it
survived without any damage. We also had a lot of wind and it does not seem to
be bothered.
I managed to work a few new ones on 12m, my "confirmed"
total for 12m QRP in LoTW is no 99, just need one more for DXCC!
While
checking my totals on LoTW I noticed the I need only one state (Wyoming) on CW
QRP for WAS. I need to go chase Wyoming!
On a similar note, I only need
one zone, Zone 23, for WAZ CW QRP. Since zone 23 is central Asia I am sure it
can be done, I most likely have the QSO I just need the QSL. Something else to
"chase"!
Update 9/1/2023: Conditions
were really not great yesterday! I tried for hours to crack the TN8K pileup
but 5W was simply not enough. I suppose his antenna was pointing to EU
anyway, no chance on 3 different bands. I have to admit the thought of
connecting one of my large amplifiers did cross my mind but I resisted the
temptation....
I did manage to work Luxembourg
and Faroe islands on 17m, both new on that band, in both cases the signals
were just above the noise.
When I tried to upload the day's QSO's to
LoTW last night there was a server error! I see other guys are also
complaining on the ARRL forum, hopefully the problem will be solved soon. Will
try again today when I am finished with my contacts for the day.
Hopefully conditions will improve over the
next few days!
I still need to lift the Hex Beam but the next 6 days
are going to be extremely hot, maybe I can make a plan early one morning?!
Update 8/1/2023:
The little R928 Plus still amazes me. Initially I
had a few issues with it, all firmware related, there are so many versions of
the firmware out there and not all of them work equally well on all versions
of these radios as there are subtle hardware differences. Once I figured that
out and found a stable firmware version all was well. Since there are no bugs
or missing features in the firmware that I am running now I have no desire to
upgrade and potentially create more problems!
Chasing DX
with the little R928 Plus.
The receiver on this radio is great, sensitive and selective and the digital
noise reduction works great. The CW filters are really effective with sharp
skirts and no AGC pumping from nearby strong signals. I am glad I stuck with
it and did not give up after initial problems.
One really irritating thing about the radio when I got it
were the two little metal plates that were supposed to serve as a stand. They
kept on falling of and you had to be careful when operating as they tended to
move and then the radio would suddenly drop to a level position. I sorted the
problem out by 3D printing a stand as can be seen in the photos, now it is
stable on the bench and a real pleasure to use!
The latest FT8WW log was uploaded this morning and I was really happy to see
my confirmation!
Seems like there is still a chance to work him on 15m (I have never seen a 15m
spot for him but it seems like he has been active there) and also 30m. Since I
am NOT interested in FT8 there is no chance of 17m at the moment.
Update 7/1/2023: I heard FT8WW again yesterday
afternoon. Initially the signal was in the noise but it slowly improved up to
the point where I had hope. I ran outside to manually rotate the Hex Beam in
the right direction, as I moved the antenna I could hear his signal get
stronger through the open window. I rushed back inside to see that his signal
was now peaking around S8!
Just as I sat down to give him a call he
announced that he was going QRT! Oh no, missed him again! But now I knew the
signal can be strong enough to hopefully work and that the antenna is at least
reasonably directional.
Fast forward to this morning, just after making
coffee I rushed to the shack, around 5am local time. I could see the pileup on
the band scope (was using the R928+) so I knew there was hope. Back outside to
move the antenna again and now I could just hear him.
R928+ on top
of the rotator controller, hunting FT8WW and other DX
I called a few
times but decided to wait as the signal was slowly improving. Finally he was
up to S5-7 with some QSB so I started calling, the pileup was quite wide so it
took me a while to figure out where he was listening and in what direction he
was scanning.
I found an open spot just ahead of the last station he
worked and called when he was done! What a nice thing to hear "ZS2?" I replied
and he came back with a ZS2M 599! I sent him a 599 and then to my surprise he
came back and said "ZS2M, fb signal, 599+ fb!". I could not believe it, he
never said something like that while I was listening! He did not even know I
was only running 5W! Well, now FT8WW is in the bag, on 20 at least, a new QRP
DXCC entity and also an all time new one!
Well after that I was really
inspired to work on my station so the rest of the morning was spent getting
cables ready for the rotator and RG-213 feed line for the antenna. It was
getting hot outside in the sun but with the antenna now on the ground I had to
at least get it up again. I managed to get it back up before the sun chased me
inside, it is still low, now about 3m high but the rotator is now mounted and
I will be able to lift the antenna, when it is safe to go outside again, in 2m
steps so the hard work is done.
6 Band Hex
beam on the rotator ready to go.
Now I am hoping for some DX this
afternoon, will be concentrating on 12 and 17m.
Update: Late afternoon
produced some results on 15m and later on 20m but other than a TN8K pileup,
where I could hear the callers but not the DX station, there was not much on
12 or 17m.
On 15m I did work a new QRP band-country, Algeria, I am
hoping he will QSL vie LoTW! So far I am having fun with the hex beam, now
that I can turn it I can report that it has a better front to back and front
to side ratio than any of the Yagi's I have used in the past like the A4S, TH4
and TH7DX, this is good news!
Unfortunately after assembling it and
setting it up I do not think that the antenna will be usable for field station
or semi-portable operation, it is simply too difficult to setup and clumsy to
move around. But I still need to see if there is a way I can make the
spreaders foldable and then find a way to fold up the wires so they do not
tangle, time will tell....
Update 6/1/2023: After
a bit of confusion, on the couriers side, my 6 band Hex beam kit arrived
yesterday. I immediately started assembling it between rain showers (yes, it
does rain in the desert!)
It went together quiet well, no real issues.
My only concern, and this may be groundless, is how well the plastic clips
that retain the wire elements will handle harsh sun and UV. They seem quite
soft and flexible, maybe the material was made to be extra UV resistant? Time
will tell but somehow I do not think it will last as long as my Yagi antennas.
Once assembly was completed I stuck it on a 3m pole, the plan was to keep
it low so that I could make any adjustments if needed. A sweep with my antenna
analyzer showed that it dipped perfectly for a very low SWR on all 6 bands!
Great news. I connected it up to a radio and the first impression was that it
was nice and quiet, most likely due to the good front to back ratio as it was
pointing away from the solar array to the South that can generate lots of
noise.
Rain interfered again so the antenna is still low, will raise it
when the weather is better but for now I will try to make a few contacts.
Update: I managed to make some contacts on the new antenna. The bands were
really dead but I did manage to work Faroe Islands on 2 bands but more
importantly I managed to work a new one on 12m, French Guiana. It is great to
finally have a directional antenna on 12! I had to drop the antenna a bit on
it's temporary mount due to really high winds, it is on a thin pole stuck into
the lawn and not very stable so it was only 2.1m high when I made the
contacts.
Update 5/1/2023:
Had a weak opening on 15m yesterday afternoon. I only switched
on the radio at 14:00 UTC and heard a few stations, started working them but
the signals were dropping quickly! I think I need to try again today but a bit
earlier. Might also try 10m around 18:00 UTC, saw some spots that time of the
day.
Update 4/1/2023:
Unfortunately it looks like the FT8WW station I worked on 14.031 CW was indeed
a pirate. It was a bit surprising when he came back to me and sounded stronger
than before but you never know, it was worth the chance! A search in the
online FT8WW log shows that I am not logged, oh well...
He was active
on 14.031 CW again this morning but there was no way I could hear him as I had
a constant S8-9 QRM signal right on 14.031! This is what is sounded like,
Recording. There was
no way I could hear him. He seems to be only active on 2 frequencies on CW, 20
and 30m so if the QRM stays on that frequency it is bad news. The good news is
that apparently he will be there till 26 March 2023 so there is still hope.
I am really hoping that the Hex Beam will arrive today, I traced the
parcel to the courier depot closest to me yesterday (about 200km away) so with
a bit of luck it will be delivered today or at the latest tomorrow morning. It
has been really hot the last few days, 41-43C but the prediction is for the
low 20's tomorrow, would be perfect weather to assemble the antenna!
On
a different note, a year ago we decided to go completely off-grid for our
power. We decided on this due to the constant load shedding and power
failures and little hope of things getting better. I worked out what we needed
and sourced the components and then installed it. Over the last 12 months it
worked perfectly and we are no longer affected by the power issues South
Africa is suffering from. As a matter of interest over the first 12 months we
"harvested" 2.5MWh of sun energy.
The system is capable of a lot more
but that is what we used. With 20KWh of storage we are covered for cloudy days
as even on cloudy days we still produce at least 25% of our solar array's full
rating. The highest wattage I have seen from the array is 3.85KW so it does
not take long on a sunny day to charge the storage bank back to 100%.
The nice thing is that my entire station is now affectively solar powered!
Update 2/1/2023:
As I have mentioned I have ordered a 6 band hex beam that I am hoping could be
modified for quick setup and fold-up for transport. If I can make it work it
will become my portable and field station antenna, specifically to be used
with the motorhome. I am hoping to receive the bits next week. At first I will
test it at home, if all is well I need to see if my collapsible portable mast,
a Comet CP-80, will support it. Maybe not at the full 8m height but I would be
happy if it would work at maybe 5m?
Time will tell! Now it is just the
choice of a new radio that remains, maybe for initial shorter test trips I
will just use one of the radios I already have.
Update
2 of 1/1/2023:
I could hear FT8WW again on 20m this morning.
Today his signal varied between S0 and S2 with noise most of the time around
S1. I decided I will try today since the pile-up seemed a bit better. I called
quite a few times, FT8WW was on 14.031 and the split was from 14.032 to about
14.042.
I eventually received a reply that sounded like ZS2M, well, 2M
at least but, as before, there were so many guys calling on 14.031 and
shouting "up on 14.031 that even after repeating 3 times I was not sure he
was replying to me. I ended up sending 599 and heard "TU" and then he worked
the next station. So I am not sure if I worked him or not, will have to wait
till he uploads his log so I can check. Again a bunch of idiots ruined it for
many of us.....
Ok, trying to stay positive, hopefully I did work him
and it is a great start to DX'ing in 2023 with a brand new QRP DXCC entity.
Update
1/1/2023:
Happy new year! Hopefully this will be a radio filled year for all of us!
I heard FT8WW again on 20m CW yesterday morning, this time the signal was
a bit stronger and the pile-up not as wide and better behaved. Unfortunately I
had other commitments and did not have time to try and work him, maybe today?
I am not so sure how long he is going to be there, need to find out today.
The rest of the day yesterday was a waste of time due to a geomagnetic
storm that shut down long distance propagation.
No real "new years"
resolutions this side other than to travel more this year and have more fun!
Hopefully some of that fun will be amateur radio related. Hope to hear you on
the air in 2023!
(c)R Venter 2023
