CT4SL -
MY
MORSE KEYS COLLECTION |
|
HOME |
PLEASE MAKE YOUR COMMENTS AND E-MAIL THEM TO ME.....HERE
|
#
121 .....
HI-MOUND TC-701
WITH COK-1 CODE
OSCILATOR |
|
HI-MOUND has been in business since just after World War II, and these well-made keys, paddles, and bugs have a well-deserved reputation for quality. "High Mound" is the closest English translation of the founder and President's name-- Takatsuka.
This is the very first morse code oscilator made by Hy-Mound.
|
|
#
122 .....
HI-MOUND
MK-703 |
|
HI-MOUND
has been in
business since
just after World
War II, and
these well-made
keys, paddles,
and bugs have a
well-deserved
reputation for
quality. "High
Mound" is
the closest
English
translation of
the founder and
President's
name--
Takatsuka. |
|
#
123 ..... SINGLE
LEVER PADDLE |
This
single lever
paddle has any
mention of the
manufacturer or
even the country
of it's origin.
Only shows the
number "0075"
engraved on the
botom of the
round piece that
suports the
lever, this one
made with
transparent
plastic.
Has
a black havy
metal square
base with
73x93x18 mm and
four round
rubber feet.
Also is supplied
with
pre-connected
shielded cable
and a chrome
1/8" plug.
Very
well preserved,
as NEW, works
smothly and is
very easy to
adjust the lever
acordingly to
the need of the
operator.
Purchased
on one eBay
auction from
IVAN G.
IVANOV, Sofia
1324, Bulgária. |
|
# 124 ..... CT 73 IAMBIC LEVER PADDLE |
Made in Russia, designed by UR5CDx, with S/N 231 UA 2009
CT 73 Dual Lever (Iambic) Paddle. Polished brass edition.
Unique individual serial number.
Individually hand crafted, finished and packed. Featuring mirror like polishe brass quality, heavy 1.5 kg base measuring 100 x 90 x 46 mm, long 5 foot shielded lead terminated with 2 universal connectors to suit virtually any new or old transceiver as well as 2 sets of solid silver contacts.
Each paddle has a brass plaque stamped with the serial number and year of manufacture. Also is supplied with pre-connected shielded cable and both a gold 1/8" plug and a 1/8 to 1/4" adapter.
For more info about UR5CDX CT Paddles, please click here
Purchased on eBay auction. |
|
# 125 ..... CT HAM IAMBIC LEVER PADDLE |
Made in Russia, designed by UR5CDx, with "S/N 511 UA 2006"
CT HAM is a dual lever paddle that has matte-black base that measures 3-1/8"square and the paddle stands 2-1/8" tall to the tip of the fingerpieces, and the total weight of the paddle is 1 Lb 6-1/4 Oz.
The paddle combines a double-polished natural brass, clear plexiglass fingerpieces, matte-black steel base, SILVER CONTACTS.
Spring and bearing tension are easily adjusted on each side, and the contacts can be set for very narrow spacing.
Each paddle has a brass plaque stamped with the serial number and year of manufacture. Also is supplied with pre-connected shielded cable and both a gold 1/8" plug and a 1/8 to 1/4" adapter.
For more info about UR5CDX CT Paddles, please click here
Purchased to Sérgio Lopes (CT1EBx), Olhão, Algarve, Portugal. |
|
# 126 ..... GLOBALMAN EK-108D ELECTRONIC KEYER |
The EK-108D keyer is one of several designs marketed by Katsumi. It is not an iambic keyer, but operates more like a bug, with a single lever that makes dots and dashes.
The power jack is an 1/8-inch mono phone plug, and despite my best efforts this afternoon and evening, there isn’t a spare 1/8-inch phone plug anywhere in my stash.
this electronic keyer was purchased on eBay from Stockton California, USA
|
|
# 127 ..... SAMSON ETM-2b |
Year: 1968
Details:
Power type and voltage dry batteries 4 × 1,5 Volt
Loudspeaker - For headphones or amp.
Model: Electronic Keyer ETM-2b
Material metal case
Dimensions (WHD) 100 x 52 x 100 mm / 3.9 x 2 x 3.9 inch
This electronic key was purchased on eBay from Alan Dimmick (GM0USI), Glasgow, Scotland.
|
|
#
128 .....
KATSUMI EK-9X |
This is other KATSUMI EK-9x
electronic keyer made by Katsumi
Electronic in Japan.
A very early solid
state electronic keyer. It has the
option of allowing the user to use it as
a bug, emulating the operation of a bug
semiautomatic key, for those who did not
want to make the switch to fully
automatic keyer sending. Uses a relay
for keying so it will work with any type
of keying line including cathode keying.
You could probably key a spark
transmitter with this thing.
It operates smoothly for what it is.
It's not very sophisticated but really
shows you how far the Japanese have come
since the early 1960's in terms of
electronic sophistication.
Purchased to SV1EDY - Athens - Greece. |
|
#
129 .....
KC-1 KANSAS CITY
KEYER |
The Kansas City
Keyer is a
compact,
full-featured
electronic keyer
that employs
microprocessor
thechnology,
with 1500
characters of
memory, for
low-cost and
high
reliability. The
basic functions,
controlled by a
16-position
keypad and
external padlles
are simple to
use and
understand.
Analog and
digital speed
controls,
flexible serial
number
generator, tune
function auto
space, WPM
funtion, padlle
reversal, QRZ
loops, beacons,
variable
weighting,
editing, plus
much more...
Highly
desirable keyer
options, such as
variable
weighting,
variable monitor
tone control,
switchable dot
memory and dash
memory,and
switchable
auto-spacing are
all standard
features of
microprocessor
keyers. On the
other hand,
digital control
of transmition
speed is
satisfactory to
vary few, as
moast operators
find that they
simply cannot
accuratly judge
speed, espetialy
in responding to
another station.
The
KC-1 Kansan City
Keyer, from
Lance
Johnson
solves this
problem neatly,
indeed
elegantly,
giving the
operator a
continuously
variable-speed
controlpot,
while retaining
all the
desirable design
features, and
adding some
significant new
features of its
own. The
features that
the KC-1 offers
are allmost too
numerous to
mention.
Take
a look at the
MANUAL
(5.258 Kb)
or
DOWNLOAD it
(5.242 Kb)
if you pretend
to keep it for
you! You have
also available
the
KC-1 INSTALATION
MANUAL
(5.912 Kb)
to read or to
DOWNLOAD
(5.898 Kb)
Manufactured
by
Lance
Johnson
Engineering,
Kansas City,
Missouri USA.
and purchased on
eBay from Los
Angeles,
California. |
|
#
130 .....
DEWSBURY
ELECTRONICS
SUPA-TUTA |
The
Supa-Tuta
has a vocabulary
of no less than 4260 words and
character with speeds of between
10 and 100 wpm, random letters,
random numbers, random callsigns
(over 3000 stored), no less than
150 QSO-format practise.
More Tests,
punctuation, abbreviations,
Q-Codes, choice of 238
'3-minute' plain texts, plus
Class-A or Novice [modes] and a
host of other useful goodies.
One very nice
Item to learn and practice MORSE
CODE.
Recently
purchased to a friend CT1GFQ.
[
