- IN THIS EDITION -

EVARC Upcoming Events/Announcements
 Test Sessions
Hamfests/Conventions
ARRL Letter - May 09, 2008
     Leaving on a Jet Plane to Dayton Hamvention
     FCC Denies Two Amateur Radio Petitions for Rulemaking
     Veteran Wireless Operators Association Honors Two Hams
     New NASA Tool Allows Exploration of Ionosphere from Inside
     Annual Armed Forces Day Crossband Test to Be Conducted May 10
In Brief
Education and Training
Closing Items

EVARC Upcoming Events/Announcements

Next monthly meeting of the Elkhorn Valley Amateur Radio Club
Date:  Saturday, June 14, 2008
Time:  08:30 AM
Location:  Country Café, 1221 Omaha Ave


Minutes from the last meeting can be read on the EVARC Web page

Visitors are always welcome to the meeting.
Bring a Guest to the Meeting

For more Information see the EVARC Web Page

Field Day - 2008

The club will be participating in Field Day again this year.  We will be operating from Sam's Shack.  Field Day is the last full weekend of June which is June 28 - 29 this year.  We will have a picnic dinner the evening of June 28.  If you plan on attending, please contact Sam, WA6BRE and let him know.  A head count is needed to plan for the dinner. Click the following link for a map to Sam's QTH

Top

Test Sessions within 100 miles of Norfolk, NE

For more testing locations see the ARRL Testing Web page

27-May-2008

     Sponsor: AK-SAR-BEN ARC INC

     Time: 6:30 PM (Walk-ins allowed)

     Contact: STEPHEN W RASMUSSEN

                    (402)296-4434

     Email: STEVE_N0WY@WINDSTREAM.NET

     VEC: ARRL/VEC

     Location: AMERICAN RED CROSS HEARTLAND CHAPTER

                      WEST SIDE LOWER LEVEL

                      2912 S 80TH AVE

                      NEAR 84TH AND CENTER

29 May-2008

     Sponsor: Lincoln Amateur Radio Club

     Time: 7:00  PM (Walk-ins allowed)

     Contact: JOHN P HAUNER

                    (402)486-1400

     Email: K0IH@ARRL.NET

     VEC: ARRL/VEC

     Location: HAVELOCK CHRISTIAN CHURCH

                      6520 COLFAX AVE

26-Jun-2008

     Sponsor: Lincoln Amateur Radio Club

     Time: 7:00  PM (Walk-ins allowed)

     Contact: JOHN P HAUNER

                    (402)486-1400

     Email: K0IH@ARRL.NET

     VEC: ARRL/VEC

     Location: HAVELOCK CHRISTIAN CHURCH

                      6520 COLFAX AVE

Top

Type Key:
* = ARRL Convention
** = ARRL Convention pending Executive Committee approval
+ = ARRL Hamfest
x = non-ARRL Hamfest

From the May 09, 2008 ARRL Letter

---

LEAVING ON A JET PLANE TO DAYTON HAMVENTION

"As the song says, 'All our bags are packed and we're ready to go' -- well, almost," said ARRL Hamvention Coordinator Katie Breen, W1KRB. "The ARRL EXPO area www.arrl.org/expo is packed up into seven shipping skids and they are in a truck on their way to Dayton. We here at headquarters are not only breathing a huge sigh of relief, but many of us are still wrapping up our individual final details." The Dayton Hamvention will run from May 16-18 at Hara Arena, just outside Dayton, Ohio www.hamvention.org/.

Breen said that all around the Newington offices, ARRL staffers are putting the last-minute touches on their Dayton preparations: "Frankie Perez, KB1NQR, is finishing up his schedule for checking cards at the DXCC area. By late Saturday afternoon at Hamvention, there will be an area set up by the card checking just for DX Talk. We've named it the DXCC Discussion Zone."

Also new this year is the "Doctor Is IN" booth. This area, Breen said, is all about and just for technology enthusiasts: "QEX Editor Larry Wolfgang, WR1B, has been putting his creative genius to work and coming up with some great plans for that booth! ARRL Circulation Manager Amy Hurtado, KB1NXO, is finalizing details on what will be available in the bookstore and membership area. And me? Well, since this is my first year of coordinating the EXPO, I think I'm just worrying about everyone else at this point!"

Breen said that one thing she is really excited about with this year's EXPO is that the ARRL will host a larger number of volunteers from around the country: "Some of our newer Section Managers, some as far away as Northern California and Florida will be there. ARRL President Joel Harrison, W5ZN, will be attending forums, meeting and greeting members and generally sharing the good stories of all that is happening here at the League. We're also going to have an international presence with the IARU; we are pleased to welcome IARU President Larry Price, W4RA, and IARU Vice President Tim Ellam, VE6SH."

"Amateur Radio is all about the people," Breen remarked. "Without people on the air in various modes, what would Amateur Radio be? Without hams invested in Public Service, what would Amateur Radio be? Without people in their communities volunteering their time, what would Amateur Radio be? I think the Dayton Amateur Radio Association (DARA) hit the nail on the head with this year's theme of 'People + Radio = Fellowship.' When it all comes down to it, we are communicating with each other, regardless of the mode being used. What better opportunity to come together and communicate than at Hamvention, the country's largest gathering of radio enthusiasts?"

Top

FCC DENIES TWO AMATEUR RADIO PETITIONS FOR RULEMAKING

On May 7, the FCC denied two separate Petitions for Rule Making (PRM) dealing with digital issues.

Mark Miller, N5RFX, of Arlington, Texas, sought to delete the FCC's 2006 addition to how it defines data, amend the rules to prohibit automatically controlled stations from transmitting on frequency segments other than those specified in Section 97.221(b), and replace the symbol rate limits in Section 97.307(f) with bandwidth limitations.

The FCC denied all three parts of Miller's PRM, saying he "did not set forth sufficient reasons for the Commission" to approve his petition and that "should future experience substantiate Miller's concerns, he may file a new, factually supported petition for rulemaking." The complete copy of the FCC's reply to Miller is on the FCC Web site http://hraunfoss.fcc.gov/edocs_public/attachmatch/DA-08-1082A1.pdf.

Ken Chafin, W6CPA, of La Crescenta, California, and Leon Brown, KC6JAR, of Los Angeles, California, also filed a PRM concerning additional spectrum for more repeaters, including digital systems, requesting that the FCC "propose to expand the frequencies on which an amateur station operating as a repeater (repeater station) may operate."

Chafin and Brown argued that additional spectrum is needed for repeater stations because some amateur repeater stations have begun using digital communications protocols" and "digital voice operation is incompatible with existing analog operations [because d]igital voice users are unable to determine if the desired frequency is in use by analog users and can inadvertently cause harmful interference to those users." The men pointed out that coordinating groups have been unable to separate analog and digital voice repeater operations to avoid harmful interference because the available repeater spectrum in the 2 meter band is "fully occupied by existing analog users in most metropolitan areas."

The FCC, after considering Chafin and Brown's PRM, concluded that the PRM did not present grounds for the Commission to amend its rules: "Repeater stations are authorized to transmit on any frequency in the 2 meter band except the 144.0-144.5 MHz and 145.5-146.0 MHz frequency segments. These two segments were excluded to minimize the possibility of harmful interference to other amateur service stations and operating activities, including 'weak signal' operations. Allocating an additional three hundred kilohertz of the 2 meter band to repeater operation would not be consistent with that concern. Rather, it would likely result in increased interference to non-repeater stations." The complete copy of the FCC's reply to Chafin and Brown is on the FCC Web site http://hraunfoss.fcc.gov/edocs_public/attachmatch/DA-08-1083A1.pdf.

Top

VETERAN WIRELESS OPERATORS ASSOCIATION HONORS TWO HAMS

At their annual awards banquet on April 26 in New York City, the Veteran Wireless Operators Association (VWOA) www.vwoa.org/ honored two Amateur Radio operators with two of the association's top awards: Fritz Raab, W1FR, and John "Jack" Curtis, K6KU. Raab gave the keynote address at the banquet. "The dinner speech was a wonderful presentation of the Amateur Radio Experiment domestically and that which is happening internationally. He explored what may happen, if things go well for the museum stations on 500 kHz and for radio amateurs," said VWOA Chairman Francis Cassidy. "Ever since the emergence of the Global Marine Distress and Safety System, professional radio officers have discussed the prior use of 500 kHz. They know the attributes in the oceans of the world where ground wave transmissions on the oceans provided their primary informational experience of these transmissions."

Fritz Raab, W1FR, of Burlington, Vermont, received the VWOA's De Forest Audion Gold Medal, honoring his "technical achievements in 35 years of radio engineering." Raab serves as the experimental project manager for The 500 KC Experimental Group for Amateur Radio www.500kc.com/. The ARRL 500 kHz experimental license, WD2XSH, was issued in September 2006 and has 20 active stations.

"I'm kind of excited to see how we can apply modern technology to a 'classic part' of the radio spectrum," Raab told ARRL in 2006 when the experimental license was issued. He pointed out that 500 kHz -- the traditional maritime emergency frequency -- is roughly geometrically halfway between the 136 kHz experimental band and the 160 meter amateur allocation. "In contrast to 160 meters, 500 kHz is low enough to offer good ground wave propagation," Raab said, "but in contrast to 137 kHz, it is high enough to allow us to engage in real communication with realistic equipment."

Raab said he would eventually like to see at least a secondary 600 meter amateur allocation from 495 to 510 kHz. "Besides the opportunities for experimenting at low frequencies, that frequency is well suited to regional groundwave communication," Raab said. He said he envisions the eventual use of the spectrum to provide Amateur Radio emergency communication via groundwave, without having to deal with the vagaries of the ionosphere or causing interference to any other services.

Additional information on the 500 KC Experimental Group for Amateur Radio can be found at the experiment's Web site and also in the July/August 2007 issue of QEX www.arrl.org/qex/2007/07/raab.pdf.

Raab said that it was "a real honor for me to receive an award named after one of the most important inventions in radio, and given by an organization whose members have included a number of the legends in the field. As a newcomer to 500 kHz through our experimental license, it is especially nice to be recognized by a group of people who have actually used 500 kHz for communication."

Raab is chief engineer and owner of Green Mountain Radio Research, a consulting firm that he founded in 1980. He received his BS, MS and PhD in electrical engineering from Iowa State University. Raab is co-author of "Solid State Radio Engineering" and author of more than 100 technical papers; he has been issued 12 patents. Raab's professional activities include RF power amplifiers, radio transmitters and radio-communication/navigation systems. He is a fellow of IEEE and a member of ARRL, Sigma Xi, Association of Old Crows, Armed Forces Communications and Electronics Association and the Radio Club of America.

Jack Curtis, K6KU, of Granite Bay, California, received the VWOA's Marconi Memorial Award Plaque "for his lifetime efforts of perfecting electronic circuits to generate Morse code as exemplified by the development of the Curtis Keyers."

In an article Brad Mitchell, N8YG, wrote for the ARRL Web site in 2002 www.arrl.org/news/features/2002/02/042/, he said, "Modern transceivers incorporate many features that not long ago were considered accessories: CW keyers and SWR meters come to mind. John Curtis, K6KU, created an electronic iambic-keyer circuit and subsequently offered an IC chip to do the job. He revolutionized keying, as we know it."

Mitchell wrote that Curtis, when studying for his Amateur Extra ticket, "decided to get a feel for the requirements of the Extra Class test by undertaking a circuit design project. John built a keyer circuit and learned about digital electronics." This keyer worked so well that Curtis's ham friends told him he should market it. Curtis followed the advice, and in 1969, he placed an ad in "Ham Radio Magazine" announcing the Curtis Electronic Devices EK-38. The -38 and its follow-up, the -39, became so successful that Curtis quit his day job and formed Curtis Electro Devices.

Curtis had established a lot of contacts while working at a semiconductor manufacturing company in the 1960s. These paid off for him when he decided that a keyer circuit could be implemented on a chip. He started with two designs: The 8043 and the 8044. "The 8043 was designed as a completely custom integrated circuit in CMOS," Mitchell wrote. "At the same time, International Microcircuits was looking for a chip in which to test their gate array technology. The first chip down the line was the 8044, produced for Curtis. The 8043 worked first try. It was limited to dit memory, and sold for $7.95 in quantities of 50 or more in 1973. The 8044 also worked right off the bat. It offered dah memory in addition and sold for $24.95 in 1975. The 8044M was introduced in 1980. M stood for meter. A meter could be hooked up to a pin of the 8044M to indicate sending speed."

In 1981 Curtis added mode B keying characteristics to his keyers. Mode B simply added an extra dit or dah when the operator stopped sending, depending on which was sent last. If a dit was sent last, an extra dah would be sent. If a dah were sent last, a dit followed. Curtis added this feature to his 8044B. He introduced several keyers incorporating his new full-featured ICs. The first was the EK430 incorporating the 8043 chip. Curtis also introduced a fully integrated keyboard chip called the 8045. In June 1982, Curtis Electro Devices produced its last keyer, the Lil' Bugger. Offered as the K5 or K5B, it incorporated the 8044 or the 8044B chip, respectively. Both models sold for $39.95 and were quite popular.

In spring of 1986, Curtis introduced the 8044ABM chip. It incorporated selectable A or B modes and the speed meter, becoming an industry standard. In the 1980s, however, microcontrollers were making serious headway and Curtis chips were no longer in demand. MFJ took over part of the line and Curtis Electro Devices ceased operations in April 2000.

The Veteran Wireless Operators Association was founded in 1925 to foster fellowship among wireless operators aboard ship, in the military, and in the shore stations. Through the years, the ranks of the VWOA have included most of the executives and innovators of the broadcasting and communication industry, as well as thousands of radio operators.

Today, in its 83rd year, the VWOA serves as both a link to the history or radio, as well as a bridge to the future. Its members have been, and continue to be, on the front lines of the development of radio and television broadcasting, satellite communications, and the entire digital revolution. Current membership is approximately 300 men and women. Members are concentrated along both US coasts, but members also reside in almost every state as well as Canada and several other countries. For more information on the VWOA, please visit the VWOA Web site www.vwoa.org/.

Top

NEW NASA TOOL ALLOWS EXPLORATION OF IONOSPHERE FROM INSIDE

Last week at the Space Weather Workshop in Boulder, Colorado, NASA released a 4D live model of the Earth's ionosphere http://science.nasa.gov/headlines/y2008/30apr_4dionosphere.htm?list2125 89. Without leaving home, anyone can fly through the layer of ionized gas that encircles Earth at the edge of space itself. All that is required is an Internet connection and a free copy of Google Earth http://earth.google.com/. NASA calls the ionosphere the "last wisp of Earth's atmosphere that astronauts leave behind when they enter space. The realm of the ionosphere stretches from 50 to 500 miles above Earth's surface where the atmosphere thins to near-vacuum and exposes itself to the fury of the sun. Solar ultraviolet radiation breaks apart molecules and atoms creating a globe-straddling haze of electrons and ions."

Using a Google Earth interface, users can fly above, around and through these regions getting a true 4D view of the situation. "The fourth dimension is time. This is a real-time system updated every 10 minutes," said W. Kent Tobiska, president of Space Environment Technologies and chief scientist of its Space Weather Division. The proper name of the system is CAPS, short for Communication Alert and Prediction System. Earth-orbiting satellites feed the system up-to-the-minute information on solar activity; the measurements are then converted to electron densities by physics-based computer codes. It is important to note, Tobiska said on the NASA Web site, that CAPS reveals the ionosphere not only as it is now, but also as it is going to be the near future.

According to propagation specialist Carl Luetzelschwab, K9LA, this model "can provide Amateur Radio operators a broad view of what the ionosphere is doing 'now.' This broad view is due to the fact that the resolution in the color coding schemes only gives coarse estimates of the six parameters available." Luetzelschwab, former editor of "National Contest Journal" (NCJ) www.arrl.org/ncj/, writes a propagation column in NCJ and other publications.

"This is an exciting development," said NASA solar physicist Lika Guhathakurta on the NASA Web site. "The ionosphere is important to pilots, ham radio operators, earth scientists and even soldiers. Using this new 4D tool, they can monitor and study the ionosphere as if they're actually inside it." Guhathakurta made his comments on the NASA Web site.

NASA understands that "[h]am radio operators know the ionosphere well. They can communicate over the horizon by bouncing their signals off of the ionosphere -- or communicate not at all when a solar flare blasts the ionosphere with X-rays and triggers a radio blackout." As radio amateurs, we use -- and depend on -- the ionosphere to make contacts.

Tobiska agrees: "For ham radio operators, this is a great application because it enables them to figure out what frequencies that are going to be available for communicating with any part of the world they want to communicate with at that moment in time. So ham radio operators who are in South Carolina want to talk to someone in Europe or Africa, they can know exactly what frequencies to turn to on their dial."

Luetzelschwab said he personally believes that "The importance of this new product is the fact that this is likely the first physical model of the ionosphere available to the widespread Amateur Radio community. This is in contrast to the model in our current propagation predictions -- such as VOACAP, W6ELProp and the like -- that is based on years of measured ionospheric data correlated to a proxy for the true solar ionizing radiation (the proxies being sunspots and 10.7 cm solar flux)."

NASA explained that it appears that this new physical model takes satellite measurements of solar radiation at extreme ultraviolet (EUV) wavelengths (the true ionizing radiation) and inputs this data, along with a geomagnetic field activity index, into a model of the atmosphere to determine electron densities. Luetzelschwab said "Yes, it only offers a broad view now -- but I think it is a sign of things to come."

More information on this tool for radio amateurs can be found on the ARRL Web site www.arrl.org/news/stories/2008/05/06/10081/.

Top

The Army, Air Force, Navy, Marine Corps and Coast Guard are co-sponsoring the annual Military/Amateur Radio Crossband Communications Test in celebration of the 58th anniversary of Armed Forces Day (AFD). Although the actual Armed Forces Day is celebrated on the third Saturday in May -- May 17 in 2008 -- the AFD Military/Amateur Crossband Communications Test will be conducted on May 10 to prevent conflict with the Dayton Hamvention(r), scheduled for May 16-18.

The annual celebration features traditional military to amateur crossband communications SSB voice tests and copying the Secretary of Defense message via digital modes. These tests give Amateur Radio operators and short wave listeners an opportunity to demonstrate their individual technical skills and to receive recognition from the Secretary of Defense and/or the appropriate military radio station for their proven expertise. QSL cards will be provided to those stations making contact with the military stations. Special commemorative certificates will be awarded to anyone who receives and copies the digital Armed Forces Day message from the Secretary of Defense.

Military-to-Amateur crossband operations will take place on the dates and time in UTC on the frequencies listed for each station on the Army MARS Web site. Voice contacts will include operations in single sideband voice (SSB). Some stations, depending on propagation and manning, may not operate the entire period. Participating military stations will transmit on selected Military MARS frequencies and listen for Amateur Radio stations in the Amateur bands. The military station operator will announce the specific amateur band frequency being monitored. Duration of each voice contact should be limited to 1-2 minutes.

The newly updated list of schedules and frequencies www.netcom.army.mil/MARS/docs/ARMEDFORCESDAYFinal.pdf of participating military stations is published on the Army MARS Web site www.netcom.army.mil/MARS/.

Top

IN BRIEF

• No ARRL Audio News on May 16: There will be no ARRL Audio News on Friday, May 16. The ARRL Letter will be released on that day. ARRL Audio News will return on Friday, May 23.

• ARRL to Blog from Dayton Hamvention: As in previous years, the ARRL will be blogging live www.arrl.org/blog/Dayton%20and%20ARRL%20Expo from Hara Arena, site of the Dayton Hamvention www.hamvention.org/. In addition to keeping everyone up with the latest and greatest at Dayton, this year's blog will feature video clips. QST Editor -- and Hamvention blogger extraordinaire -- Steve Ford, WB8IMY, said, "The video clips were such a big hit with last year's blog that we decided to do even more of them for this year!" Ford says he plans on featuring new products that are debuting at the Hamvention, as well as all the "fun stuff" that pops up: "Both I and the staff have a lot of fun with this, and we hope those who read the blog do, too." Look for the blog to go "live" Thursday, May 15 and continue throughout the Hamvention.

• History Channel Show to Feature Nikola Tesla: Modern Marvels, a series on The History Channel, will feature electricity pioneer Nikola Tesla in an episode scheduled to air May 14 www.history.com/shows.do?action=detail&episodeId=295798. Helping out with the program was Bob "Loby" Lobenstein, WA2AXZ; Lobenstein is General Superintendent, Power Operations for New York City's subway system. "We did 8 hours of taping interviews at my 1904 power substation," Lobenstein said. "In addition to the action scenes of me throwing the 100 year old switches and demonstrating the use of power, I did a 'Mr Wizard' talk, showing the various things that 'Mr T' envisioned and invented. Of course, radio had a part and I just had to put the D-104 mic with our club's K2IRT shield into view!" According to The History Channel, Tesla's "...bizarre vision of the future brought him failure, but his genius electrified the world. Travel to Niagara Falls, where in 1893, Tesla installed his new system of Alternating Electrical Current known as AC -- the same power we use today. Uncover the forgotten ruins of Tesla's dream experiment -- a huge tower on Long Island Sound he hoped would wirelessly power the world. Radar, death rays, invisibility devices and earthquake machines: Tesla claimed to have created them all. More than 100 years ago Tesla foresaw the need for alternative energies like geothermal and solar." Check the The History Channel Web site for show times www.history.com/.

• Colorado Group Receives D-STAR Equipment: The Colorado Council of Amateur Radio Clubs (CCARC) recently teamed up with Ham Radio Outlet (HRO) in Denver to donate a 2 meter, 70 cm and 23 cm D-STAR system stack. According to ARRL Colorado Section Manager and CCARC Board Member Jeff Ryan, K0RM, the two groups hit upon the idea of issuing a Request for Proposal (RFP) to Colorado radio amateurs. "We received three excellent proposals," Ryan said, "and on March 21, CCARC and HRO awarded the D-STAR system to the Colorado D-STAR Association, a consortium of Denver area individuals, clubs and ARES groups." Ryan explained that the goal of the CCARC, which also serves as Colorado's frequency coordination body, was "to spur the interest and use of digital Amateur Radio technology. This is the first D-STAR system that will go on the air in Colorado. The hope is that it is the first of many such systems, ultimately linking the entire Amateur Radio community throughout Colorado and beyond." The 3-band D-STAR system, serving the Denver Metro area and the Front Range of Colorado from Ft Collins to Castle Rock and points east, will be installed this summer at a mountaintop site. The system will have a coverage area of more than 5400 square miles, nearly the size of Connecticut. Ryan said that the RFP placed "special emphasis" on the D-STAR systems being available to ARES groups in the served area, "and also requires the host group to link to any other requesting D-STAR system that comes on the air in Colorado."

Top
