ELEMENT LENGTH (in.) SPAC. TO REF. (in.) ELE. DIA. (in.) Reflector 13.6875 0 0.25000 Driven 12.9063 5.1250 0.25000 Director 1 12.1563 10.2500 0.25000
420.000 8.92 16.23 16.89+j5.8 14.68 420.682 8.96 15.72 16.61+j7.2 14.22 421.364 9.00 15.21 16.34+j8.61 13.75 422.046 9.03 14.72 16.06+j10.06 13.27 422.728 9.07 14.24 15.79+j11.52 12.78 423.410 9.10 13.77 15.52+j13.01 12.28 424.092 9.14 13.31 15.25+j14.52 11.77 424.774 9.17 12.87 14.99+j16.05 11.25 425.456 9.20 12.43 14.73+j17.61 10.72 426.138 9.23 12.01 14.48+j19.19 10.18 426.820 9.26 11.60 14.24+j20.79 9.64 427.502 9.28 11.21 14.01+j22.42 9.09 428.184 9.31 10.82 13.78+j24.07 8.54 428.866 9.32 10.44 13.57+j25.74 7.99 429.548 9.34 10.07 13.37+j27.43 7.44 430.230 9.35 9.71 13.18+j29.15 6.89 430.912 9.36 9.36 13.00+j30.88 6.34 431.594 9.36 9.02 12.84+j32.64 5.81 432.276 9.35 8.68 12.69+j34.42 5.28 432.958 9.34 8.35 12.56+j36.22 4.77 433.640 9.33 8.03 12.44+j38.04 4.28 434.322 9.31 7.72 12.35+j39.89 3.82 435.004 9.28 7.41 12.27+j41.75 3.38 435.686 9.24 7.11 12.21+j43.62 2.96 436.368 9.20 6.81 12.17+j45.52 2.58 437.050 9.15 6.52 12.15+j47.43 2.23 437.732 9.09 6.24 12.16+j49.36 1.92 438.414 9.02 5.96 12.18+j51.31 1.64 439.096 8.94 5.68 12.23+j53.27 1.40 439.778 8.86 5.42 12.3+j55.24 1.18 440.460 8.77 5.15 12.4+j57.23 1.00 441.142 8.67 4.90 12.52+j59.23 1.17 441.824 8.56 4.64 12.67+j61.24 1.36 442.506 8.45 4.40 12.84+j63.27 1.57 443.188 8.33 4.16 13.03+j65.3 1.82 443.870 8.20 3.92 13.26+j67.34 2.09 444.552 8.06 3.69 13.5+j69.39 2.38 445.234 7.92 3.46 13.78+j71.45 2.71 445.916 7.77 3.24 14.08+j73.51 3.05 446.598 7.62 3.02 14.41+j75.58 3.41 447.280 7.47 2.81 14.77+j77.65 3.80 447.962 7.31 2.60 15.15+j79.72 4.20 448.644 7.14 2.40 15.56+j81.8 4.61 449.326 6.98 2.21 15.99+j83.88 5.03 450.008 6.81 2.01 16.45+j85.95 5.46
