Calculate a Dipole

Enter the Desired Centre Frequency in Mcs.
i.e. 3.7625 Mcs.

Total length of the dipole will be feet

Each leg of the dipole will be feet

The half-wave dipole is very simple to construct. Use 75 or 50 ohm cable to feed the centre of the dipole. This could be 50 ohm types such as RG58, RG8X, RG8, RG213, or 75 ohm type such as RG11, RG59, RG6 or even 75 ohm twin lead. Even zip cord such as what is used for lamp cords will perform quite well.

With 10 metres being open most days world-wide, why not try a simple ten metre dipole. You only need 16.5 feet of space and if horizontal space is at a premium try hanging it from a broom stick of a balcony. (it is best if you know your neighbours below. hi hi)

Be sure to solder the feedcable to each leg of the dipole. It is also advisable to provide some strain relief which can be accomplished by wrapping the feedcable once around the center insulator and securing with a "black" tie-wrap.

Of course if you are using power in excess of 100 watts, you must be sure that the feedline and insulators will support the power being used.

Enjoy .... Ed --- KB8QEU
