HAM RADIO BANDS

3.500 to 3.900 MHz - 80 Metres

3.500-3.520 CW DX Window simplex or split
3 530 IOTA CW Calling Frequency
3.559 Hellschreiber(USB Region 3)
3 560 QRP CW Calling Frequency
3.570 BPSK31
3.575 Hellschreiber (USB)
3.576 JT65A (USB)
3.580 RTTY
3.590 RTTY DX
3 620-3.640 VK/ZL Digital Window
3.710 QRP CW Calling Frequency
3.730-3.740 SSTV (ITU Region 1)
3.755 IOTA SSB Calling Frequency
3.776-3.800 SSB DX Window
3.845 SSTV (Region 2)
3.885 AM Calling Frequency

7.000 to 7.300 MHz - 40 Metres
7.000-7.020 CW DX Window simplex or split
7.030 IOTA CW Calling Frequency
7.030-7.040 Hellschreiber (USB)
7.035-7.040 BPSK31 (ITU Regions 1 & 3)
7.035-7.045 RTTY (ITU Regions 1 & 3)
7.039 JT65A (USB)
7.039 Hellschreiber (USB)
7.040 RTTY DX
7.040 QRP Calling Frequency (Region 2)
7.070-7.075 BPSK31 (Region 2)
7.076 JT65A (USB)
7.080 RTTY (Region 2)
7.084 Hellschreiber (USB Region 1)
7.075-7.100 SSB Calling Simplex or split
7.100-7.200 SSB (Region 1)
7.125-7.300 SSB (Region 2)
7.171 SSTV
7.285 QRP Calling Frequency
7.290 AM Calling Frequency

10.100 to 10.150 MHz - 30 Metres
10.000-10.010 CW DX Window simplex or split
10.115 IOTA CW Calling Frequency
10.116 QRP CW Calling Frequency
10.135-10.145 Hellschreiber (USB)
10.139 JT65A (USB)
10.140 BPSK31
10.140-10.150 RTTY
10.147 MFSK16 (USB)
14.00 to 14.350 MHz - 20 Metres
14.000-14.025 CW DX Window simplex or split
14.040 IOTA CW Calling Frequency
14.060 CW QRP Calling Frequency
14.070-14.0725 QPSK31 FSK31 BPSK31
14.0715-14.073 PSK63
14.071-14.075 Hellschreiber (USB)
14.073 Hellschreiber DX Calling Frequency (USB)
14.076 JT65A (USB)
14.078-14.080 Throb
14.078-14.082 MFSK16 (USB)
14.080-14.90 RTTY
14.090-14.110 Packet
14.100 NCDXF International Beacon Network
14.109-14.111 MT63 (USB)
14.190-14.197 SSB DX Calling Simplex or split
14.227 SSTV
14.230 SSTV
14.233 SSTV
14.236 SSTV
14.260 IOTA SSB Calling Frequency
14.285 SSB QRP Calling Frequency
14.286 AM Calling Frequency

18.968 to 18.168 MHz - 17 Metres
18.072-18.080 CW DX Window simplex or split
18.090 IOTA CW Calling Frequency
18.100 BPSK31 (USB)
18.102 JT65A (USB)
18.104-18.107 Hellschreiber (USB)
18.105 MFSK16 (USB)
18.110 NCDXF International Beacon Network
18.128 IOTA SSB Calling Frequency
18.135-18.145 SSB DX Calling simplex or split

21.000 to 21.450 MHz - 15 Metres
21.000-21.025 CW DX Window simplex or split
21.040 IOTA CW Calling Frequency
21.060 QRP CW Calling Frequency
21.063-21.070 Hellschreiber (USB)
21.063 MFSK16 (USB)
21.070 BPSK31 (USB)
21.074 Hellschreiber (USB)
21.076 JT65A (USB)
21.080 BPSK31 (USB)
21.080 RTTY DX
21.080-21.110 RTTY
21 150 NCDXF International Beacon Network
21.275-21.297 SSB DX Calling simplex or split
21.340-21.430 SSTV
21.385 QRP SSB Calling Frequency
21.260 IOTA SSB Calling Frequency

24.890 to 24.990 MHz - 12 Metres
24.890-24.910 CW DX Window simplex or split
24.920 JT65A (USB)
24.920-24.925 BPSK31 (USB)
24.920-24.930 RTTY
24.924 Hellschreiber (USB)
24.930 NCDXF International Beacon Network
24.935-24.950 SSB DX Calling simplex or split
24.950 IOTA SSB Calling Frequency

28.000 to 29.700 MHz - 10 Metres
28.000-28.025 CW DX Window simplex or split
28.060 QRP CW Calling Frequency
28.063-28.070 Hellschreiber (USB)
28.074 Hellschreiber (USB)
28.076 JT65A (USB)
28.080 RTTY DX
28.080-28.110 RTTY
28.120 BPSK31 (USB)
28.200-28.300 Beacons
28.200 NCDXF International Beacon Network
28.385 QRP SSB Calling Frequency
28.475-28.497 SSB DX Calling simplex or split
28.460 IOTA SSB Calling Frequency
28.560 IOTA SSB Calling Frequency
28.675-28.685 SSTV
28.885 6m Liaison Frequency
29.000-29.200 AM Operations
29.300-29.510 Satellite Downlinks
29.520-29.580 Repeater Inputs
29.600 FM Simplex Calling Frequency
29.620-29.680 Repeater Outputs

50.000 to 52.000 MHz - 6 meters
50.000 - 50.020 MHz - Telegrafia
50.020 - 50.080 MHz - Radiolatarnie
50.080 - 50.100 MHz - Telegrafia
50.090 MHz - Środek aktywności telegrafii
50.100 - 50.500 MHz - SSB
50.000 - 50.130 MHz - Łączności międzykontynentalne CW/SSB
50.110 MHz - Wywołanie DX
50.150 MHz - Środek aktywności SSB
50.185 MHz - Środek aktywności crossband
50.200 MHz - Środek aktywności MS
50.230 MHz - Środek aktywności JT6M
50.500 MHz - 52.000 - Wszystkie emisje
50.510 MHz - SSTV AFSK
50.550 MHz - FAX
50.600 MHz - RTTY FSK
50.620 - 50.750 MHz - Emisje cyfrowe
51.210 - 51.390 MHz - Wejścia przem. FM od F21 (50.210) do F39 (51.390) co 10 kHz
51.410 - 51.590 MHz - Kanały simpleksowe FM od F41 (51.410) do F59 (51.590)
51.810 - 51.990 MHz - Wyjścia przem. FM od RF81 (51.810) do RF99 (51.990) co 10 kHz

144.000 to 146.000 MHz - 2 Metres
144.000 - 144.150 MHz - Telegrafia
144.000 - 144. 035 MHz - EME CW i SSB
144.050 MHz - Wywołanie CW
144.100 MHz - Częstotliwość odniesienia dla Random MS CW
144.140 - 144.150 MHz - FAI CW
144.150 - 144.400 MHz - SSB
144.150 - 144.160 MHz - FAI SSB
144.195 - 144.205 MHz - Random MS SSB
144.300 MHz - Wywołanie SSB
144.390 - 144.400 MHz - Random MS SSB
144.400 - 144.490 MHz - Radiolatarnie
144.490 MHz - Sarex uplink
144.490 - 144.500 MHz - Wycinek ochronny
144.500 - 144.800 MHz - Wszystkie emisje
144.500 MHz - Wywołanie SSTV
144.525 MHz - Częst. środkowa odpowiedzi ATV (SSB) 144.600 MHz - Wywołanie RTTY
144.700 MHz - Wywołanie FAX
144.750 MHz - Kanał rozmówny i wywołanie ATV
144.800 - 144.990 MHz - Emisje cyfr.
144.990 - 145.1875 MHz - Wejścia przem. NBFM (kanały V00 (145.000) do V15 (145.1875) co 12.5 kHz)
145.1875 - 145.5875 MHz - NBFM simplex (kanały V16 (145.200) do V47 (145.5875) co 12.5 kHz)
145.5875 - 145.800 MHz - Wyjścia przem. NBFM (kanały RV48 (145.600) do RV62 (145.775) co 12.5 kHz)
145.800 - 146.000 MHz - Łączność satelitarna

430.000 to 440.000 MHz - 70 cm
430.000 - 430.400 MHz - NBFM
430.0125 - 430.3875 MHz - Kan. wej. przem. (F) U001 - U031
430.400 - 430.9375 MHz - łaczność cyfrowa
430.400 - 430.550 MHz - Linki transmisji cyfrowych
430.600 - 430.925 MHz - Packet Radio dupleks, kan. wej. digipeaterów PR52 - PR65
430.9375 - 431.0375 MHz - Wszystkie emisje
430.950 - 431.025 MHz - Kan. wej. multi-mode R66 - R69
431.0375 - 431.9875 MHz - NBFM
431.050 - 431.825 MHz - Kan. wej. przem. (HB,DL,OE) U084 - U146
431.60125 - 431.9875 MHz - Kan. wyj. przem. (F) U129 - U159
432.000 - 432.150 MHz - Telegrafia
432.000 - 432.025 MHz - EME
432.050 MHz - Środek aktywności telegrafii
432.150 - 432.800 MHz - SSB
432.200 MHz - Środek aktywności SSB
432.350 MHz - Środek kanałów rozmównych łączności mikrofalowych
432.500 MHz - SSTV wąskopasmowa
432.600 MHz - RTTY FSK/PSK
432.700 MHz - FAX (FSK)
432.750 MHz - FSK PSK cyfrowa
432.150 - 432.600 MHz - Wejścia przem. liniowych
432.600 - 432.800 MHz - Wyjścia przem. liniowych
432.800 - 432.990 MHz - Radiolatarnie
432.990 - 435.000 MHz - NBFM
433.000 - 433.3875 MHz - Kan wej. przem. (R1 IARU) U240 - U271
433.400 - 434.5875 MHz - Kan. simplex U272 - U367
434.600 - 434.9875 MHz - Kan. wyj. przem (R1 IARU) RU368 -RU399
435.000 - 438.000 MHz - Łączność satelitarna
438.000 - 438.050 MHz - Segment ochronny
438.050 - 438.5375 MHz - Emisje cyfrowe
438.200 - 438.525 MHz - Packet Radio dupleks, kan. wyj. PR52 - PR 65
438.550 - 438.625 MHz - Kan. wyj. multimode, R66 - R69
438.6375 - 439.4375 MHz - NBFM
438.650 - 439.425 MHz - Kan. wyj. przem. (HB,DL,OE) RU692 - RU754
439.43125 - 439.800 MHz - Segment ochronny
439.800 - 440.000 MHz - Linki transmisji cyfrowych
--------------------------------------------------------

----- SKCC
3530 3550 7055 7120 10120 14050 18080 21050 24910 28050


----- AM
29.000 - 29.200 MHz , 3.870-3.885 Mhz
1.885, 1.930, 1.985, 3.615, 3.625, 7.285, 14.286, 21.425, 29.910 Mhz


----- FM
29.600 FM Simplex
29.620-29.680 Repeater Outputs

----- IOTA
3530 3755 7055 10115 14040 14260 18098 18128 21040 21260 24920 24950 28040 28560


----- QRP
3560 3690 7030 7090 10106 10116 14060 14285 18096 21060 21285 24910 24950 28060 28360


----- PSK
3580 7035 10140 14070 18110 21070 24920 28120


----- DX
3505 3799 7010 7065 10110 14025 14195 18075 18145 21025 21295 24895 24945 28025 28495


----- HF Pack 3559cw 3791usb 7029,5cw 7185usb 10117,5cw 14059cw 14342,5usb 14346usb 18081cw 18117,5usb 18157,5usb 18158cw 21437,5usb 21438cw 24977,5usb 24978cw 28312,3usb 28328cw

----- Marine Mobile
14.300 14.303 14.313 14.122.5 14.323 14.297 14.316 14.300 7.241 7.085 14.118 14.315 21.400


----- 10m FM repeaters
The standard 10-meter repeater offset is down 100 kHz. Some repeaters may require a CTCSS or PL tone.
29.510 - 29.590 Repeater inputs, (10 kHz spacing)
29.610 - 29.690 Repeater outputs, (10 kHz spacing)


----- 2 m repeaters Shift TX = RX - 600Khz
TX 145.0000 - 145,1875 Mhz
RX 145,6000 - 145,7875 Mhz


----- 70cm repeaters Shift TX=RX - 7.6Mhz
TX 431,0500 - 431,8875
RX 438,6500 - 439,4875


--- 6m repeaters Shift TX=RX - 600 Khz
TX 51.210 - 51.390 MHz
RX 51.810 - 51.990 MHz


----- BEACONS
20 meters = 14.100 MHz, 17 meters = 18.110 MHz, 15 meters = 21.150 MHz, 12 meters = 24.930 MHz, 10 meters = 28.200 MHz.

The 10 second beacon transmit sequence moves westward from New York across North America, Asia, Pacific to Africa, Europe, and South America. On each frequency, each beacon transmits the following for ten seconds: its call sign (in Morse code at 22 wpm) and a one-second carrier at 100 watts followed by three additional one-second carriers at 10, 1, and 0.1 watts respectively. If band conditions are good, you will hear a number of beacons identifying in Morse and sending a series of four 1 second carriers each at a lower (-10dB) power level. The more beacons you hear, the more open the band is to different parts of the world. The 1st one second dash is at 100 watts, 2nd dash is 10 watts, 3rd dash is 1 watt and the 4th dash is 100 milliwatts.
The more dashes you hear per beacon, the better the quality of propagation and the more robust the band opening is. If you hear the 100 milliwatt carrier from many beacons, you know that band is wide open!


----- Broadcast bands
- 75m 3,9-4 Mhz
- 49m 5,95-6,2 Mhz
- 41m 7,1-7,3 Mhz
- 31m 9,5-9,775 Mhz
- 25m 11,7-11,975 Mhz
- 19m 15,1-11,45Mhz
- 16m 17,7-17,9 Mhz
- 13m 21,45-21,75 Mhz
- 11m 25,6-26,1 Mhz
