Extract of the PAT48PG Manual in format (png), e.g. readable by IPP4 or MS Photo Editor.
You can view or download following graphics:
Special Information for RAM Configurations is given here:
use PS/2-Modules exclusively on 4 bytes architecture plus real parity!
e.g. in my computer:
RNC2 = installed
M1-PS/2= 2 M x 36 Bit = 8 MByte
M2 = unused
SIM1-4 = 4 x 1M x 9 Bit = 4 MByte
total memory in function = 12 MByte
Good luck,
Helmut Jahn
