| Frequency range: | 144-146 / 430-440 MHz |
| Mode: | FM |
| RF Power output: | Hi: 5/5 W, Lo3: 3.5 W, Lo2: 1.5 W, Lo1: 0.5, El: 15 mW |
| Voltage: | 5-16 VDC |
| Current drain: | RX: 15-150 mA, TX: Max 1.5 A |
| Impedance: | 50 ohms, BNC |
| Dimensions (W*H*D): | 57*125*35 mm |
| Weight: | 390 gr |
| Manufactured: | 1992-19xx |
| Other: | RX: 100-950 MHz. Twin RX New price 1992 in Sweden: 4000:- SEK |
| Extras: |
