| Frequency range: | 144-146 / 430-440 MHz |
| Mode: | FM |
| RF Power output: | Hi: 5/5 W, Lo: 0.5/0.5 W |
| Voltage: | 4.5-16 VDC |
| Current drain: | RX: 40-210 mA, TX: Max 1.6 A |
| Impedance: | 50 ohms, BNC |
| Dimensions (W*H*D): | 57*137*33 mm |
| Weight: | 450 gr |
| Manufactured: | 19xx-19xx |
| Other: | RX: 108-950 MHz AM/FM. Twin RX |
