Amateur Satellites




This report is organized into five (5) parts.

Part 1 (S1) - operational analog amateur satellites

Part 2 (S2) - operational digital amateur satellites

Part 3 (S3) - non - operational satellites

Part 4 (S4) - proposed satellites

Part 5 (S5) - deborbited/returned satellites


SB SAT @ AMSAT W8ISS ANS-029.S1

WSR 029 Part 1 01/29/2009


AMSAT NEWS SERVICE BULLETIN 029.S1

FROM AMSAT HQ SILVER SPRING, MD, January 29, 2009

TO ALL RADIO AMATEURS

BID: $ANS-029.S1


DO-64 Delfi-C3

Catalog number: 32789

Launch Date: April 28, 2008


Status: OPERATIONAL

Current Mode: Science Mode - Beacon ONLY

Telemetry: 145.870 MHz


Downlink: 145.880 to 145.920 MHz

Uplink:   435.530 to 435.570 MHz


Proposed Frequencies:

Primary telemetry downlink: 145.870 MHz 1200 Baud BPSK AX.25 400mW

Backup telemetry downlink:  145.930 MHz 1200 Baud BPSK AX.25 400mW

Linear transponder passband downlink: 145.880 - 145.920 MHz(inverting)

Linear transponder passband uplink: 435.570 - 435.530 MHz

Transponder mode beacon: 145.870 MHz CW (10dB below transponder PEP)


Delfi-C3 web page: http://www.delfic3.nl/


IARU coordination status page:

http://www.amsat.org.uk/iaru/finished_detail.asp?serial=68

[01012009]

=====

VO-52 HAMSAT

Catalog number: 28650

Launch Date: May 05,2005


Status: Operational

Current Mode: U/v - Indian Transponder


Frequencies:

Indian Transponder:

Uplink:   435.220 to 435.280 MHz LSB/CW

Downlink: 145.930 to 145.870 MHz USB/CW


Dutch Transponder:

Uplink:   435.225 to 435.275 MHz LSB/CW

Downlink: 145.925 to 145.875 MHz USB/CW



Indian Beacon:  145.859330 MHZ CW

Dutch Beacon:   145.860 MHz 12WPM with CW message


Mode and Antenna Polarization:

V: LHCP

U: RHCP


Official Webpage: http://www.amsatindia.org/hamsat.htm


To know what transponder is switched on please listen for the beacon

that is active. Each transponder has a different beacon.

[08072008]

=====

AO-51 ECHO

Catalog number: 28375

Launch date: June 29, 2004


Status: Operational


Current Modes:   FM Repeater - L-FM/s-FM

V-SSTV/u-SSTV

BBS - OFF

Telemetry - OFF


Analog voice downlink:     435.300 MHz FM

435.150 MHz FM

2401.200 Mhz FM

Analog voice uplink:       145.880 MHZ FM

145.880 MHz USB

145.920 MHz FM

1268.700 MHz FM 67Hz PL tone

Digital Downlinks:        435.150 MHz FM 38k4 PBP, 1 watt output

435.150 MHz FM 9k6 Pacsat Broadcast Protocol

2401.200 MHz FM 38k4 bps, AX.25

Digital Uplink:           145.860 MHz FM 9k6 Pacsat Broadcast Protocol

1268.700 mhz FM 9k6 PBP Digital

Beacon:                   435.150 MHz


Mode and Antenna Polarization:

T: Linear

V: Linear

U: TX A (usually digital)LHCP

TX B (usually analog) RHCP

L: Linear

S: Linear


Broadcast: PECHO-11

BBS: PECHO-12


Official Webpage: http://www.amsat.org/amsat-new/echo/


IARU coordination status page:

http://www.amsat.org.uk/iaru/finished_detail.asp?serial=19

[01292009]

=====

SO-50 SAUDISAT-1C

Catalog number: 27607

Launch date: December 20, 2002


Status: Operational.


Current Mode: V/u


Uplink:   145.850 MHz FM - 67.0 Hz PL tone

Downlink: 436.795 MHz


Mode and Antenna Polarization:

V: Linear

U: Linear


Official Webpage: http://saudisat.kacst.edu.sa/index.shtml

(not up and running currently)


To switch the transmitter on, you need to send a CTCSS tone of 74.4

Hz. The order of operation is thus: (allow for Doppler as necessary):

1) Transmit on 145.850 MHz with a tone of 74.4 Hz to arm the 10 minute

timer on board the spacecraft.

2) Now transmit on 145.850 MHz (FM Voice) using 67.0 Hz to PT the re-

peater on and off within the 10 Minute window.

3) Sending the 74.4 tone again within the 10 minute window will reset

the 10 minute timer.

[05282007]

=====

FO-29 JAS-2

Catalog number: 24278

Launch Date: August 17, 1996


Status: Operational

Current Mode: V/u (Mode JA)


Voice/CW Mode JA

Uplink:   145.90 to 146.00 MHz CW/LSB

Downlink: 435.80 to 435.90 MHz CW/USB

Beacon:   435.795 MHz


Digital Mode JD

Uplinks:  145.850 MHz FM

145.870 MHz FM

145.910 MHz FM

Downlink: 435.910 MHz 1200-baud BPSK or 9600-baud FSK

Callsign: 8J1JCS

Digitalker: 435.910 MHz


Mode and Antenna Polarization:

V: RHCP

U: RHCP


For current operational schedule for FO-29:

http://www.ne.jp/asahi/m-arai/gkz/satinfo/fo29e.htm


JARL English webpage:

http://www.jarl.or.jp/English/5_Fuji/ejasmenu.htm


AMSAT-NA Webpage:

http://www.amsat.org/amsat-new/satellites/satInfo.php?satID

=5&retURL=/satellites/status.php


Mineo Wakita, JE9PEL, has created a simple decoder program for FO29's

CW telemetry downlink: http://www.ne.jp/asahi/hamradio/je9pel/fo29cwts

.htm

[01012009]

=====

AO-7 AMSAT OSCAR 7

Catalog number: 07530

Launch Date: November 15, 1974


Status: Operational


Current Mode: Alternating between Mode A and B every 24 hours


Uplink:   145.850 to 145.950 MHz CW/USB Mode A

432.125 to 432.175 MHz CW/LSB Mode B

Downlink:  29.400 to 29.500 MHz CW/USB Mode A (1W PEP)

145.975 to 145.925 MHz CW/USB Mode B (8W PEP)

145.975 to 145.925 MHz CW/USB Mode C (2W PEP)

Beacons:   29.502 MHz CW

145.972 MHz CW

435.100 MHz CW

2304.100 MHz CW


Official Webpage:

http://www.amsat.org/amsat-new/satellites/sat_summary/ao7.php


The AO-7 Logbook and Resource Website:

http://www.planetemily.com/ao7/


AO-7 Usage Guidelines on the AO-7 Log and Resource Site located at:

http://www.planetemily.com/ao7

[05282007]

=====

INTERNATIONAL SPACE STATION (ISS) - ARISS

Catalog number: 25544

Launch date: November 20, 1998


Status: Operational


Current Active Modes: FM Repeater - V/u

Voice -       V/v

BBS -         V/v

APRS -        V/v

SSTV -        V/v


Expedition 18 Crew:

Commander:                Mike Fincke      KE5AIT

Flight Engineer:          Yury Lonchakov   RA3DT

Flight Engineer:          Sandra Magnus    KE5FYE



Available Modes and Frequencies:


Digital/APRS:

Worldwide packet uplink:   145.825 MHz FM 9k6

Worldwide packet downlink: 145.825 Mhz FM 9k6


Voice:

Region 1 voice uplink:     145.200 MHz FM

Region 2/3 voice uplink:   144.490 MHz FM

Worldwide downlink:        145.800 MHz FM


Crossband Repeater:

Repeater Uplinks:         1269.650 MHz FM

437.800 MHz FM

145.990 MHz FM - 67.0 PL (Kenwood)

Repeater Downlink:         145.800 MHz FM

437.800 MHz FM (Kenwood)


SSTV Robot 36:

Downlink:                  145.800 MHz FM


Mode and Antenna Polarization:

V: Linear

U: Linear


Callsigns:

Belgian:                   OR4ISS

German:                    DP0ISS

Russian:                   RS0ISS

                          RZ3DZR

United States:             NA1SS

Packet Mailbox:            RS0ISS-11

Digipeater callsign:       ARISS


Official ARISS Webpage:    http://www.rac.ca/ariss

ISS Fan Club Webpage:      http://www.issfanclub.com

APRS tracking page:        http://www.ariss.net/


ISS Daily Crew Schedule: http://spaceflight.nasa.gov/station/timelines

Remember that the crew operates on UTC time. Also, all of the time

line is NOT translated from Russian and posted.

[01082009]

NNNN

/EX


SB SAT @ AMSAT W8ISS ANS-029.S2

WSR 029 Part 2 01/29/2009


AMSAT NEWS SERVICE BULLETIN 029.S2

FROM AMSAT HQ SILVER SPRING, MD, January 29, 2009

TO ALL RADIO AMATEURS

BID: $ANS-029.S2


RS-30 Radio Sputnik 30 (Yubileiny)

Catalog Number:

Launch Date: May 23, 2008


Status: Operational


Curent Mode: Telemetry

Audio

Images


Downlinks: 435.315 MHz

435.215 MHz

[05292008]

=====

CAPE-1

Catalog Number: 31130

Launch Date: April 17,2007


Status: Intermittent


Current Mode:  /u


TLM Downlink: 435.245 MHz 9600 bs FSK AX.25

CW Beacon:    435.245 MHz CW


Callsign: K5USL


TLM and CW interchange every 30 seconds.

[11152007]

=====

CP3

Catalog Number: 31128

Launch Date: April 17,2007


Status: Operational


Current Mode:  /u


Downlink: 436.845 MHz 1200 bps AFSK AX.25

[07302007]

=====

GENESAT-1 ?O-??

Catalog Number: 29655

Launch Date: December 16, 2006


Status: Operational


Current Mode: /u


Telemetry Beacon Downlink: 437.0670 MHz AFSK 1200 BPS


Official webpage: http://www.crestnrp.org/genesat1/ahc.html

[01082007]

=====

CO-58 CubeSat XI-V

Catalog number: 28895

Launch Date: October 27, 2005


Status: Operational - CW Beacon only


Current Mode: /u


Telemetry Downlink: 437.4250 MHz AFSK 1200bps using AFK protocol

Beacon:             437.2750 MHz CW


Callsign: JQ1YGW


Official Webpage: http://www.space.t.u-tokyo.ac.jp/cubesat/mission/V/


Pictures received by Mineo Wakita - JE9PEL:

http://www.ne.jp/asahi/hamradio/je9pel/

[03262007]

=====

CO-57 CubeSat XI-IV

Catalog number: 27848

Launch date: June 30, 2003


Status: Operational


Current Mode: /u


Beacon:     436.8475 MHz CW

Telemetry : 437.4900 MHz AFSK 1200 BPS


Callsign: JQ1YGW


Official Webpage: http://www.space.t.u-tokyo.ac.jp/cubesat/mission/V/

[01082007]

=====

CO-56 CUTE-1.7 + APD

Catalog number: 28941

Launch date: February 21, 2006


Status: Operational?


Uplink:  1268.5000 MHz GMSK 9600 BPS

Downlink: 437.4700 MHz 1200 FM ax25 or SRLL (ACTIVE only near Japan?)


Telemetry Beacon: 437.3850 CW

Callsign: JQ1YPC


Information webpage:

http://lss.mes.titech.ac.jp/ssp/spacerium/cute1blog/

[12182008]

=====

CO-55 CUTE-1

Catalog Number: 27844

Launch date: June 30, 2003


Status: Operational


Current Mode: CW downlink worldwide

AX25 Packet with uplink command over Japan only


Mode U Telemetry

Downlink: 437.4000 MHz AFSK 1200 BPS


Mode U TLM Beacon

Downlink: 436.8375 MHz CW

[08132007]

=====

AO-51 ECHO

Catalog number: 28375

Launch date: June 29, 2004


Status: Operational


Current Modes:   FM Repeater - L-FM/s-FM

V-SSTV/u-SSTV

BBS         - OFF

Telemetry   - OFF


Analog voice downlink:     435.300 MHz FM

435.150 MHz FM

2401.200 Mhz FM

Analog voice uplink:       145.880 MHZ FM

145.880 MHz USB

145.920 MHz FM

1268.700 MHz FM 67Hz PL tone

Digital Downlinks:        435.150 MHz FM 38k4 PBP, 1 watt output

435.150 MHz FM 9k6 Pacsat Broadcast Protocol

2401.200 MHz FM 38k4 bps, AX.25

Digital Uplink:           145.860 MHz FM 9k6 Pacsat Broadcast Protocol

1268.700 mhz FM 9k6 PBP Digital

Beacon:                   435.150 MHz


Mode and Antenna Polarization:

T: Linear

V: Linear

U: TX A (usually digital)LHCP

TX B (usually analog) RHCP

L: Linear

S: Linear


Broadcast: PECHO-11

BBS: PECHO-12


Official Webpage: http://www.amsat.org/amsat-new/echo/


IARU coordination status page:

http://www.amsat.org.uk/iaru/finished_detail.asp?serial=19

[01292009]

=====

NO-44 PCSAT

Catalog number: 26931

Launch Date: September 30, 2001


Status: Semi-operational


Current Mode: V/v


General Usage Uplink/Downlink: 145.827 MHz 1200 Baud

Special Usage Downlink:        144.390 Mhz 1200 Baud


PCSAT APRS page: http://pcsat.aprs.org


aprstlm Telemetry Decoder program:

http://www.xciv.org/~iain/aprstlm/v1.2/

[09242007]

=====

GO-32 Gurwin TechSat-1B

Catalog number: 25397

Launch Date: July 10, 1998


Status: Non-Operational


Current Modes: V/U

L/U


Downlink: 435.225 MHz FM (9600-baud FSK)

435.325 Mhz - Not Available - temperature problems

Uplinks:  145.850 FM

145.890 FM

145.930 FM

1269.700 FM

1269.800 FM

1269.900 FM


Broadcast Callsign: 4XTECH-11

BBS Callsign: 4XTECH-12


More information of GO-32 can be found at:

http://www.iarc.org/techsat/techsat.html

[12042007]

=====

RS-22 RADIO SPORT RS-22

Catalog number: 27939

Launch Date: September 27, 2003


Status: Operational - 70cm cw only


Current Mode:  /u


CW Beacon - 435.352 MHz

145.818 MHz

[08062007]

=====

Can X-2

Catalog number:

Launch Date: April 28, 2008


Status: IN ORBIT


Downlink: 437.478 MHz GFSK


For the latest project status update please visit the Can X-2 web

page: http://www.utias-sfl.net/nanosatellites/CanX2/


IARU coordination status page:

http://www.amsat.org.uk/iaru/finished_detail.asp?serial=46

[05292008]

=====

AAUSAT-II

Catalog number: 32788

Launch Date: April 28, 2008


Status: IN ORBIT


Downlink: 437.425 MHz


For the latest project status update please visit the AAUSAT-II web

page:

http://www.aausatii.aau.dk/homepage/index.php?language=en&page=home


IARU coordination status page:

http://www.amsat.org.uk/iaru/finished_detail.asp?serial=60

[05292008]

=====

CO-65 Cute-1.7+APD II

Catalog number: 32785

Launch Date: April 28, 2008


Status: IN ORBIT


Downlink:  437.475 MHz 9k6 Packet

Uplink:   1267.600 Mhz


For the latest project status update please visit the Cute-1.7+APD II

web page: http://lss.mes.titech.ac.jp/ssp/cute1.7/index_e.html


IARU coordination status page:

http://www.amsat.org.uk/iaru/finished_detail.asp?serial=78

[07312008]

=====

Compass-1

Catalog number: 32787

Launch Date: April 28, 2008


Status: IN ORBIT


Downlink: 437.275 Mhz CW

437.405 MHz Packet


For the latest project status update please visit the Compass 1 web

page: http://www.raumfahrt.fh-aachen.de/


IARU coordination status page:

http://www.amsat.org.uk/iaru/finished_detail.asp?serial=52

[05292008]

=====

CO-66 Seeds II

Catalog number:

Launch Date: April 28, 2008


Status: Operational


Downlink: 437.485 MHz


For the latest project status update please visit the Seeds 2 web

page: http://cubesat.aero.cst.nihon-u.ac.jp/english/main_e.html


IARU coordination status page:

http://www.amsat.org.uk/iaru/finished_detail.asp?serial=36

[12042008]

=====

INTERNATIONAL SPACE STATION (ISS) - ARISS

Catalog number: 25544

Launch date: November 20, 1998


Status: Operational


Current Active Modes: FM Repeater - V/u

Voice -       V/v

BBS -         V/v

APRS -        V/v

SSTV -        V/v


Expedition 18 Crew:

Commander:                Mike Fincke      KE5AIT

Flight Engineer:          Yury Lonchakov   RA3DT

Flight Engineer:          Sandra Magnus    KE5FYE



Available Modes and Frequencies:


Digital/APRS:

Worldwide packet uplink:   145.825 MHz FM 9k6

Worldwide packet downlink: 145.825 Mhz FM 9k6


Voice:

Region 1 voice uplink:     145.200 MHz FM

Region 2/3 voice uplink:   144.490 MHz FM

Worldwide downlink:        145.800 MHz FM


Crossband Repeater:

Repeater Uplinks:         1269.650 MHz FM

437.800 MHz FM

145.990 MHz FM - 67.0 PL (Kenwood)

Repeater Downlink:         145.800 MHz FM

437.800 MHz FM (Kenwood)


SSTV Robot 36:

Downlink:                  145.800 MHz FM


Mode and Antenna Polarization:

V: Linear

U: Linear


Callsigns:

Belgian:                   OR4ISS

German:                    DP0ISS

Russian:                   RS0ISS

                          RZ3DZR

United States:             NA1SS

Packet Mailbox:            RS0ISS-11

Digipeater callsign:       ARISS


Official ARISS Webpage:    http://www.rac.ca/ariss

ISS Fan Club Webpage:      http://www.issfanclub.com

APRS tracking page:        http://www.ariss.net/


ISS Daily Crew Schedule: http://spaceflight.nasa.gov/station/timelines

Remember that the crew operates on UTC time. Also, all of the time

line is NOT translated from Russian and posted.

[01082009]

NNNN

/EX


SB SAT @ AMSAT W8ISS ANS-029.S3

WSR 029 Part 3 01/29/2009


AMSAT NEWS SERVICE BULLETIN 029.S3

FROM AMSAT HQ SILVER SPRING, MD, January 29, 2009

TO ALL RADIO AMATEURS

BID: $ANS-029.S3


THE FOLLOWING ARE IN ORBIT BUT ARE NON-OPERATIONAL AT THIS TIME:


CP4

Catalog Number: 31122

Launch Date: April 17,2007


Status: Non-Operational


Current Mode: /u


TLM Downlink: 437.325 MHz 1200 bps FSK AX.25

CW Beacon:    437.325 MHz CW


IARU coordination status page:

http://www.amsat.org.uk/iaru/finished_detail.asp?serial=79

[10022008]

=====

PO-63 PEHUENSAT-1

Catalog Number: 29712

Launch Date: January 10, 2007


Status: Non-Operational


Current Mode: V/v


Uplink/Downlink: 145.825 Mhz FM

Voice Recorder:  145.825 Mhz FM

[01012009]

=====

NCUBE-2

Catalog number: 28897

Launch Date: October 27, 2005


Status: Still attached to XO-53 (SSETI)?


Proposed Callsign: TBA

Proposed Transmit Frequency:  437.305

2407.250


Official Website: http://www.ncube.no

[05012006]

=====

XO-53 SSETI

Catalog number: 28894

Launch Date: October 27, 2005


Status: Non-operational


Voice Uplink:        437.250 MHz FM 67Hz CTCSS

Voice Downlink:     2401.835 MHz FM

Packet Up/Downlink:  437.250 MHz 9k6 packet

Packet Downlink     2401.835 MHz 38k4 packet


Official webpage: http://sseti.gte.tuwien.ac.at/WSW4/

Latest news: http://sseti.gte.tuwien.ac.at/WSW4/MOPWS/news.php

[01222007]

=====

UWE-1

Catalog Number: 28892

Launch Date: October 27, 2005


Status: Non=Operational


Mode U Telemetry

Downlink: 437.5050 MHz 9600 AFSK

[08132007]

=====

AO-49 AATiS OSCAR-49 (SAFIR-M)

Catalog number: 27605

Launch Date: December 20, 2002


Status: Non-operational.


Uplink:   435.275 MHz 1200-baud AFSK

Downlink: 145.825 MHz 9600-baud FSK

(optional voice message)

Broadcast callsign: DP0AIS


Official webpage: http://amend.gmxhome.de

[01222007]

=====

MO-46 TIUNGSAT-1

Catalog number: 26548

Launch date: September 26, 2000


Status: Non-Operational


Uplinks:   145.850 MHz

145.925 MHz 9600-baud FSK

Downlink:  437.325 MHz


Broadcast callsign: MYSAT3-11

BBS:                MYSAT3-12


TiungSat-1 is Malaysia's first micro-satellite and in addition to

commercial land and weather imaging payloads offers FM and FSK

Amateur Radio communication.


TiungSat-1, named after the mynah bird of Malaysia, was developed as

a collaborative effort between the Malaysian government and Surrey

Satellite Technology Ltd.

[007302007]

=====

NO-45 SAPPHIRE

Catalog number: 26932

Launch Date: September 30, 2001


Status: Non-Operational


Downlink: 437.095 MHz 1200 baud AX-25 AFSK

Uplink:   145.945 MHz UI Digipeater

Digi Callsign: KE6QMD


Everyone is welcome to use the digipeating/APRS features of Sapphire,

as per the user service agreement located at the following URL:

http://web.usna.navy.mil/~bruninga/pcsat/contract.txt

[03132005]

=====

SO-42 SAUDISAT-1B

Catalog number: 26549

Launch date: September 26, 2000


Status: Non-Operational


Downlink: 437.075 MHz


Broadcast Callsign: SASAT2-11

BBS:                SASAT2-12


Further information is available at:

http://www.amsat.org/amsat/sats/n7hpr/so42.html

[01222007]

=====

SO-41 SAUDISAT-1A

Catalog number: 26545

Launch Date: September 26, 2000


Status: Non-Operational


Uplink:   145.850 MHz

Downlink: 436.775 MHz


Broadcast Callsign: SASAT1-11

BBS:                SASAT1-12


Further information is available at:

http://www.amsat.org/amsat/sats/n7hpr/so41.html

[01222007]

=====

AO-40 AMSAT OSCAR 40

Catalog number: 26609

Launch Date: November 16, 2000


Status: Non-Operational


Uplinks

-------

V-band:   145.840 -  145.990 MHz CW/LSB

U-band:   435.550 -  435.800 MHz CW/LSB

L1-band: 1269.250 - 1269.500 MHz CW/LSB

L2-band: 1268.325 - 1268.575 MHz CW/LSB


Downlinks

---------

S2-band:  2401.225 -  2401.475 MHz CW/USB

K-band:  24048.010 - 24048.060 MHz CW/USB

Beacon:   2401.323 MHz

24048.035 MHz


P3-D Telemetry Beacons (IHU)

----------------------------

BEACON General Beacon(GB)  Middle Beacon(MB)  Engineering Beacon(EB)

2 m                   none        145.898 MHz                    none

70cm           435.438 MHz        435.588 MHz             435.838 MHz

13cm(1)       2400.188 MHz       2400.338 MHz            2400.588 MHz

13cm(2)       2401.173 MHz       2401.323 MHz            2401.573 MHz

3cm          10450.975 MHz      10451.125 MHz           10451.375 MHz

1.5cm        24047.885 MHz      24048.035 MHz           24048.285 MHz

[07162007]

=====

OO-38 OPAL

Catalog Number: 26063

Launch Date: January 27, 2000


Status: Non-Operational


Mode U TLM Beacon

Downlink: 437.1000 MHz 9600 FSK

[08132007]

=====

UO-36 UoSAT-12

Catalog number: 25693

Launch date: April 21, 1999


Status: Unknown


Uplink:    145.960 MHz (9600-baud FSK)

Downlinks: 437.025 MHz

437.400 MHz


Broadcast Callsign: UO121-11

BBS: UO121-12


The VK5HI viewer shareware for UO-36 is available on the AMSAT-NA web

site at the following URL:

ftp://ftp.amsat.org/amsat/software/win32/display/ccddsp97-119.zip

[01222007]

=====

SO-35 SUNSAT

Catalog Number: ?

Launch date:February 23, 1999


Status: Non-Operational


Downlink: Mode B Repeater: 436.291 MHz

Mode J Digipeater:         436.250 MHz


Uplinks: Mode B Repeater:  145.825 MHz

Mode J Digipeater:         145.825 MHz

                          145.900 MHz


For more information of SUNSAT vist the satellite web site:

http://esl.ee.sun.ac.za/projects/sunsat/

[01222007]

=====

PO-34 PANSAT

Catalog number: 25520

Launch date: October 30, 1998


Status: Telemetry downloads only


Uplink/downlink: 436.500 MHz


Official Webpage: http://www.sp.nps.navy.mil/pansat/

[05092004]

=====

SO-33 SEDSAT-1

Catalog number: 25509

Launch date: October 24, 1998


Status: Semi-operational


Downlink: 437.910 MHz FM (9600-baud FSK)


The satellite is not currently available for uplink transmissions and

the image and transponder recovery efforts have been unsuccessful.


For more information on SedSat-1 visit the satellite web site:

http://seds.uah.edu/projects/sedsat/sedsat.htm

[09042006]

=====

TO-31 TMSAT-1

Catalog number: 25396

Launch Date: July 10, 1998


Status: Non-operational


Uplink:   145.925 MHz 9600 baud FSK

Downlink: 436.925 MHz 9600 baud FSK


Broadcast callsign: TMSAT1-11

BBS: TMSAT1-12

[05012006]

=====

PO-28 POSAT-1

Catalog number: 22829

Launch Date: September 25, 1993


Status: Non-operational


Downlink: 429.950

Uplink: Not until handover back to Amatuer usage


Broadcast callsign: POSAT1-11

BBS callsign:       POSAT1-12


AMSAT Webpage: http://www.amsat.org/amsat/sats/n7hpr/po28.html

POSAT-1 webpage:

http://www.ee.surrey.ac.uk/SSC/CSER/UOSAT/missions/posat1.html

[01012009]

=====

AO-27 AMRAD

Catalog number: 22825

Launch date: September 26, 1993


Status: Non-operational


Current Mode: V/u


Uplink:   145.850 MHz FM

Downlink: 436.797 MHz FM


Mode and Antenna Polarization:

V: Linear

U: Linear


Official Webpage: http://www.ao27.org

[01292009]

=====

IO-26 ITAMSAT

Catalog number: 22826

Launch Date: September 26, 1993


Status: PSK carrier only


Current Mode:


Uplinks:  145.875 MHz FM 1200-baud

145.900 MHz FM 1200-baud

145.925 MHz FM 1200-baud

145.950 MHz FM 1200-baud


Downlink: 435.808 MHz PSK


Broadcast Callsign: ITMSAT-11

BBS: ITMSAT-12


Official webpage: http://www.itamsat.org

AMSAT Webpage: http://www.amsat.org/amsat/sats/n7hpr/io26.html

[01212007]

=====

KO-25 KITSAT

Catalog number: 22828

Launch date: September 26, 1993


Status: Non-operational


Uplink:   145.980 MHz FM 9600-baud FSK

Downlink: 436.500 MHz FM


Broadcast Callsign: HL02-11

BBS: HL02-12

[05092004]

=====

KO-23 KITSAT

Catalog number: 22077

Launch date: August 10, 1992


Status: Non-operational


Uplink:   145.900 MHz FM (9600-baud FSK)

Downlink: 435.170 MHz FM


Broadcast Callsign: HLO1-11

BBS: HLO1-12

[01222007]

=====

UO-22 UOSAT

Catalog number: 21575

Launch date: July 17, 1991


Status: Non-Operational


Uplink:   145.900 FM 9600-baud FSK

Downlink: 435.120 MHz FM


Broadcast Callsign: UOSAT5-11

BBS: UOSAT5-12

[01222007]

=====

AO-21 AMSAT-OSCAR 21

Catalog Number: 21087

Launch Date: January 29, 1991


Status: Non-Operational


Uplink:   435.041 MHz FM DSP

Downlink: 145.983 MHz FM DSP

[01222007]

=====

FO-20 JAS-1b

Catalog number: 20480

Launch Date: February 07, 1990


Status: Non-Operational


Beacons:   435.795 MHz CW

435.910 MHz AX25


Voice Transponder:

Uplink:   145.900 to 146.000 MHz CW/LSB

Downlink: 435.800 to 435.900 MHz CW/USB


Digital Transponder:

Uplinks:  145.850 MHz

145.870 MHz

145.890 MHz

145.910 MHz

Downlink: 435.910 MHz


More FO-20 info can be found at:

http://www.amsat.org/amsat/sats/n7hpr/fo20.html

[01152007]

=====

LIBERTAD-1

Catalog Number: 31129

Launch Date: April 17,2007


Status: Non-Operational


Current Mode: V/u APRS Packet ax25


Callsign: 5K3L


Uplink:   145.825 MHz 1200 AFSK ax25 APRS

Downlink: 437.399 MHz 1200 AFSK ax25 APRS


Telemetry Beacon: 437.4050 MHz 1200 AFSK ax25

[10222007]

=====

LO-19 LUSAT

Catalog number: 20442

Launch date: January 22, 1990


Status: CW Beacon only


Uplinks:          145.840 MHz 1200-baud Manchester FSK

145.860 MHz 1200-baud Manchester FSK

145.880 MHz 1200-baud Manchester FSK

145.900 MHz 1200-baud Manchester FSK


CW downlink:      437.125 MHz


Digital downlink: 437.150 MHz SSB (RC-BPSK 1200-baud PSK)


Broadcast Callsign: LUSAT-11

BBS: LUSAT-12o


General information and telemetry samples can be found at:

www.telecable.es/personales/ea1bcu

[01222007]

=====

WO-18 WEBERSAT

Catalog Number: 20441

Launch Date: January 22, 1990


Status: Non-Operational


Downlink: 437.104 MHz SSB 1200 Baud PSK AX.25

[05012006]

=====

DO-17 Dove

Catalog Number: 20440

Launch Date: January 22, 1990


Status: Non-operational.


Downlink:  145.825 MHz FM 1200 Baud AFSK

Beacon:   2401.220 MHz

[05012006]

=====

AO-16 PACSAT

Catalog number: 20439

Launch Date: January 22, 1990


Status: SEMI-Operational


Current Mode:  V/u


Uplink:         145.900 MHz FM 1200-baud Manchester FSK (reserved)

145.920 MHz FM VOICE

145.940 MHz FM 1200-baud Manchester FSK (reserved)

145.960 MHz FM 1200-baud Manchester FSK (reserved)


Downlink:       437.026 MHz USB VOICE

(1200-baud PSK - MBL Telemetry Only)


Mode-S Beacon: 2401.1428 MHz [NO FUTURE OPERATIONS PLANNED]


Mode and Antenna Polarization:

U: RC  437.050 MHz RHCP

PSK 437.026 MHz LHCP

V: Linear


Broadcast Callsign: PACSAT-11

BBS:                PACSAT-12


AO-16 AMSAT Webpage: http://www.amsat.org/amsat/sats/n7hpr/ao16.html

[12252008]

=====

UO-14 UoSAT-3

Catalog number: 20437

Launch date: January 22, 1990


Status: Non-operational


Uplink:   145.975 MHz FM

Downlink: 435.070 MHz FM

[05092004]

=====

FO-12 Fuji-OSCAR 12

Catalog Number: 16909

Launch Date: August 12, 1986


Status: Non-Operational


Mode V/U (J) Linear Transponder (Inverting):

Uplink: 145.9000 - 146.0000 MHz SSB/CW

Downlink 435.8000 - 435.9000 MHz SSB/CW


Mode V/U (J) Packet:

Uplink: 145.8500 MHz MFSK 1200 BPS

Uplink: 145.8700 MHz MFSK 1200 BPS

Uplink: 145.8900 MHz MFSK 1200 BPS

Uplink: 145.9100 MHz MFSK 1200 BPS


Downlink 435.9100 MHz PSK 1200 BPS


Telemetry Beacon: 435.7950 MHz SSB/CW

[01152007]

=====

UO-11 OSCAR-11

Catalog number: 14781

Launch Date: March 1, 1984


Status: Non-operational.


Current Mode:  /v


Telemetry Downlink: 145.825 MHz FM 1200 AFSK

UHFBeacon:          435.025 MHz

Mode-S Beacon:     2401.500 MHz


Mode and Antenna Polarization:

V: RHCP

S: LHCP


Webpage: http://www.users.zetnet.co.uk/clivew/

MPEG3 files: http://www.ne.jp/asahi/hamradio/je9pel/uo11tlme.htm

[01012009]

=====

AO-10 OSCAR 10

Catalog number: 14129

Launch Date: June 16, 1983


Status: Non-operational


Uplink:   435.030 to 435.180 MHz CW/LSB

Downlink: 145.975 to 145.825 MHz CW/USB


Beacon:   145.810 MHz (unmodulated carrier)


W4SM has more information about the satellite at the following URL:

http://www.cstone.net/~w4sm/AO-10.html

[05092004]

=====

AO-8 AMSAT-OSCAR 8

Catalog Number: 10703

Launch Date: March 3, 1978


Status: Non-Operational


Mode V/U (J) Linear Transponder (Non-Inverting): Non-Operational

Uplink: 145.9000 - 146.0000 MHz SSB/CW

Downlink 435.1990 - 435.2000 MHz SSB/CW


Mode V/U (J) TLM Beacon: Non-Operational

Downlink 435.0950 MHz CW


Mode V/A (A) Linear Transponder (Non-Inverting): Non-Operational

Uplink: 145.8500 - 145.9000 MHz SSB/CW

Downlink 29.4000 -  29.5000 MHz SSB/CW


Mode V/A (A) TLM Beacon: Non-Operational

Downlink 29.4020 MHz CW

[01152007]

=====

AO-6 AMSAT-OSCAR 6

Catalog Number: 06236

Launch Date: October 15, 1972


Status: Non-Operational


Uplink:   145.9000 - 146.0000 MHz SSB/CW

Downlink:  29.4500 -  29.5500 MHz SSB/CW

Beacons:   29.450 MHz

435.100 MHz

[01312008]

=====

AO-5 Australis-OSCAR 5

Catalog Number: 04321

Launch Date: January 23, 1970


Status: Non-Operational


Telemetry Beacons: 144.0500 MHz CW

29.4500 MHz CW

[01152007]

=====

OSCAR III

Catalog Number: 01293

Launch Date: March 09, 1965


Status: Non-Operational


Uplink:   145.9750 - 146.0250 MHz SSB/CW

Downlink: 144.3250 - 144.3750 MHz SSB/CW

[01012007]

=====

RS-15 RADIO SPORT RS-15

Catalog number: 23439

Launch Date: December 26, 1994


Status: Non-operational


Uplink:   145.858 to 145.898 MHz CW/USB

Downlink:  29.354 to  29.394 MHz CW/USB


Beacon 1:  29.352 MHz (intermittent)

Beacon 2:  29.398 MHz


SSB meeting frequency: 29.380 MHz (unofficial)

[06202004]

=====

RS-13 RADIO SPORT RS-13

Catalog number: 21089

Launch date: February 5, 1991


Status: Non-operational


Uplink:     21.260 to 21.300 MHz CW/USB

Downlink:  145.860 to 145.900 MHz CW/USB


Beacon:    145.860 MHz


Robot:     145.908 MHz

[05232004]

=====

RS-12 RADIO SPORT RS-12

Catalog number: 21089

Launch date: February 5, 1991


Status: Non-operational


Uplink:   21.210 to 21.250 MHz CW/USB

Downlink: 29.410 to 29.450 MHz CW/USB


Beacon:   29.408 MHz


Robot:    29.454 MHz

[05232004]

NNNN

/EX


SB SAT @ AMSAT W8ISS ANS-029.S4

WSR 029 Part 4 01/29/2009


AMSAT NEWS SERVICE BULLETIN 029.S4

FROM AMSAT HQ SILVER SPRING, MD, January 29, 2009

TO ALL RADIO AMATEURS

BID: $ANS-029.S4


THE FOLLOWING SATELLITES ARE NOT IN ORBIT BUT ARE PROPOSED FOR LAUNCH

AT THIS TIME:


KAGAYAKI (Solan Co.)

Catalog Number:

Proposed Launch Date: January 21, 2009


Status: Launch Phase


Reported Frequncy and Modes:

Downlink: 437.375 MHZ    FSK9k6/CW

Beacon:   437.375 MHz    FSK9k6/CW


IARU coordination status page:


[01152009]

=====

STARS (Kagawa Univ.)

Catalog Number:

Proposed Launch Date: January 21, 2009


Status: Launch Phase


Reported Frequncy and Modes:

Downlinks: 437.485 MHz FM/CW

437.465 MHz FM/CW

Beacons:   437.305 MHz FM/CW

437.275 MHz FM/CW


Callsigns: JR5YBN

JR5YBO


IARU coordination status page:

http://www.amsat.org.uk/iaru/finished_detail.asp?serial=99

[01152009]

=====

KKS-1 (Tokyo MCIT)

Catalog Number:

Proposed Launch Date: January 21, 2009


Status: Launch Phase


Proposed Frequencies and Modes:

Downlink:  437.455 MHz AFSK/CW

Beacon:    437.385 MHz AFSK/CW


Callsign: JQ1YYY


IARU coordination status page:

http://www.amsat.org.uk/iaru/finished_detail.asp?serial=107

[01152009]

=====

PRISM (Tokyo Univ.)

Catalog Number:

Proposed Launch Date: January 21, 2009


Status: Launch Phase


Proposed Frequencies and Modes:

Downlink: 437.425 MHz AFSK/GMSK/CW

Beacon:   437.250 MHz AFSK/GMSK/CW


Callsign: JQ1YCX


IARU coordination status page:

http://www.amsat.org.uk/iaru/finished_detail.asp?serial=97

[01152009]

=====

SOHLA-1 (ASTRO TECH.)

Catalog Number:

Proposed Launch Date: January 21,2009


Status: Launch Phase


Proposed Frequencies and Modes:

Downlink: 437.505 MHz AFSK/CW

Beacon:   437.505 MHz AFSK/CW


Callsign:


IARU coordination status page:

http://www.amsat.org.uk/iaru/formal_detail.asp?serial=101

[01152009]

=====

UNITEC

Catalog Number:

Proposed Launch Date: May 2010


Status: Design Phase


Proposed Equipment:


IARU coordination status page:

http://www.amsat.org.uk/iaru/formal_detail.asp?serial=141

[01152009]

=====

XW-1

Catalog Number:

Proposed Launch Date: Summer 2009?


Status: Design Phase


Proposed Equipment:

Beacon: 435Mhz, CW 20dBm

Linear transponder: RX: 145Mhz, TX: 435Mhz, 40KHz, 30dBm

FM Transponder: RX: 145Mhz, TX: 435Mhz, 16KHz, 30dBm

Digital store and forward transponder: RX: 145Mhz, TX: 435Mhz, 16KHz,

30dBm


IARU coordination status page:

http://www.amsat.org.uk/iaru/formal_detail.asp?serial=108

[10092008]

=====

Phase 5a Mars Mission AO-??

Catalog Number:

Proposed Launch Date: 2009 or 2011


Status: Design Phase


For the latest project status update please visit the AMSAT-DL P5-A

web page:

http://ticket-to-mars.org

[01222007]

=====

PHASE 3E AO-??

Catalog number:

Proposed Launch Date: Late 2008


Status: Under Construction


For the latest project status update please visit the AMSAT-DL P3-E

web page:

http://www.amsat-dl.org/p3e/

[01222007]

=====

Eagle AO-??

Catalog Number:

Proposed Launch Date: Early/Mid 2009


Status: Design Phase


For the latest project status updates please visit the AMSAT-NA web

page: http://www.amsat.org

[01222007]

NNNN

/EX


SB SAT @ AMSAT W8ISS ANS-029.S5

WSR 029 Part 5 01/29/2009


AMSAT NEWS SERVICE BULLETIN 029.S5

FROM AMSAT HQ SILVER SPRING, MD, January 29, 2009

TO ALL RADIO AMATEURS

BID: $ANS-029.S5


THE FOLLOWING SATELLITES HAVE RE-ENTERED OR HAVE BEEN RETURNED SAFELY:


NO-62 FCAL

Catalog Number: 29667

Launch Date: December 21, 2006


Status: Re-Entered

Re-entered: July 28, 2008


Downlink: 437.385 Mhz APRS AX25


Downlink ID: KD4HBO


Website: http://eng.usna.navy.mil/~bruninga/fcal.html

[01012009]

=====

NO-61 ANDE

Catalog Number: 29664

Launch Date: December 21, 2006


Status: Re-Entered

Re-entered: December 25, 2007


Uplink/Downlink: 145.825 Mhz FM APRS AX25

[01032008]

=====

NO-60 RAFT-1

Catalog Number: 29661

Launch Date: December 21, 2006


Status: Re-Entered

Re-entered: May 30, 2007


Main Downlink:      145.825 Mhz FM APRS AX25

APRS Uplink:        145.825 MHz FM APRS AX25

Voice/PSK31 Uplink:  28.120 MHz


Packet to Voice ID: RAFT

[06112007]

=====

HO-59 HITSat

Catalog number: 29484

Launch date: September 22, 2006


Status: Re-Entered

Re-entered: June 18, 2008


Telemetry Downlink: 437.4250 MHz AFSK 1200 BPS

Beacon:             437.2750 MHz CW


Callsign: JR8YJT

[01012009]

NNNN

/EX


ANS is released worldwide via the AMSAT ANS e-mail reflector and a live

radiocast on the AMSAT-NA 20-meter net held each Sunday on 14.282 MHz.

Pre-net operations start at 18:00 UTC, with current ANS bulletins trans-

mitted to the eastern U.S. at 19:00 UTC and to the western U.S. at 19:30

UTC.


Information on AMSAT-NA is available at the following URL:

http://www.amsat.org


Mailing address:

AMSAT-NA

850 Sligo Avenue, Suite 600

Silver Spring, Maryland 20910-4703


Voice: 301-589-6062

888-322-6728

FAX:   301-608-3410


Currently, AMSAT-NA supports the following (free) mailing lists:


* AMSAT News Service (ANS)

* General satellite discussion (AMSAT-BB)

* Orbit data (KEPS)

* Manned space missions (SAREX)

* District of Columbia area (AMSAT-DC)

* New England area (AMSAT-NE)

* AMSAT Educational Liaison mailing list (AMSAT-EDU)

* AMSAT K-12 Educational Liaison mailing list (AMSAT-K12)


A daily digest version is available for each list.


To subscribe, or for more list information, visit the following URL:

http://www.amsat.org/mailman/listinfo/ans


In addition to regular membership, AMSAT-NA offers membership in the

President's Club. Members of the President's Club, as sustaining

donors to AMSAT Project Funds, will be eligible to receive additional

benefits. Application forms are available from the AMSAT-NA Office.


This week's Weekly Satellite Report Editor is James French, W8ISS.


ANS is always dedicated to past ANS editor 'BJ' Arts, WT0N, and to

the memory of longtime AMSAT supporters Werner Haas, DJ5KQ, Dennis

Kitchen, G0FCL and John Branegan GM4IHJ.


Please send any amateur satellite news or reports to: ans-editor{at}

amsat.org

NNNN

/EX

Ham Radio operators have been designing, building, and launching satellites for decades. This picture is AO-40 (phase3d) which had a failure after launch. Amsat members are currently working on more satellites to launch to keep satellites operators going for more decades. Here is some satellite information to help you out.
