| Frequency range: | 144-148 / 440-450 MHz |
| Mode: | FM |
| RF Power output: | Hi: 5/5 W, Lo3: 3.5/3.5 W, Lo2: 1.5/1.5 W, Lo1: 0.5/0.5 W |
| Voltage: | 6-16 VDC |
| Current drain: | RX: 20-200 mA, TX: Max 1.8 A |
| Impedance: | 50 ohms, BNC |
| Dimensions (W*H*D): | 54*154*36 mm |
| Weight: | 450 gr (with BP-83) |
| Manufactured: | 1991-19xx |
| Other: | 60 memories. RX: 136-174 / 400-470 MHz. Twin RX |
