Maximum Take-off Weight 394,625 kg/870,000 lb Cruise Altitude 29-43,000 ft Wing Span 64.94 metres/213.0 ft Maximum Fuel Capacity 216,507 litres/47,614 gallons Overall Length 70.4 metres/231.8 ft Range With Full Payload 12,700 km/7,892 miles Vertical Fin Height 18.96 metres/62.2 ft Freight Capacity 13,400 kg/29,542 lb Cabin Width 6.1 metres/20 ft Volumetric Payload 48,400 kg/106,704 lb Wing Area 525 sq m/5,650 sq ft Maximum Thrust 258.0 kilonewton/58,000 lb Average Cruise Speed 920 kph/572 mph Engines Rolls-Royce RB211-5 24D4G

Maximum Take-off Weight 377,842 kg/833,000 lb Cruise Altitude 30-42,000 ft Wing Span 59.64 metres/195.7 ft Maximum Fuel Capacity 204,355 litres/44,952 gallons Overall Length 70.4 metres/231.8 ft Range With Full Payload 10,271 km/6,382 miles Vertical Fin Height 18.96 metres/62.2 ft Freight Capacity 13,641 kg/30,073 lb Cabin Width 6.1 metres/20 ft Volumetric Payload 51,727 kg/114,038 lb Wing Area 511 sq m/5,500 sq ft Maximum Thrust 236.25 kilonewton/53,110 lb Average Cruise Speed 920 kph/572 mph Engines Rolls-Royce RB211-5 24D4U

Maximum Take-off Weight 377,842 kg/833,000 lb Cruise Altitude 30-42,000 ft Wing Span 59.64 metres/195.7 ft Maximum Fuel Capacity 204,355 litres/44,952 gallons Overall Length 70.4 metres/231.8 ft Range With Full Payload 10,469 km/6,506 miles Vertical Fin Height 18.96 metres/62.2 ft Freight Capacity 10,827 kg/23,869 lb Cabin Width 6.1 metres/20 ft Volumetric Payload 50,580 kg/111,509 lb Wing Area 511 sq m/5,500 sq ft Maximum Thrust 236.25 kilonewton/53,110 lb Average Cruise Speed 920 kph/572 mph Engines Rolls-Royce RB211-5 24D4U

Maximum Take-off Weight 172,365 kg/380,000 lb Cruise Altitude 35-41,000 ft Wing Span 47.57 metres/156.0 ft Maximum Fuel Capacity 91,040 litres/20,026 gallons Overall Length 54.94 metres/180.25 ft Range With Full Payload 8,154 km/5,067 miles Vertical Fin Height 15.85 metres/52.0 ft Freight Capacity 11,170 kg/24,623 lb Cabin Width 4.72 metres/15.5 ft Volumetric Payload 34,209 kg/75,418 lb Wing Area 283.3 sq m/3,050 sq ft Maximum Thrust 273.53 kilonewton/61,500 lb Average Cruise Speed 857 kph/533 mph Engines General Electric CF 6-80C2B6

Maximum Take-off Weight 156,500 kg/345,000 lb Cruise Altitude 35-41,000 ft Wing Span 47.57 metres/156.1 ft Maximum Fuel Capacity 77,412 litres/17,028 gallons Overall Length 48.51 metres/159.2 ft Range With Full Payload 7,034 km/4,371 miles Vertical Fin Height 15.85 metres/52.0 ft Freight Capacity 8,276 kg/18,245 lb Cabin Width 4.72 metres/15.5 ft Volumetric Payload 27,549 kg/60,735 lb Wing Area 283.3 sq m/3,050 sq ft Maximum Thrust 221.5 kilonewton/49,800 lb Average Cruise Speed 857 kph/533 mph Engines Pratt & Whitney JT9 D-7R4E

Maximum Take-off Weight 68,034 kg/149,684 lb Cruise Altitude 33-37,000 ft Wing Span 28.88 metres/94.75 ft Maximum Fuel Capacity 23,830 litres/6,295 gallons Overall Length 36.45 metres/119.58 ft Range With Full Payload 4,400 km/2,750 miles Vertical Fin Height 11.13 metres/36.51 ft Freight Capacity 2,868 kg/6,323 lb Cabin Width 3.54 metres/11.62 ft Volumetric Payload 15,540 kg/34,259 lb Wing Area 91 sq m/980 sq ft Maximum Thrust 104.788 kilonewton/22,000 lb Average Cruise Speed 830 kph/516 mph Engines CFM56-3C-1

Maximum Take-off Weight 61,235 kg/134,717 lb Cruise Altitude 33-37,000 ft Wing Span 28.88 metres/94.75 ft Maximum Fuel Capacity 20,105 litres/5,311 gallons Overall Length 33.4 metres/109.58 ft Range With Full Payload 4,100 km/2,560 miles Vertical Fin Height 11.13 metres/36.51 ft Freight Capacity 2,978 kg/6,565 lb Cabin Width 3.54 metres/11.62 ft Volumetric Payload 13,442 kg/29,634 lb Wing Area 91 sq m/980 sq ft Maximum Thrust 98.1 kilonewton/21,000 lb Average Cruise Speed 830 kph/516 mph Engines CFMS56-3B-2

Maximum Take-off Weight 157,500 kg/346,500 lb Cruise Altitude 31-35,000 ft Wing Span 44.84 metres/147.1 ft Maximum Fuel Capacity 60,750 litres/16,048 gallons Overall Length 54.08 metres/177.42 ft Range With Full Payload 5,400 km/3,375 miles Vertical Fin Height 16.55 metres/54.20 ft Freight Capacity 10,747 kg/23,693 lb Cabin Width 5.1 metres/16.75 ft Volumetric Payload 33,979 kg/74,910 lb Wing Area 260 sq m/2,799 sq ft Maximum Thrust 230.01 kilonewton/51,708 lb Average Cruise Speed 865 kph/538 mph Engines CF6-50

Maximum Take-off Weight 38,102 kg/84,000 lb Cruise Altitude 29,000 ft Wing Span 26.21 metres/86.0 ft Maximum Fuel Capacity 11,728 litres/3,100 gallons Overall Length 26.20 metres/85.96 ft Range With Full Payload 1,667 km/1,040 miles Vertical Fin Height 8.61 metres/28.25 ft Freight Capacity 1,500 kg/3,300 lb Cabin Width 3.42 metres/11.21 ft Volumetric Payload 6,110 kg/13,470 lb Wing Area 77.30 sq m/832 sq ft Maximum Thrust 124 kilonewton/6,970 lb Average Cruise Speed 669 kph/416 mph Engines LYCOMING ALF 502R-5

Maximum Take-off Weight 6,950 kg/15,322 lb Cruise Altitude 25,000 ft Wing Span 15.85 metres/52 ft Maximum Fuel Capacity 1,707 litres/451 gallons Overall Length 14.36 metres/47.13 ft Range With Full Payload 704 km/440 miles Vertical Fin Height 5.38 metres/17.66 ft Freight Capacity N/A Cabin Width 1.85 metres/6.08 ft Volumetric Payload 1,692 kg/3,730 lb Wing Area 25.2 sq m/271.24 sq ft Maximum Thrust 2 x 760 kilowatt engines Average Cruise Speed 478 kph/297 mph Engines GARRETT TPE331

Maximum Take-off Weight 3,810 kg/8,400 lb Cruise Altitude 10,000 ft Wing Span 14.12 metres/46.33 ft Maximum Fuel Capacity 1,287 litres/340 gallons Overall Length 12.04 metres/39.52 ft Range With Full Payload 1,025 km/649 miles Vertical Fin Height 4.04 metres/13.25 ft Freight Capacity N/A Cabin Width 1.42 metres/4.66 ft Volumetric Payload 846 kg/1,865 lb Wing Area 22.48 sq m/242 sq ft Maximum Thrust 2 x 280 kilowatt engines Average Cruise Speed 302 kph/188 mph Engines CONTINENTAL GTSIO-520-M

Maximum Take-off Weight 15,650 kg/34,500 lb Cruise Altitude 25,000 ft Wing Span 25.91 metres/85 ft Maximum Fuel Capacity 3,160 litres/835 gallons Overall Length 22.25 metres/73 ft Range With Full Payload 1,557 km/970 miles Vertical Fin Height 7.49 metres/24.58 ft Freight Capacity N/A Cabin Width 2.49 metres/8.166 ft Volumetric Payload 3,384 kg/7,460 lb Wing Area 54.35 sq m/585 sq ft Maximum Thrust 2 x 1513 kilowatt engines Average Cruise Speed 463 kph/288 mph Engines PRATT & WHITNEY PW120A

Maximum Take-off Weight 12,292 kg/27,100 lb Cruise Altitude 10,000 ft Wing Span 22.80 metres/74.79 ft Maximum Fuel Capacity 2,182 litres/576 gallons Overall Length 21.58 metres/70.9 ft Range With Full Payload 1,020 km/638 miles Vertical Fin Height 7.27 metres/23.854 ft Freight Capacity N/A Cabin Width 1.93 metres/6.333 ft Volumetric Payload 3,102 kg/6,839 lb Wing Area 42.18 sq m/454 sq ft Maximum Thrust 2 x 1,062 kilowatt engines Average Cruise Speed 400 kph/249 mph Engines PT6A-67R

Maximum Take-off Weight 5,670 kg/12,500 lb Cruise Altitude 10,000 ft Wing Span 19.81 metres/65.0 ft Maximum Fuel Capacity 1,446 litres/382 gallons Overall Length 15.77 metres/51.75 ft Range With Full Payload 1,297 km/810 miles Vertical Fin Height 5.94 metres/19.5 ft Freight Capacity N/A Cabin Width 1.61 metres/5.27 ft Volumetric Payload 1,786 kg/3,937 lb Wing Area 39.02 sq m/420 sq ft Maximum Thrust 2 x 486 kilowatt engines Average Cruise Speed 277.8 kph/172.74 mph Engines PRATT & WHITNEY PT6 A-27
