| Frequency range: | 144-146 / 430-440 MHz (Europe) 144-148 / 440-450 MHz (USA) |
| Mode: | FM |
| RF Power output: | Hi: 45/35 W, Mid: 10/10 W, Lo: 5/5 W |
| Voltage: | 13.8 VDC |
| Current drain: | RX: Max ? mA, TX: Max 10.5 A |
| Impedance: | 50 ohms, SO-239 |
| Dimensions (W*H*D): | 140*40*175 mm |
| Weight: | 1.35 Kg |
| Manufactured: | 1991-19xx |
| Other: | RX:136-174 MHz / 400-479 MHz. Twin RX New price 1991 in Sweden: 7500:- SEK |
| Related documents: |
